Overview
Xilinx Shift RAM IP is a LogiCORE™ IP core provided by AMD Xilinx, designed to implement efficient shift registers in FPGAs. This IP core utilizes the FPGA’s Distributed RAM or Block RAM resources to create a configurable shift register that supports user-defined width and depth, suitable for scenarios requiring data delay, data buffering, or pipelining. The Shift RAM IP offers flexible input/output interfaces and control signals, supporting synchronous operations, and is widely used in digital signal processing (DSP), communication systems, and data stream processing.
Main Features
The core functionality of the Shift RAM IP is to implement efficient shift registers, supporting the following features:
- Configurable Shift Register:
- Supports input/output data widths from 1 to 256 bits.
- Supports depths (delay lengths) from 2 to 4096 shift cycles.
- Distributed RAM: Uses LUTs in CLBs (Configurable Logic Blocks) as storage elements, suitable for small depth shift registers.
- Block RAM: Uses dedicated Block RAM (BRAM) in the FPGA, suitable for large depth shift registers.
- Supports Clock Enable (CE) to control shift operations.
- Supports Synchronous Clear (SCLR) to reset the contents of the shift register.
- Supports Synchronous Initialization (SINIT) to initialize outputs to user-defined values.
- D: Data input, supporting multi-bit wide vectors.
- Q: Data output, providing shifted data.
- Optional address input (A) for direct access to specific shift depths (only in Block RAM mode).
- Maximum frequency varies by device and implementation method, with typical values reaching hundreds of MHz (e.g., exceeding 400 MHz on UltraScale devices).
- Optimized timing performance, suitable for high-throughput applications.
- 7 Series FPGAs (Artix-7, Kintex-7, Virtex-7, Zynq-7000).
- UltraScale and UltraScale+ series.
- Older devices like Spartan-6, Virtex-6 (requires ISE tools).
IP Core Architecture
The internal architecture of the Shift RAM IP varies based on the implementation method (Distributed RAM or Block RAM), with core components including:
- Shift Register Logic:
- Implements stage-by-stage shifting of data, with input data D shifting back one position on each clock cycle, ultimately outputting from Q.
- In Distributed RAM mode, small shift registers are implemented using LUTs.
- In Block RAM mode, deep shift registers are implemented using BRAM.
- Handles CE, SCLR, and SINIT signals to ensure synchronous operations.
- In Block RAM mode, supports address input (A) to access data at specific depths.
- Distributed RAM: Utilizes LUT resources in CLBs, suitable for smaller depth shift registers (typically < 64 bits).
- Block RAM: Utilizes dedicated BRAM resources in the FPGA, suitable for larger depth shift registers (> 64 bits).
- Provides a simple parallel interface, including clock (CLK), data input (D), data output (Q), and control signals.
- In Block RAM mode, optional address input (A) supports random access.
This IP core is instantiated through the Vivado Design Suite’s IP Integrator or HDL, automatically optimizing resource allocation and timing performance.
Configuration Options
The Shift RAM IP offers various configuration options, which users can set through the IP customization interface in Vivado or Tcl scripts. The main configuration parameters include:
- Implementation Method:
- Distributed RAM: Uses LUT resources, suitable for small depth shift registers.
- Block RAM: Uses BRAM resources, suitable for large depth shift registers.
- Configurable from 1 to 256 bits, defining the bit width of input D and output Q.
- Configurable from 2 to 4096 shift cycles, defining the delay length.
- CE: Clock enable, controls shift operations (enabled by default).
- SCLR: Synchronous clear, resets the contents of the shift register to 0.
- SINIT: Synchronous initialization, initializes output Q to user-defined values (SINIT_VALUE).
- Sets the output value during SINIT operation, with bit width matching the data width.
- Default value is 0.
- A: Address input, allows access to specific depth register values.
- Address bit width is ceil(log2(depth)), for example, 8 bits are needed for a depth of 256.
- Speed Optimization: Prioritizes increasing clock frequency.
- Area Optimization: Reduces resource usage (e.g., choosing Distributed RAM over BRAM).
- Supports single clock input (CLK), which can be driven by BUFG or MMCM/PLL.
Example Configuration
Below is a Verilog instantiation example of a Distributed RAM shift register with 8-bit width and 16-bit depth:
module shift_ram_example ( input wire clk, // Clock input input wire ce, // Clock enable input wire sclr, // Synchronous clear input wire [7:0] d, // Data input output wire [7:0] q // Data output ); c_shift_ram #( .C_WIDTH(8), // 8-bit width .C_DEPTH(16), // 16-bit depth .C_MEMORY_TYPE("Distributed"), // Distributed RAM .C_SINIT_VALUE(8'h00), // Initial value of 0 .C_HAS_CE("TRUE"), // Enable CE .C_HAS_SCLR("TRUE")// Enable SCLR) shift_ram_inst ( .CLK(clk), .CE(ce), .SCLR(sclr), .D(d), .Q(q) );
endmodule
