QT C++: Digital Management System for Device Management

Further enhance the digital management system for device management in terms of integrity, usability, and maintainability, focusing on plugin management, database, device communication, configuration, logging, and main window status for functional enhancements. Below is the detailed design process:

Enhancing Plugin Management Functionality

Design Objective: Achieve lifecycle management of plugins (start/stop), enable/disable, dependency checks, and version compatibility, improving the stability and maintainability of the plugin system.

Technical Solution

1. Extend Plugin Interface: Add <span>IPlugin</span> (the base interface for all plugins) with new methods <span>start()</span> and <span>stop()</span> to manage the plugin lifecycle.

2. Plugin State Management: <span>PluginManager</span> maintains the “enable/disable” flag for plugins, skipping disabled plugins during loading.

3. Dependency Resolution: Declare dependencies on other plugins in the plugin metadata (<span>.json</span>), and <span>PluginManager</span> checks dependencies before loading.

Code Example

// iplugin.h (new lifecycle and basic configuration) #ifndef IPLUGIN_H #define IPLUGIN_H #include <QObject> #include <QString> #include <QJsonObject> class IPlugin : public QObject { Q_OBJECT public: virtual ~IPlugin() = default; virtual QString pluginName() const = 0; // Plugin name virtual QString version() const = 0; // Version number virtual QString description() const = 0; // Description virtual QStringList dependencies() const = 0; // List of dependent plugin names virtual bool isEnabled() const = 0; // Is enabled virtual void setEnabled(bool enabled) = 0; // Set enabled state virtual void start() = 0; // Start plugin (initialize resources, register services, etc.) virtual void stop() = 0; // Stop plugin (release resources, unregister services) }; Q_DECLARE_INTERFACE(IPlugin, "com.example.IPlugin/1.0") #endif // IPLUGIN_H

// pluginmanager.cpp (enhanced dependency and lifecycle management) void PluginManager::loadPlugins(const QString &pluginDirPath) { // 1. Scan the plugin directory and read the metadata (.json) for each plugin QDir dir(pluginDirPath); dir.setFilter(QDir::Files | QDir::Readable); for (const QFileInfo &fileInfo : dir.entryInfoList()) { QPluginLoader *loader = new QPluginLoader(fileInfo.absoluteFilePath(), this); QObject *pluginObj = loader->instance(); if (!pluginObj) { qWarning() << "Plugin loading failed:" << fileInfo.fileName() << loader->errorString(); delete loader; continue; } // 2. Cast to IPlugin interface and check dependencies IPlugin *plugin = qobject_cast<IPlugin*>(pluginObj); if (!plugin) { qWarning() << fileInfo.fileName() << "does not implement IPlugin interface"; loader->unload(); delete loader; continue; } // Check if all dependencies are satisfied bool depsSatisfied = true; for (const QString &depName : plugin->dependencies()) { bool depFound = false; for (IPlugin *p : m_allPlugins) { // m_allPlugins is all loaded (not disabled) plugins if (p->pluginName() == depName) { depFound = true; break; } } if (!depFound) { depsSatisfied = false; qWarning() << fileInfo.fileName() << "Dependency plugin" << depName << "not found"; break; } } if (!depsSatisfied) { plugin->setEnabled(false); // Disable if dependencies are not satisfied } else { plugin->setEnabled(true); plugin->start(); // Start plugin } m_plugins.append(plugin); m_loaders.insert(fileInfo.fileName(), loader); }} // New: Enable/Disable Plugin API bool PluginManager::enablePlugin(const QString &pluginName, bool enable) { for (IPlugin *plugin : m_plugins) { if (plugin->pluginName() == pluginName) { plugin->setEnabled(enable); if (enable) { plugin->start(); // Start when enabled } else { plugin->stop(); // Stop when disabled } return true; } } return false; }

Database Management Enhancements

Design Objective: Implement ORM mapping (devices, data records, user configurations), transaction support, multi-database connection pool, and automatic backup, improving data layer reliability and development efficiency.

Technical Solution

1. ORM Encapsulation: Based on <span>QSqlTableModel</span> or custom mapping, provide CRUD interfaces for entities like devices and data.

2. Transaction Support: <span>DatabaseManager</span> encapsulates <span>beginTransaction()</span>, <span>commit()</span>, and <span>rollback()</span> methods.

