As the level of information technology in modern enterprises continues to rise, the complexity of network architecture is also increasing. To effectively manage and optimize network resources while enhancing network security and flexibility, VLAN (Virtual Local Area Network) technology has emerged. As a widely used network technology in environments such as enterprises and data centers, VLAN plays a crucial role in achieving network isolation and improving management efficiency.
What is VLAN?
VLAN (Virtual Local Area Network), as the name suggests, is a technology that divides a physical network into multiple logical sub-networks through software techniques. The purpose of VLAN is to group devices in a physical network according to logical needs and provide more efficient and secure communication between these devices.
Unlike traditional Local Area Networks (LAN), the device division in VLAN no longer relies on physical location but instead uses network devices (such as switches) to tag and forward data packets at the data link layer (Layer 2). In other words, VLAN is “virtual” because it does not require any physical isolation; it only requires network devices to support VLAN functionality.
📌 For more information on the OSI seven-layer model structure, please refer to the “Blueprint of Network Communication”—a deep understanding of the OSI seven-layer model and the TCP/IP four-layer model.
| Layer | Name (Chinese) | Name (English) | Main Function Summary |
| Layer 7 | 应用层 | Application Layer | User-oriented, providing network services (such as HTTP, FTP, SMTP, etc.) |
| Layer 6 | 表示层 | Presentation Layer | Data format conversion, encryption/decryption, compression |
| Layer 5 | 会话层 | Session Layer | Establishing, managing, and terminating session connections |
| Layer 4 | 传输层 | Transport Layer | Providing end-to-end reliable transmission (such as TCP, UDP) |
| Layer 3 | 网络层 | Network Layer | Responsible for path selection and logical addressing (such as IP) |
| Layer 2 | 数据链路层 | Data Link Layer | Responsible for physical address recognition and error detection (such as MAC, ARP) |
| Layer 1 | 物理层 | Physical Layer | Defining physical transmission media and interface standards (such as cables, optical fibers) |
How VLAN Works
The core of VLAN lies in the operation of switches. Switches tag data packets based on the VLAN Tag, which determines which VLAN the data packet belongs to. The workflow of VLAN is as follows:
- 1. VLAN Tagging: When a switch receives a data packet, it adds a VLAN tag to the packet based on the source port or configured rules, identifying its belonging to a specific virtual local area network.
- 2. Packet Forwarding: The switch determines the forwarding path of the data packet based on the VLAN tag. Only devices within the same VLAN can receive the data packet, while devices in other VLANs are unaffected.
- 3. VLAN Isolation: VLAN isolates communication between different VLANs, preventing the spread of broadcast storms, thus enhancing network efficiency and security. If communication between different VLANs is required, it must be routed through a router or a Layer 3 switch to forward data.
Common types of VLAN ports are generally divided into three categories:
- • Access Port: Connects to end devices (such as computers, printers), adding/removing VLAN tags as data frames enter/exit.
- • Trunk Port: Used for interconnecting switches, allowing data from multiple VLANs to pass through, identified by the 802.1Q protocol.
- • Hybrid Port: Supports both tagged and untagged data frames, commonly used to connect devices like APs and IP phones that have different tagging compatibility requirements.
Main Advantages of VLAN
As an important technology for network management, VLAN offers numerous advantages. Its benefits are not only reflected in optimizing network architecture but also in enhancing security and simplifying management.
1. Improved Network Security
By isolating network traffic through VLAN, unnecessary communication between different departments and projects is reduced, allowing sensitive information to be contained within specific VLANs, thus preventing data leakage. For example, the finance department and the R&D department can be placed in different VLANs, ensuring effective isolation of data and traffic even when connected to the same switch.
2. Simplified Network Management
Without VLAN, network administrators must manage a large, mixed physical network, making it difficult to categorize devices and users orderly. VLAN allows logical division based on different departments, functions, or application scenarios, making network management simpler and clearer. For instance, technical support, sales, and marketing departments can be assigned to different VLANs for easier management and maintenance.
3. Reduced Network Broadcasts
Broadcast messages in a network can burden the network, especially in large LANs, where broadcast messages can spread throughout the network. VLAN reduces unnecessary network traffic by dividing the network into smaller sub-networks, allowing broadcast messages to be transmitted only within the same VLAN, thus enhancing overall network performance.
📌 A broadcast domain is an important concept in computer networks, defining the range of all devices that can receive a broadcast data packet. In other words, all hosts within the same broadcast domain can receive broadcast messages sent by a device. VLANs and inter-segment routing (routers, subnets) can isolate broadcast domains.
