Linux Security | Measuring Traffic with iptablesThe Role of iptables and the Difference from firewalld

1. What is iptables? What is it used for?

iptables is a classic firewall tool on Linux systems, operating at the network layer, with main functions including:

  • Packet Filtering

    Allowing or blocking specific network traffic based on rules (such as IP addresses, ports, protocols, etc.)

  • Traffic Forwarding

    Controlling the forwarding of packets between different network interfaces

  • Network Address Translation (NAT)

    Implementing functions such as port mapping and IP address translation

  • Traffic Monitoring and Statistics

    Recording the number of packets and bytes passing through the firewall, which is very useful in network debugging, penetration testing, etc.

Why use iptables instead of firewalld?

firewalld is a newer firewall management tool in RedHat-based Linux, essentially a front-end wrapper for iptables, providing a more user-friendly interface and dynamic update mechanism. However, in the following scenarios, iptables has advantages:

  • Granular Traffic Statistics

    iptables can directly log traffic data for specific IP/port through rule chains, making operations simple and direct

  • Scripting Automation

    iptables commands are more suitable for scripting, enabling automated configuration of complex firewall policies

  • Compatibility

    All Linux distributions support iptables, while firewalld is mainly used in RedHat systems

  • Learning Curve

    For simple filtering and monitoring needs, using iptables commands directly is more intuitive than learning the zone concept of firewalld

For more information, see:

  • Linux Security | Detailed Explanation of the Firewall Tool iptables

  • [Red Hat Linux]RHEL 8 and 9 Security Hardening Guide

Teaching you[ How to Use iptables to Measure Traffic ]]

Experimental StepsFirst, check the current status of iptables using the -L option:

[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain FORWARD (policy ACCEPT)
target prot opt source destination
Chain OUTPUT (policy ACCEPT)
target prot opt source destination

We can see the three rule chains currently in the system. Assuming there are already some rules in the system, to avoid disrupting the existing rules, we need to create a dedicated rule chain for measuring traffic, which we will call “traffic”.

Use the command iptables -N to create a new rule chain.

[root@localhost ~]# iptables -N traffic
[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target      prot opt source       destination
Chain FORWARD (policy ACCEPT)
target      prot opt source       destination
Chain OUTPUT (policy ACCEPT)
target      prot opt source       destination
Chain traffic (0 references)
target       prot opt source      destination

Next, add two rules to the traffic chain to measure the traffic between this machine and the server at 192.168.88.100;

[root@localhost ~]# iptables -A traffic -s 192.168.88.100
[root@localhost ~]# iptables -A traffic -d 192.168.88.100
[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target     prot opt source      destination
Chain FORWARD (policy ACCEPT)
target     prot opt source      destination
Chain OUTPUT (policy ACCEPT)
target     prot opt source      destination
Chain traffic (0 references)
target      prot opt source      destination
           all -- 192.168.88.100 anywhere
           all -- anywhere 192.168.88.100
[root@localhost ~]#

Next, we need to attach the traffic chain to the original “INPUT” and “OUTPUT” rule chains in the system so that we can monitor the traffic.

[root@localhost ~]# iptables -A INPUT -j traffic
[root@localhost ~]# iptables -A OUTPUT -j traffic
[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target      prot opt source       destination
traffic     all -- anywhere       anywhere
Chain FORWARD (policy ACCEPT)
target      prot opt source       destination
Chain OUTPUT (policy ACCEPT)
target      prot opt source       destination
traffic     all -- anywhere       anywhere
Chain traffic (2 references)
target      prot opt source      destination
            all -- 192.168.88.100 anywhere
            all -- anywhere 192.168.88.100
[root@localhost ~]#

Use iptables -Z to reset the traffic statistics, everything is ready, and we can trigger traffic for observation.

[root@localhost ~]# iptables -Z

Use the iptables -L rule chain -nvx command to see how many packets and bytes have been transmitted to and from the target server; it is recommended to use the watch command for continuous monitoring.

[root@localhost ~]# watch -d -n1 iptables -L traffic -nvx
Every 1.0s: iptables -L traffic -nvx                                               Wed May 11 14:01:57 2022
Chain traffic (2 references)
    pkts     bytes target    prot opt in     out     source            destination
      17     708             all -- *        *       192.168.88.100    0.0.0.0/0
     364     15940           all -- *        *       0.0.0.0/0         192.168.88.100

As you can see, iptables will record how many packets you have sent out and the size of the traffic; it can also record the traffic sent to you by the other party.

After monitoring, restore iptables

1. First, clear the “traffic” rule from the original “INPUT” and “OUTPUT” rule chains; but first check the rule’s number in the chain (which is the line number).

The command format for deleting a rule is: iptables -D INPUT rule_number

[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target      prot opt source              destination
traffic     all -- anywhere              anywhere # <-- This is the first rule, in line 1, so the number is 1
Chain FORWARD (policy ACCEPT)
target      prot opt source              destination
Chain OUTPUT (policy ACCEPT)
target      prot opt source              destination
traffic     all -- anywhere              anywhere # <-- The first rule under this chain, number 1
Chain traffic (2 references)
target      prot opt source      destination
            all -- 192.168.88.100        anywhere
            all -- anywhere              192.168.88.100

Delete the “traffic” rule from INPUT and OUTPUT.

[root@localhost ~]# iptables -D INPUT 1
[root@localhost ~]# iptables -D OUTPUT 1
# Verify again, and find that the rules under the chain have been deleted.
[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target      prot opt source         destination
Chain FORWARD (policy ACCEPT)
target      prot opt source         destination
Chain OUTPUT (policy ACCEPT)
target      prot opt source         destination
Chain traffic (0 references)
target      prot opt source         destination
            all -- 192.168.88.100 anywhere
            all -- anywhere 192.168.88.100

2. Clean up the rules inside the traffic chain using the iptables -F option.

[root@localhost ~]# iptables -F traffic
[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target        prot opt source         destination
Chain FORWARD (policy ACCEPT)
target        prot opt source         destination
Chain OUTPUT (policy ACCEPT)
target        prot opt source         destination
Chain traffic (0 references)
target        prot opt source         destination
[root@localhost ~]#

3. Delete the traffic chain, leaving only the original three rule chains in the system.

[root@localhost ~]# iptables -X traffic
[root@localhost ~]# iptables -L
Chain INPUT (policy ACCEPT)
target         prot opt source       destination
Chain FORWARD (policy ACCEPT)
target         prot opt source       destination
Chain OUTPUT (policy ACCEPT)
target         prot opt source       destination
[root@localhost ~]#