3. Connection Pool: Manage multiple SQLite connections to avoid performance bottlenecks under high concurrency.

4. Automatic Backup: Periodically (e.g., every hour) copy the database file to a backup directory.

Code Example

// database_manager.h (enhanced version) #ifndef DATABASE_MANAGER_H #define DATABASE_MANAGER_H #include <QObject> #include <QSqlDatabase> #include <QQueue> #include <QTimer> #include "device_orm.h" // Device ORM class class DatabaseManager : public QObject { Q_OBJECT public: explicit DatabaseManager(QObject *parent = nullptr); ~DatabaseManager(); // Get database connection (connection pool) QSqlDatabase getConnection(); void releaseConnection(QSqlDatabase &connection); // ORM operations: device related bool addDevice(const Device &device); // Add device bool updateDevice(const Device &device); // Update device QList<Device> getDevices(); // Get all devices // Transaction support void beginTransaction(); void commitTransaction(); void rollbackTransaction(); // Automatic backup void enableAutoBackup(int intervalMinutes = 60); // Enable automatic backup, interval in minutes private: QSqlDatabase m_mainDb; // Main database connection (default) QQueue<QSqlDatabase> m_connectionPool; // Connection pool QTimer *m_backupTimer; // Backup timer QString m_dbPath; // Database file path void initDatabase(); // Initialize database (create tables) void backupDatabase(); // Execute backup }; #endif // DATABASE_MANAGER_H

// device_orm.h (Device ORM example) #ifndef DEVICE_ORM_H #define DEVICE_ORM_H #include <QSqlTableModel> #include "device.h" class DeviceOrm : public QSqlTableModel { Q_OBJECT public: explicit DeviceOrm(QObject *parent = nullptr, QSqlDatabase db = QSqlDatabase()); QVariant data(const QModelIndex &index, int role) const override; bool setData(const QModelIndex &index, const QVariant &value, int role) override; QHash<int, QByteArray> roleNames() const override; // Business method: Add device bool insertDevice(const Device &device); // Business method: Query device by ID Device deviceById(const QString &deviceId); }; #endif // DEVICE_ORM_H

Device Communication Management

Design Objective: Standardize communication protocols (Modbus, MQTT, Serial), connection pool, status monitoring, and reconnection, simplifying the development and maintenance of the device interaction layer.

Technical Solution

1. Communication Interface Abstraction: Define <span>ICommunicationInterface</span> base interface, encapsulating common operations like “open/close/read/write”.

2. Protocol Implementation: Implement <span>ModbusCommunication</span>, <span>MqttCommunication</span>, and <span>SerialCommunication</span> classes for Modbus, MQTT, and Serial respectively.

3. Communication Manager: <span>CommunicationManager</span> manages all communication instances, providing functions like “get instance, status listener”.

Code Example

// communication_interface.h (Communication interface) #ifndef ICOMMUNICATIONINTERFACE_H #define ICOMMUNICATIONINTERFACE_H #include <QObject> #include <QByteArray> class ICommunicationInterface : public QObject { Q_OBJECT public: virtual ~ICommunicationInterface() = default; virtual bool open() = 0; // Open connection virtual void close() = 0; // Close connection virtual bool write(const QByteArray &data) = 0; // Write data virtual QByteArray read() = 0; // Read data virtual bool isConnected() const = 0; // Is connected signals: void connected(); // Connection successful void disconnected(); // Connection closed void errorOccurred(const QString &error); // Error occurred }; Q_DECLARE_INTERFACE(ICommunicationInterface, "com.example.ICommunicationInterface/1.0") #endif // ICOMMUNICATIONINTERFACE_H

// communication_manager.h (Communication manager) #ifndef COMMUNICATION_MANAGER_H #define COMMUNICATION_MANAGER_H #include <QObject> #include <QMap> #include <QSharedPointer> #include "communication_interface.h" class CommunicationManager : public QObject { Q_OBJECT public: explicit CommunicationManager(QObject *parent = nullptr); ~CommunicationManager(); // Get communication instance (by protocol + parameters, e.g., [email protected]:502) QSharedPointer<ICommunicationInterface> getCommunication( const QString &protocol, const QString &params); // Status listener: connection status of all communication instances void registerStatusListener(QObject *listener, const char *signal); private: QMap<QString, QSharedPointer<ICommunicationInterface>> m_communications; // Protocol + parameters -> instance }; #endif // COMMUNICATION_MANAGER_H

Configuration Management

Design Objective: Centrally manage system configurations (theme, language), device configurations (communication parameters, acquisition frequency), user configurations (permissions, preferences), supporting persistence and real-time effectiveness.

