1 Overview

See CSDN Sea God’s Light with the same title

**1 Analysis of Human Blockage in Urban Millimeter-Wave Cellular Communication** The millimeter-wave frequency band (30-300GHz) has high bandwidth advantages in 5G communication but is easily affected by obstacles such as the human body. Human blockage can lead to signal attenuation, multipath effects, and link interruptions. The analysis principle is based on the following core mechanisms: **Electromagnetic Wave Propagation Characteristics** The free-space path loss formula for millimeter waves is: $$ L_{fs} = 92.4 + 20 ext{log}_{10}(f) + 20 ext{log}_{10}(d) $$ where $f$ is the frequency (GHz) and $d$ is the distance (km). The absorption attenuation of millimeter waves by the human body can reach 20-40dB, depending on the frequency and angle of incidence. **Scattering and Diffraction Model** The roughness of the human body surface causes non-specular reflection, and the Knife-edge diffraction model is commonly used to calculate diffraction loss: $$ L_{diff} = 6.9 + 20 ext{log}_{10}( ext{sqrt}((v-0.1)^2 +1) + v -0.1) $$ where $v$ is the Fresnel zone parameter, related to the height and position of the obstacle. **2 Human Blockage Analysis Process** **Data Collection Phase** Channel parameters are obtained through ray tracing simulation or actual measurement: – Use 3D laser scanning to establish a human geometric model – Vector network analyzer measures S parameters in the 28/60GHz frequency band – Dynamic capture system records pedestrian movement trajectories **Modeling and Simulation Phase** A hybrid modeling approach is adopted: – Determine the dielectric constant of human body materials ($ ext{ε}_r=3-50$, $ ext{σ}=0.5-15$S/m) – Simulate crowd density based on time-varying Poisson processes – Use Monte Carlo methods to evaluate blockage probability: $$ P_{block} = 1 – e^{- ext{λ} A_{shadow}} $$ where $ ext{λ}$ is the human density per unit area and $A_{shadow}$ is the shadow area. **Performance Evaluation Metrics** – Interruption probability: The proportion of time the received signal is below the threshold (typically -85dBm) – Spatial availability: The percentage of the coverage area that meets QoS requirements – Delay spread: The maximum delay difference of multipath components (typical values 5-20ns) **3 Mitigation Strategy Verification** **Beam Switching Optimization** A fast beam switching algorithm based on blockage prediction, with a switching delay of less than 100ms. Beamforming weight calculation: $$ extbf{w} = ext{arg} ext{max}_{ extbf{w}} ext{||H extbf{w}||}^2 $$ where $ extbf{H}$ is the channel matrix. **Intelligent Reflective Surface Deployment** The phase adjustment formula for RIS units: $$ heta_n = ext{mod}igg(-rac{2 ext{π}}{ ext{λ}}(d_{n}^{tx} + d_{n}^{rx}), 2 ext{π}igg) $$ where $d_{n}^{tx}$ and $d_{n}^{rx}$ are the distances to the transmitter and receiver, respectively. **Machine Learning Prediction** The input to the LSTM network includes: – Historical channel state information (CSI) – Pedestrian movement speed (0-1.5m/s) – Base station height (3-10m) The output blockage probability prediction error can be controlled within 8%.

2 Code and Running Steps

2.1 Partial Code2.2 Running Steps

(1) Directly run main.m to generate the graph with one click

3Running Results

4MATLAB Version and References

1 MATLAB Version

2019b

2 References

[1] Ni Yiyang, Zhu Hongbo, Wang Yuxi. Overview of Millimeter-Wave D2D Communication Technology for 5G [J]. Modern Electronic Technology. 2019

[2] Wan Yuan, Li Xingguo, Wang Hong. Application of Channel Coding Technology in Millimeter-Wave Communication [J]. Journal of Ordnance and Guidance. 2006

3 Note

This section is excerpted from the internet for reference only. If there is any infringement, please contact for removal.