Imagine you shout in the office, “Who wants milk tea?” The people who hear you form a “broadcast domain.” If the adjacent office cannot hear you, they are not in this broadcast domain.
4. Enhanced Network Performance
VLAN reduces unnecessary network traffic by separating broadcast domains, allowing each VLAN’s bandwidth to be utilized more efficiently. Additionally, VLAN can help manage network load, preventing any part of the network from becoming overloaded, ensuring the stability and smoothness of the entire network.
Common Applications of VLAN
VLAN technology is widely used in modern enterprises and data centers. Here are some typical application scenarios:
1. Enterprise Network Segmentation
In large enterprises, VLAN technology can group devices based on different departments, projects, or user groups. For example, sales, R&D, and finance departments can be segmented into different VLANs, ensuring that their traffic does not interfere with each other while ensuring data security.
2. Virtualization Management in Data Centers
Data centers typically contain a large number of servers and network devices. VLAN can logically divide different virtual networks, allowing for more efficient utilization of network resources. For instance, in a virtualized environment, different VLANs can be assigned based on different virtual machines to achieve resource isolation and optimization.
3. Network Segmentation in Institutions like Schools and Hospitals
Institutions like schools and hospitals often need to isolate networks for different departments and functions. VLAN can ensure reasonable management and control of network traffic through flexible segmentation methods. For example, schools can separate teaching areas, administrative areas, and student dormitories into different VLANs to avoid traffic conflicts and enhance network efficiency.
4. Security Management of Public Wireless Networks
For public places such as shopping malls and airports, VLAN can achieve network isolation between visitors and staff, ensuring the security of the internal network and improving the management efficiency of the wireless network.
Types of VLAN
VLAN can be categorized in various ways, with several common types including:
- 1. Port-based VLAN: Divides VLANs based on the physical ports of switches, with each port corresponding to a specific VLAN.
- 2. MAC-based VLAN: Divides VLANs based on the MAC addresses of devices, suitable for scenarios where devices frequently move.
- 3. Protocol-based VLAN: Divides VLANs based on network protocols, for example, separating devices using IP and IPX protocols into different VLANs.
- 4. IP Subnet-based VLAN: Divides VLANs based on IP address subnets, suitable for networks with clear IP address structures.
Relationship Between VLAN and Other Network Technologies
VLAN is often used in conjunction with the following technologies to achieve better network performance:
- • STP (Spanning Tree Protocol): Prevents switch loop issues, ensuring stable connections between VLANs.
- • 802.1Q Protocol: A standardized VLAN tagging protocol used to add VLAN tags to Ethernet frames for VLAN identification and forwarding.
- • Routers and Layer 3 Switches: Communication between different VLANs requires forwarding through routers or Layer 3 switches.
Considerations for Configuring VLAN
- • Planning First
- • Design VLAN IDs and subnet IP ranges based on business needs to avoid confusion later.
- • It is recommended to retain VLAN 1 (default management VLAN) and set a strong password.
- • Trunk Port Security
- • Limit the VLAN list allowed through trunk ports to prevent unauthorized VLAN penetration.
- • Consistency Across Devices
- • Ensure consistent VLAN ID definitions across multiple switches; otherwise, communication failures may occur.
- • Combine with Layer 3 Switching
- • If inter-VLAN communication is needed, configure gateways and ACL policies through Layer 3 switches or routers.
The Future of VLAN
As a fundamental and critical network technology, VLAN continues to play an important role in current and future network environments. Although it was developed over 30 years ago, it has not become obsolete; rather, it is continuously evolving and integrating, especially in areas such as cloud computing, virtualization, software-defined networking (SDN), and security isolation.
📌 Challenges and Improvement Directions for VLAN
| Limitations of Traditional VLAN | Future Improvement Directions |
| Limited number of VLANs (up to 4096) | Evolution towards technologies like VXLAN (supporting 16 million network isolations) |
| Static configuration, cumbersome manual operations | Combining with SDN for automated orchestration and policy deployment |
| Difficulties in extending across Layer 3 networks | Using tunneling encapsulation (e.g., VXLAN over IP) for cross-DC deployment |
| Does not support dynamic identity association | Integration with NAC/AAA/AD for dynamic user network access control |
VLAN will not disappear but will evolve. It will transform from a “physical isolation tool” into an “intelligent network management unit,” integrating into more advanced network architectures, collaborating with technologies like VXLAN, SDN, and zero trust, and continuing to play a foundational yet important role in enterprise networks, cloud computing, and the Internet of Things.
