MATLAB Tips: Simple Yet Powerful Techniques You Can’t Forget

In MATLAB, there is a super simple yet powerful feature: flatten any n-dimensional array into a column vector in column-major order.

No matter what the original dimension of A is:

• 1 dimensional, 2 dimensional, 3 dimensional, N dimensional

• 4×4, 512×1024, 128×128×64

As long as you write: v = A(:); You will get a 1 column vector.

Since MATLAB‘s underlying storage is column-major (Fortran storage method), which we know as “column-major order”, the memory layout of A is:

A(:,1), A(:,2), A(:,3), … arranged sequentially

Therefore, (:) actually lays out the memory order completely, with zero overhead and very fast. Thus, (:) the value of “one-click flattening” lies in transforming complex multidimensional problems into 1D processing:

• Modify a portion of elements in the matrix based on certain conditions;

• Perform some operation on each element;

• Batch process N×M data;

• When writing algorithms, just think about “doing something for all samples” instead of dealing with multidimensional structures.

(:) is commonly paired with: reshape

If you flatten the matrix and want to reshape it back or change dimensions:

A1 = reshape(v, size(A));B = reshape(A, new_rows, new_cols);

In MATLAB, reshape does not change the underlying data, it only changes the “view” (how dimensions are interpreted), for example: A = reshape(1:8, [2 4]) has memory as [1 2 3 4 5 6 7 8], but is interpreted as:

1 3 5 72 4 6 8

Using (:) to flatten is essentially “changing the view back to one-dimensional”.

The number of elements used with reshape must match, otherwise it will throw an error, and the matrix after reshape is still constructed in column-major order. Understanding this, you will immediately know the result of all dimension transformations without trial.

Application Scenario 1: Modify the matrix based on conditions (without writing a for loop), for example, compressing all points exceeding a threshold to th, without needing a loop or find:

th = 0.5;A = rand(1024, 4096);v = A(:);v(v > th) = th;A2 = reshape(v, size(A));

Application Scenario 2: Perform operations on a certain dimension, but the algorithm is better suited for 1D writing, for example, normalizing all elements of a matrix, making global normalization of a multidimensional matrix very elegant:

A = rand(256, 1024);v = A(:);v = (v - min(v)) / (max(v) - min(v));A_norm = reshape(v, size(A));

Since the underlying linear data remains unchanged, reshape(A,3,2) merely interprets this segment of data in a new dimension without copying data, thus it is extremely fast (O(1) operation), so you need not worry about performance when performing complex data dimension transformations.
