1 Overview
**1 Principle of PSO Algorithm in Characterizing Piezoelectric Material Parameters** Particle Swarm Optimization (PSO) optimizes the objective function by simulating collective intelligence behavior. In the characterization of piezoelectric material parameters, PSO is used to minimize the error between the measured impedance curve and the model simulation impedance curve. Each particle represents a set of candidate parameters (such as elastic constants, dielectric constants, piezoelectric coefficients), and iteratively updates the particle position (parameter combination) to approach the global optimal solution. The fitness function is typically defined as: $$ f(\theta) = \sum_{i=1}^{N} |Z_{meas}(f_i) – Z_{model}(f_i, \theta)|^2 $$ where $Z_{meas}$ is the measured impedance, $Z_{model}$ is the simulated impedance based on the equivalent circuit model, and $\theta$ is the parameter vector to be determined. **2 Impedance Measurement and Preprocessing Process** The impedance analyzer measures the impedance magnitude and phase of the piezoelectric device over a specific frequency range (usually 1Hz-10MHz). The raw data must undergo normalization and noise filtering to eliminate instrument errors and parasitic effects. Typical preprocessing includes: – Calibration to remove fixture parasitic parameters – Data interpolation to ensure uniform distribution of frequency points – Logarithmic transformation to enhance low-frequency weight **3 Equivalent Circuit Model Construction** The commonly used Butterworth-Van Dyke (BVD) equivalent circuit model for piezoelectric devices is: $$ Z_{model} = \left[ j\omega C_0 + \frac{1}{R_m + j\omega L_m + 1/(j\omega C_m)} \right]^{-1} $$ The parameter vector $\theta = [C_0, R_m, L_m, C_m]$ corresponds to static capacitance, mechanical loss, dynamic inductance, and dynamic capacitance, respectively. **4 PSO Parameter Extraction Implementation Steps** Initialize the particle swarm, setting the parameter ranges based on the material type: – $C_0$: 1pF-100nF – $R_m$: 0.1-100Ω – $L_m$: 1μH-1H – $C_m$: 1pF-1μF Set PSO hyperparameters: – Number of particles: 30-100 – Learning factors: $c_1=c_2=1.5$ – Inertia weight: 0.4-0.9 linearly decreasing – Maximum number of iterations: 200-500 In each iteration, calculate the particle fitness and update the individual and global optimal positions. The termination condition is a relative error less than 1e-4 or reaching the maximum number of iterations. **5 Result Verification and Error Analysis** After obtaining the optimal parameters, cross-validation is required: 1. Compare the correlation coefficient between the measured and simulated impedance curves (should be >0.95) 2. Check the physical validity of the parameters (e.g., negative values are invalid) 3. Verify transducer efficiency: $$ k_t = \frac{e_{33}}{\sqrt{c_{33}^D \epsilon_{33}^S}} $$ where $e_{33}$ is the piezoelectric constant, $c_{33}^D$ is the elastic stiffness, and $\epsilon_{33}^S$ is the dielectric constant. The typical $k_t$ for PZT materials should be in the range of 0.4-0.7. **6 Notes** The frequency range selection must cover resonance/anti-resonance peaks: – Thin sheet samples: 100kHz-10MHz – Bulk samples: 10kHz-1MHz For multilayer structures, a modified BVD model should be used, adding parallel branches. Anisotropic materials need to introduce direction-dependent parameters, which will expand the parameter vector dimension to 6-8.
2 Partial Code and Running Steps
2.1 Partial Code2.2 Running Steps
(1) Directly run main.m to generate the plot with one click
3Running Results
4MATLAB Version and References
1 MATLAB Version
2019b
2 References
[1] Hu Shaochuang. Research on Estimation of Thermal Radiation Parameters of Translucent Materials Based on Particle Swarm Algorithm[D]. Civil Aviation University of China. 2024
3 Remarks
This section is excerpted from the internet for reference only. If there is any infringement, please contact for removal.