Technical Solution

1. Configuration Layering: Split by module (<span>SystemConfig</span>, <span>DeviceConfig</span>, <span>UserConfig</span>), using structs or classes to encapsulate configuration items.

2. Persistent Storage: Implement configuration read/write based on <span>QSettings</span>, supporting formats like INI, JSON, etc.

3. Real-time Effectiveness: Send signals on configuration changes to notify related modules (e.g., UI, communication layer) to update.

Code Example

// config_manager.h #ifndef CONFIG_MANAGER_H #define CONFIG_MANAGER_H #include <QObject> #include <QSettings> #include <QMap> struct SystemConfig { QString theme; // Theme (light/dark) QString language; // Language (zh_CN/en_US) }; struct DeviceConfig { QString deviceId; QString communicationType; // modbus/mqtt/serial QString params; // Protocol parameters (e.g., Modbus IP + port) }; class ConfigManager : public QObject { Q_OBJECT public: explicit ConfigManager(QObject *parent = nullptr); ~ConfigManager(); // System configuration SystemConfig systemConfig() const; void setSystemConfig(const SystemConfig &config); // Device configuration DeviceConfig deviceConfig(const QString &deviceId) const; void setDeviceConfig(const QString &deviceId, const DeviceConfig &config); // User configuration (example: user permissions) QMap<QString, QString> userPermissions(const QString &userId) const; void setUserPermissions(const QString &userId, const QMap<QString, QString> &permissions); signals: void systemConfigChanged(); // System configuration change signal void deviceConfigChanged(); // Device configuration change signal void userConfigChanged(); // User configuration change signal private: QSettings m_settings; // Persistent storage const QString m_orgName = "YourCompany"; const QString m_appName = "DeviceManagementSystem"; }; #endif // CONFIG_MANAGER_H

// config_manager.cpp #include "config_manager.h" ConfigManager::ConfigManager(QObject *parent) : QObject(parent), m_settings(m_orgName, m_appName) {} SystemConfig ConfigManager::systemConfig() const { SystemConfig config; config.theme = m_settings.value("System/theme", "light").toString(); config.language = m_settings.value("System/language", "zh_CN").toString(); return config; } void ConfigManager::setSystemConfig(const SystemConfig &config) { m_settings.setValue("System/theme", config.theme); m_settings.setValue("System/language", config.language); emit systemConfigChanged(); // Send change signal } // Reading and writing device configuration, user configuration is similar...

Logging System

Design Objective: Implement hierarchical logging (Debug/Info/Warning/Error), multiple output targets (file + database), real-time viewing, and filtering, assisting in problem troubleshooting and system monitoring.

Technical Solution

1. Log Level Definition: Define <span>LogLevel</span> enum (Debug/Info/Warning/Error).

2. Log Output: <span>Logger</span> class encapsulates log writing (to file, database), supporting asynchronous writing to avoid blocking the UI.

3. Log Model: <span>LogModel</span> inherits <span>QAbstractListModel</span>, providing log data display and filtering for the UI.

Code Example

// logger.h #ifndef LOGGER_H #define LOGGER_H #include <QObject> #include <QFile> #include <QTextStream> #include <QDateTime> #include <QQueue> #include <QThread> #include "log_model.h" enum class LogLevel { Debug, Info, Warning, Error }; class Logger : public QObject { Q_OBJECT public: explicit Logger(QObject *parent = nullptr); ~Logger(); // Record log void log(LogLevel level, const QString &message, const QString &module = ""); // Set output target (file, database) void setLogFile(const QString &filePath); void setLogDatabase(QSqlDatabase db); signals: void newLog(const QDateTime &time, LogLevel level, const QString &module, const QString &message); private: QFile m_logFile; QTextStream m_fileStream; QSqlDatabase m_logDb; QQueue<QString> m_logQueue; // Asynchronous writing queue QThread m_workerThread; // Worker thread (to avoid blocking UI) LogModel *m_logModel; // Log model void processLogQueue(); // Process log queue (worker thread execution) }; #endif // LOGGER_H

