2D ISAC Imaging Simulation of Millimeter Wave OFDM Signals Based on MATLAB MUSIC Algorithm (Including MATLAB Source Code)

Click the blue text above to follow us

Message from the author

🔊 Author Introduction: Graduate student from a top university, researcher in the field of MATLAB;

🚅 Motto: A journey of a thousand miles begins with a single step.

✅ Research Areas: Complete code, paper reproduction, program customization, journal writing, research collaboration

🏆 Code Acquisition Method: Method to obtain MATLAB code for the “Sea God’s Light”

For more MATLAB signal processing simulation content, click below👇

MATLAB Signal Processing (Advanced Version)

MATLAB Signal Processing Radar Communication (Affordable Version)

Introduction

📋📋📋 The contents of this article are as follows: 🎁🎁🎁

Table of Contents

💥1 Overview

📚2 Code and Execution Steps

🎉3 Execution Results

🌈4 MATLAB Version and References

🔎5 Code Acquisition Method

🍅6 Simulation Consultation

1 Overview

See CSDN Sea God’s Light with the same title

**1 MUSIC Algorithm Principle** The MUSIC (Multiple Signal Classification) algorithm is a high-resolution direction of arrival (DOA) estimation method based on subspace decomposition. Its core idea is to decompose the covariance matrix of the received signal into signal and noise subspaces, utilizing the orthogonality of the noise subspace and the signal direction vectors to construct the spatial spectrum function. For millimeter wave OFDM signals, the MUSIC algorithm can be extended to two-dimensional parameter estimation (joint distance-angle estimation). The signal model can be represented as: $X = A(θ)S + N$ where $A(θ)$ is the direction matrix, $S$ is the signal matrix, and $N$ is the noise matrix. **2 2D ISAC Imaging Process** **Signal Preprocessing Stage** The millimeter wave OFDM communication signal is transmitted after orthogonal modulation, and the receiving end collects the echo signal through an antenna array. The received signal undergoes carrier synchronization and symbol timing synchronization to eliminate frequency offset and timing deviation. **Distance Dimension Processing** The frequency domain characteristics of the OFDM signal are utilized for distance estimation. An FFT transformation is performed on each subcarrier to extract phase information and construct the distance dimension vector: $R(f_k) = \\sum_{n=0}^{N-1} r_n e^{-j2πkn/N}$ **Angle Dimension Processing** A uniform linear array or planar array is used to receive the signal, and the array covariance matrix is calculated: $R_{xx} = E[XX^H]$ Eigenvalue decomposition is performed on it, and the eigenvectors corresponding to the smaller eigenvalues are selected to form the noise subspace $U_n$. **Two-Dimensional Joint Estimation** A two-dimensional spatial spectrum function is constructed: $P(θ,d) = rac{1}{a^H(θ,d)U_nU_n^Ha(θ,d)}$ where $a(θ,d)$ is the joint steering vector containing distance and angle information. Two-dimensional parameter estimation is achieved through peak searching. **3 Key Points of Simulation Implementation** **Parameter Settings** – Carrier frequency: 24-30GHz millimeter wave band – OFDM parameters: Number of subcarriers 256, cyclic prefix length 64 – Antenna array: 4×4 URA configuration, element spacing half wavelength **Key Steps** Generate OFDM baseband signal, add cyclic prefix and window function Simulate target reflection echo, considering multipath delay and angle offset Calculate two-dimensional spatial spectrum and perform peak detection Improve resolution through interpolation algorithms **Performance Evaluation Metrics** – Distance resolution: $\\Delta d = c/(2B)$ – Angle resolution: $\\Deltaθ ≈ 2/(Mcosθ)$ – Mean Square Error (MSE) curve – Detection probability and false alarm probability curve **4 Typical Simulation Results** Under the condition of SNR=10dB, the algorithm can achieve: – Distance estimation accuracy better than 0.1m – Angle estimation accuracy better than 1° – Multi-target resolution capability: effectively distinguish when the target spacing is greater than the Rayleigh limit – Imaging results can clearly display the distribution of target scattering points This simulation method can be extended to MIMO-OFDM systems, further enhancing imaging performance through space-time coding. In practical implementation, RF imperfections and array calibration and other non-ideal factors must be considered.

2 Code and Execution Steps

2.1 Partial Code2.2 Execution Steps

(1) Directly run main.m to generate the figure with one click

3Execution Results

4 MATLAB Version and References

1 MATLAB Version

2019b

2 References

[1] Ni Yiyang, Zhu Hongbo, Wang Yuxi. Overview of Millimeter Wave D2D Communication Technology for 5G. Modern Electronic Technology. 2019
