BLE Bluetooth modules are extremely common wireless communication modules, widely used in various smart devices. By utilizing low-power Bluetooth technology, they connect various devices in the home, adjusting the smart home system through automatic sensing of the environment and human conditions, which is the IoT engineer‘s design for smart home Bluetooth solutions.
Before designing Bluetooth solutions and selecting BLE Bluetooth modules, it is essential to understand the application scenarios of the Bluetooth solution, the functions to be achieved (application block diagram), and the interfaces that can be provided during the function implementation (master/slave devices, functionalities). Consider module power supply, size, receiving sensitivity, transmitting power, Flash, RAM, power consumption (broadcast, continuous transmission, deep sleep, standby), connection distance, interfaces, antennas, cost-effectiveness, etc.
According to the Bluetooth standard, BLE Bluetooth modules are roughly divided into BLE4.0 modules, BLE4.2 modules, and BLE5.0 modules, among which BLE5.0 modules support Bluetooth Mesh technology; if the Bluetooth solution requires a Bluetooth module that supports master-slave integration, you can choose the BLE4.0 module SKB360 or the BLE5.0 module SKB369. If you want to achieve Mesh networking applications, prioritize Bluetooth 5.0 modules that support Bluetooth Mesh technology.
Parameters for Selecting BLE Bluetooth Modules
Connection Distance: Choose based on the distance; determine which BLE Bluetooth module can better meet data transmission needs according to the actual application distance of the Bluetooth solution.
Communication Interface: The module products themselves are designed to shorten the product launch cycle, and to facilitate the use of Bluetooth modules, existing BLE Bluetooth modules provide flexible hardware interfaces, supporting UART/SPI/GPIO/I²C/I²S/PWM interfaces, allowing users to start based on the actual needs of the Bluetooth solution.Operating Mode: BLE Bluetooth is generally divided into master, slave, master-slave integrated/slave connected; one master can currently communicate with a maximum of 7 slaves, supporting point-to-point communication. Based on supporting Bluetooth Mesh technology, it can achieve a “many-to-many” signal transmission mode, meeting more connection requirements.Power Consumption: BLE Bluetooth modules are known for their low power consumption, but because they have multiple operating states: broadcasting (100ms interval), continuous transmission (20ms interval), deep sleep (μA), standby (μA); the power consumption values in each state are different, which needs to be determined by engineers based on the actual Bluetooth solution.If two modules seem suitable based on parameters, it is recommended to seek assistance from engineers for selection, testing, and sample requests; understanding the basic selection tips for BLE Bluetooth modules during the Bluetooth solution design phase will surely make the engineers’ design work more efficient.
