1 Overview
See CSDN Poseidon Code with the same title
**1 Reentry Principles and Processes of Ballistic Capsules** Reentry of ballistic capsules relies on blunt body design and high heat-resistant materials, decelerating through aerodynamic drag. During reentry, kinetic energy is converted into thermal energy, absorbed or dissipated by the Thermal Protection System (TPS). **Aerodynamic Heating and Thermal Protection** High temperatures generated by high-speed friction during reentry can reach thousands of degrees Celsius. Ablative materials (such as carbon-phenolic) are used to carry away heat through vaporization of surface materials, or thermal tiles (such as space shuttle ceramic tiles) reflect radiative heat. **Trajectory Control** Ballistic capsules typically lack active control capabilities and rely on the initial reentry angle. An angle that is too large can lead to overheating, while too small may cause the capsule to bounce out of the atmosphere. Limited attitude adjustments can be achieved through center of mass offset or small wings. **2 Reentry Principles and Processes of Lift Vehicles** Lift vehicles (such as the Space Shuttle, X-37B) utilize wings to generate lift, achieving controlled gliding reentry with higher landing accuracy. **Lift Body Design** A flat bottom surface and high angle of attack during reentry increase aerodynamic lift. The lift-to-drag ratio (L/D) is typically between 1-4, allowing lateral maneuvers over hundreds of kilometers. **Thermal Management Strategies** Active cooling (such as hydrogen circulation cooling) or passive thermal protection (enhanced carbon-carbon composites) are employed. High-temperature areas (such as the leading edge of wings) use oxidation-resistant coatings. **Guidance Algorithms** Predictive-corrective guidance adjusts angle of attack and sideslip in real-time, balancing thermal flow, overload, and range requirements. For example: – **Numerical Prediction**: Integrating motion equations based on current state. – **Closed-loop Correction**: Eliminating heading deviations through lateral maneuvers. **3 General Reentry Process** **1. Deorbit Phase** Retro rockets decelerate, lowering the perigee into the atmosphere (about 120 kilometers). **2. Initial Reentry** Entering the atmosphere at an angle of 25-40 degrees, relying on aerodynamic drag to decelerate. The ballistic capsule free-falls while the lift vehicle begins gliding. **3. Blackout Zone** At altitudes of 80-40 kilometers, plasma sheath interrupts communication for about 4 minutes. **4. Terminal Energy Management** Below 30 kilometers, the lift vehicle adjusts its heading to align with the landing site, while the ballistic capsule deploys parachutes. **5. Landing** The ballistic capsule lands by parachute (e.g., Soyuz), while the lift vehicle lands horizontally (e.g., Space Shuttle). **4 Key Technical Challenges** – **Reliability of Thermal Protection Systems**: Must withstand extreme temperature gradients and mechanical stresses. – **Accuracy of GNC Systems**: Lift vehicle reentry requires high-precision attitude control, with error tolerance less than 0.1 degrees. – **Material Degradation**: Performance of thermal protection layers declines after multiple reentries, necessitating reusable designs.
2 Partial Code and Running Steps
2.1 Partial Code2.2 Running Steps
(1) Directly run main.m to generate the graph with one click
3Running Results
4MATLAB Version and References
1 MATLAB Version
2019b
2 References
[1] Men Yunge. MATLAB Physical Computation and Visualization [M]. Tsinghua University Press, 2013.
3 Note
This section is extracted from the internet for reference only. If there is any infringement, please contact for removal.
