1 Overview

See CSDN Poseidon with the same title

**1 Hybrid Millimeter Wave Channel Simulation Principles for Joint Communication and Positioning** The millimeter wave frequency band (30-300GHz) has become a key technology for high-precision positioning and high-speed communication due to its large bandwidth characteristics. The hybrid simulation of joint communication and positioning needs to consider the following core principles: **Multipath Channel Modeling** Millimeter wave channels exhibit sparse multipath characteristics, described by geometric random models (e.g., 3GPP TR 38.901) that detail path loss, delay spread, and angle spread: – Path loss model: $PL(d) = PL_0 + 10n ext{log}_{10}(d) + X_ ext{sigma}$ where $d$ is the distance, $n$ is the path loss exponent, and $X_ ext{sigma}$ is the shadow fading. **Joint Design of Signal Parameters** Positioning and communication share pilot signals, achieving time-frequency resource multiplexing through Orthogonal Frequency Division Multiplexing (OFDM) frame structure. Key parameters include: – Bandwidth $B$ determines delay resolution $ ext{Δ} au = 1/B$ – Antenna array aperture determines angle resolution $ ext{Δ} heta ext{≈} ext{λ}/Nd$ **Hardware Impairment Compensation** It is necessary to model hardware effects such as phase noise and power amplifier nonlinearity, using iterative algorithms to separate communication and positioning errors. **2 Simulation Process Implementation** **Scene and Parameter Configuration** – Define topology (indoor/outdoor), base station/user equipment (UE) locations, and mobility trajectories – Set carrier frequency (e.g., 28/60GHz), bandwidth (≥500MHz), antenna array (ULA/UPA) **Channel Generation** 1. Generate multipath components (MPC) based on ray tracing or random models 2. Calculate the delay $ au_k$, angle of arrival $ heta_k$, and angle of departure $ ext{φ}_k$ for each path 3. Construct the channel matrix $H$: $$H(t,f) = ext{∑}_{k=1}^K ext{α}_k ext{a}_r( heta_k) ext{a}_t^H( ext{φ}_k)e^{-j2 ext{π}f au_k}$$ **Signal Processing Chain** – **Communication Link**: Calculate Signal-to-Noise Ratio (SNR) and spectral efficiency $SNR = rac{ ext{∥}H ext{w}∥^2 P_t}{N_0B}$ – **Positioning Link**: Estimate multipath parameters using MUSIC or compressed sensing algorithms, constructing the positioning equation: $$ ext{ˆ} ext{p} = ext{arg} ext{min}_{ ext{p}} ext{∑}_{k=1}^K ext{∥}τ_k – rac{ ext{∥} ext{p} – ext{b}_k∥}{c}∥^2$$ **Performance Evaluation Indicators** – Communication side: Bit Error Rate (BER), throughput – Positioning side: Root Mean Square Error (RMSE), Cramér-Rao Lower Bound (CRLB) **3 Key Implementation Technologies** **Hybrid Beamforming** A digital-analog hybrid architecture is adopted to balance positioning accuracy and hardware complexity. Code example (MATLAB): “`matlab % Generate hybrid beam weights F_RF = exp(1j*2*pi*rand(Nt, N_RF)); % Analog beam F_BB = sqrt(1/N_RF)*eye(N_RF); % Digital beam W = F_RF * F_BB; % Hybrid beam matrix “` **Machine Learning Enhancement** Utilize deep neural networks to solve Non-Line-of-Sight (NLOS) path recognition problems: “`python # NLOS classification model in PyTorch class NLOS_Classifier(nn.Module): def __init__(self): super().__init__() self.lstm = nn.LSTM(input_size=64, hidden_size=128) self.fc = nn.Linear(128, 2) # Binary classification “` **Dynamic Resource Allocation** Achieve Pareto optimality between communication rate and positioning accuracy through convex optimization: $$ ext{max}_{ ext{R}, ext{P}} ext{ηR} + (1- ext{η}) ext{log}(1/ ext{CRLB})$$ s.t. $ ext{R} ext{∈} ext{C}, ext{P} ext{≤} P_{ ext{max}}$

2 Partial Code and Running Steps

2.1 Partial Code2.2 Running Steps

(1) Directly run main.m to generate the graph with one click

3Running Results

4MATLAB Version and References

1 MATLAB Version

2019b

2 References

[1] Ni Yiyang, Zhu Hongbo, Wang Yuxi. Overview of Millimeter Wave D2D Communication Technology for 5G [J]. Modern Electronic Technology. 2019

[2] Wan Yuan, Li Xingguo, Wang Hong. Application of Channel Coding Technology in Millimeter Wave Communication [J]. Journal of Ordnance and Guidance. 2006

3 Note

This section is excerpted from the internet for reference only. If there is any infringement, please contact for deletion.