// logger.cpp (key logic) Logger::Logger(QObject *parent) : QObject(parent) { m_logModel = new LogModel(this); connect(this, &Logger::newLog, m_logModel, &LogModel::addLog); // Start worker thread to process log queue moveToThread(&m_workerThread); connect(&m_workerThread, &QThread::started, this, &Logger::processLogQueue); m_workerThread.start(); } void Logger::log(LogLevel level, const QString &message, const QString &module) { QString levelStr; switch (level) { case LogLevel::Debug: levelStr = "DEBUG"; break; case LogLevel::Info: levelStr = "INFO"; break; case LogLevel::Warning: levelStr = "WARNING"; break; case LogLevel::Error: levelStr = "ERROR"; break; } QString logEntry = QString("[%1] [%2] [%3] %4") .arg(QDateTime::currentDateTime().toString("yyyy-MM-dd hh:mm:ss.zzz")) .arg(levelStr) .arg(module) .arg(message); // Write to queue (asynchronous processing) QMetaObject::invokeMethod(this, "enqueueLog", Qt::QueuedConnection, Q_ARG(QString, logEntry)); } void Logger::processLogQueue() { while (true) { QString logEntry = m_logQueue.dequeue(); // Write to file if (m_logFile.isOpen()) { m_fileStream << logEntry << endl; m_fileStream.flush(); } // Write to database if (m_logDb.isOpen()) { QSqlQuery query(m_logDb); query.prepare("INSERT INTO logs (time, level, module, message) " "VALUES (:time, :level, :module, :message)"); query.bindValue(":time", QDateTime::currentDateTime()); query.bindValue(":level", logEntry.section(" ", 0, 0).mid(1, 7)); // Extract DEBUG from [DEBUG] query.bindValue(":module", logEntry.section("] [", 1, 1).section("] ", 0, 0)); query.bindValue(":message", logEntry.mid(logEntry.indexOf("] ] ") + 4)); query.exec(); } // Emit signal to UI model emit newLog(/* Parse time, level, module, message */); } }

Enhancements to Main Window Status Management

Design Objective: Implement window layout persistence (sidebar collapse, window size/position), session recovery (last opened page, device connection status), multi-window mode, enhancing user experience and operational efficiency.

Technical Solution

1. Status Serialization: <span>WindowState</span> class encapsulates window state (sidebar width, collapse state, window geometry information).

2. Session Management: <span>SessionManager</span> encapsulates session data like “opened pages, device connection status”, using <span>QSettings</span> for persistence.

3. Multi-window Support: <span>MainWindow</span> supports “new window” functionality, sharing core data (like plugins, databases) but with independent UI.

Code Example

// window_state.h #ifndef WINDOW_STATE_H #define WINDOW_STATE_H #include <QByteArray> #include <QRect> class WindowState { public: QByteArray sideBarState; // Sidebar collapse state (QByteArray, saved by QSplitter) int sideBarWidth = 200; // Sidebar width bool sideBarCollapsed = false; // Is sidebar collapsed QRect windowGeometry; // Window geometry (position + size) Qt::WindowStates windowState = Qt::WindowNoState; // Window state (maximized/minimized, etc.) // Serialize to QVariantMap (for QSettings storage) QVariantMap toVariantMap() const; // Deserialize from QVariantMap void fromVariantMap(const QVariantMap &map); }; #endif // WINDOW_STATE_H

// mainwindow.cpp (integrate state management) MainWindow::MainWindow(QWidget *parent) : QMainWindow(parent) { // ... Other initializations ... // Load last saved state loadWindowState(); // Connect window close event to save state connect(this, &MainWindow::aboutToClose, this, &MainWindow::saveWindowState); } void MainWindow::loadWindowState() { QSettings settings; QVariantMap stateMap = settings.value("MainWindow/state").toMap(); WindowState state; state.fromVariantMap(stateMap); // Restore sidebar m_sideBar->restoreState(state.sideBarState); m_sideBar->setCollapsed(state.sideBarCollapsed); setSideBarWidth(state.sideBarWidth); // Restore window setGeometry(state.windowGeometry); setWindowState(state.windowState); } void MainWindow::saveWindowState() { WindowState state; state.sideBarState = m_sideBar->saveState(); state.sideBarWidth = m_sideBar->width(); state.sideBarCollapsed = m_sideBar->isCollapsed(); state.windowGeometry = geometry(); state.windowState = windowState(); QSettings settings; settings.setValue("MainWindow/state", state.toVariantMap()); } // Session recovery (example: restore last opened device page) void MainWindow::restoreSession() { SessionManager &session = SessionManager::instance(); QList<QString> openedPages = session.openedPages(); for (const QString &page : openedPages) { if (page == "device_detail") { // Restore device detail page and pass device ID QString deviceId = session.deviceIdForPage(page); openDeviceDetailPage(deviceId); } } }

With these enhancements, the system will exhibit greater maturity as an enterprise-level product in terms of plugin governance, data reliability, device interaction, and user experience.
