Open Source IoT Management System! Includes User Authorization System, Location Monitoring, Distance Calculation, and Service Health Monitoring

IoT management system based on Gin/Fiber and Vue3Source code

https://www.gitpp.com/laoxiangjun/project0922-iot-manage-system

Includes user authorization system, location monitoring, distance calculation, and service health monitoring

Detailed Functionality and Implementation Plan of the IoT Management System Based on Gin/Fiber and Vue3

1. Core Functional Architecture

The system adopts a front-end and back-end separation architecture, with the back-end based on the Go language’s Gin/Fiber framework (high-performance web framework), and the front-end built using Vue3 (reactive framework). The database is PostgreSQL (supports complex queries and JSON fields), with Redis as the caching layer. The functional modules include: User Authorization System, Location Monitoring, Distance Calculation, Service Health Monitoring.

2. Detailed Function Implementation

1. User Authorization System

Objective: To achieve fine-grained access control based on the RBAC model, supporting dynamic routing and menu generation.Technical Implementation:

Back-end:

Use the Casbin library (permission management middleware) to define policy models, supporting flexible binding of roles and permissions.
Intercept requests through Gin middleware to verify user permissions (e.g., /system/user/list requires system:user:list permission).

Interface example:

// Role management interface
func listRole(c *gin.Context) {
    roles, err := roleService.GetRoleList() // Query role list
    if err != nil {
        response.Fail(c, "Query failed")
        return
    }
    response.Success(c, roles)
}

Front-end:

Dynamic route generation: Filter unauthorized routes based on the permission information returned from the back-end.
Button-level permission control: Hide unauthorized buttons using the v-auth directive (e.g., v-auth="'system:user:add'").

Code example:

// src/router/index.js
const routes = [
    {
        path: '/user',
        component: () => import('@/views/user/list.vue'),
        meta: { title: 'User List', auth: ['system:user:list'] } // Route identifier
    }
]

2. Location Monitoring

Objective: To track device locations in real-time, supporting historical trajectory playback and geofencing alerts.Technical Implementation:

Data Collection:

The device reports location data (longitude, latitude, timestamp) to the back-end at regular intervals via the MQTT protocol.
The back-end uses WebSocket to push location updates to the front-end, achieving real-time map rendering.

Front-end Display:

Integrate Leaflet/OpenLayers mapping libraries to mark device locations and draw trajectories.
Historical trajectory query: Filter location records in the database by time range to generate dynamic trajectory animations.

Database Design:

CREATE TABLE device_location (
    id SERIAL PRIMARY KEY,
    device_id VARCHAR(50) NOT NULL,
    longitude DECIMAL(10, 6) NOT NULL,
    latitude DECIMAL(10, 6) NOT NULL,
    timestamp TIMESTAMP DEFAULT CURRENT_TIMESTAMP);

3. Distance Calculation

Objective: To calculate the straight-line distance or path distance between two devices based on their location data.Technical Implementation:

Algorithm Selection:

Haversine Formula: Calculates the great-circle distance between two points on a sphere (suitable for short distances, error < 0.5%).
OSRM/GraphHopper: Calls open-source routing services to calculate actual path distances (requires service deployment or API usage).

Back-end Interface:

// Calculate distance between two devices
func calculateDistance(c *gin.Context) {
    deviceA, deviceB := c.Param("deviceA"), c.Param("deviceB")
    locA, locB := locationService.GetLatestLocation(deviceA), locationService.GetLatestLocation(deviceB)
    distance := haversine(locA.Longitude, locA.Latitude, locB.Longitude, locB.Latitude)
    response.Success(c, map[string]interface{}{"distance": distance})
}

4. Service Health Monitoring

Objective: To monitor the status of system services (e.g., database, MQTT broker, microservices) and automatically alert in case of anomalies.Technical Implementation:

Monitoring Metric Collection:

Use Prometheus to collect service metrics (e.g., HTTP request latency, memory usage).
Custom Exporter to monitor business metrics (e.g., number of online devices, message queue backlog).

Alert Rules:

Configure threshold alerts through Alertmanager (e.g., CPU usage > 90% for 5 minutes).
Integrate with WeChat/DingTalk bots to send alert notifications.

Front-end Dashboard:

Service Status: Green light (healthy) / Red light (anomalous).
Response Time: 95th percentile < 500ms.

Integrate Grafana to display real-time monitoring data, supporting custom dashboards.
Example dashboard:

3. System Advantages and Scalability

High Performance:

The Gin/Fiber framework handles high concurrent requests (QPS > 10K), and Redis caches hot data (e.g., device status).

Easy to Expand:

Modular design supports adding new features (e.g., adding an “energy consumption monitoring” module only requires developing an independent service and connecting to the API).

Security and Compliance:

Data transmission encryption (HTTPS/WSS), sensitive operations recorded in audit logs.

4. Application Scenarios

Smart Logistics: Real-time tracking of truck locations, calculating transport distances and times.
Industrial IoT: Monitoring equipment health status, preventive maintenance to reduce downtime.
Smart Cities: Managing the operational status of public facilities (e.g., streetlights, trash bins).
