1 Overview

See CSDN Sea God Light with the same title

Constant-Amplitude Multi-Beamforming (CAMB) is a technology for achieving multi-beam coverage in millimeter wave communication. Its core lies in beamforming through phase control while maintaining a constant amplitude of the transmitted signal, reducing hardware complexity and improving power efficiency.

**1 Algorithm Principles**

1. **Constant Amplitude Constraint**

The algorithm requires that the amplitude of the transmitted signal from each antenna element is the same, and beamforming is achieved solely through phase adjustments. The mathematical expression is:

|w_i| = 1, orall i \\in \{1, 2, \ldots, N\}

where w_i is the weight of the i-th antenna element, and N is the total number of antennas.

2. **Multi-Beam Generation**

By optimizing the phase distribution, a single antenna array can simultaneously generate multiple beams to cover users in different directions. The objective function is typically to maximize the signal strength in the target direction while suppressing interference in other directions.

3. **Phase Optimization**

Iterative algorithms (such as gradient descent or convex optimization) are used to adjust the phase so that the synthesized beam pattern meets the needs of multiple users. Common optimization objectives include:

• Maximizing beam pointing gain
• Minimizing inter-beam interference
• Satisfying specific coverage requirements

**2 Algorithm Process**

1. **Initialize Phase**

Randomly generate or initialize the phase values \theta_i for each antenna element based on preset beam directions, with weights w_i = e^{j\theta_i}.

2. **Pattern Synthesis**

Calculate the array pattern F(\phi) under the current weights:

F(\phi) = \sum_{i=1}^N w_i e^{j k d_i \sin \phi}

where \phi is the azimuth angle, k is the wave number, and d_i is the antenna spacing.

3. **Objective Function Evaluation**

Design the objective function based on multi-beam requirements, such as:

• Maximizing main lobe gain
• Minimizing side lobe levels
• Power balancing among multiple beams

4. **Phase Iterative Optimization**

Adjust the phase using numerical methods (such as genetic algorithms or particle swarm optimization) to gradually approach the optimal solution. Update \theta_i in each iteration and recalculate the pattern.

5. **Convergence Check**

Terminate when the change in the objective function is less than a threshold or the maximum number of iterations is reached, outputting the final phase distribution.

**3 Application Scenarios**

– **Millimeter Wave Base Stations**: Covering multiple users or sectors.

– **Satellite Communication**: Achieving multi-point beam switching.

– **Radar Systems**: Multi-target tracking and detection.

**4 Advantages and Challenges**

– **Advantages**: Simple hardware implementation (no amplitude control required), high power efficiency.

– **Challenges**: High complexity in phase optimization, potential interference between multiple beams.

By reasonably designing the phase distribution, constant amplitude multi-beamforming can balance performance and hardware costs in millimeter wave systems.
