In embedded GUI development, issues such as screen flickering during refresh, excessive memory usage leading to system crashes, stuttering animations, and significant performance drops during multi-screen displays are common challenges.
As a leading lightweight embedded graphics library, LVGL’s buffer management directly determines the smoothness of applications and resource consumption. Today, we will share how to optimize display performance.
1. Three Core Rendering Modes of LVGL Buffers
LVGL manages display devices through the <span><span>lv_display_t</span></span> object, with three rendering modes corresponding to different hardware scenarios. Choosing the right one is half the battle!
| Rendering Mode | Number of Buffers | Memory Usage | Performance | Applicable Scenarios |
|---|---|---|---|---|
| Partial Rendering (PARTIAL) | 1 | Low (only 10% of the screen) | Medium | Memory-constrained devices (e.g., low-end MCUs) |
| Direct Rendering (DIRECT) | 2 | Medium (2 times screen size) | Good | General applications (require no flickering) |
| Full Screen Rendering (FULL) | 2-3 | High (2-3 times screen size) | Excellent | Complex animations, high-performance requirements |
Key Configuration Examples
- Partial Rendering (Memory Optimal):
-
#define BYTES_PER_PIXEL 2 // RGB565 format static uint8_t partial_buf[320 * 240 / 10 * BYTES_PER_PIXEL]; lv_display_set_buffers(disp, partial_buf, NULL, sizeof(partial_buf), LV_DISPLAY_RENDER_MODE_PARTIAL); - Double Buffering (Preferred for No Flickering):
static uint8_t buf1[320 * 240 * BYTES_PER_PIXEL]; static uint8_t buf2[320 * 240 * BYTES_PER_PIXEL]; lv_display_set_buffers(disp, buf1, buf2, sizeof(buf1), LV_DISPLAY_RENDER_MODE_DIRECT);
2. Resource-Efficient High Performance
1. Choosing the Right Color Format Saves Memory
The memory usage varies significantly with different color formats; in embedded scenarios, RGB565 is the preferred choice!
| Color Format | Bytes per Pixel | Memory Usage for 320×240 Screen | Visual Quality |
|---|---|---|---|
| RGB565 | 2B | 150KB | Clear enough (recommended) |
| RGB888 | 3B | 225KB | More accurate colors |
| ARGB8888 | 4B | 300KB | Includes alpha channel (memory-intensive) |
2. Buffer Size Calculation Formula
uint32_t calculate_buffer_size(int32_t width, int32_t height,
lv_color_format_t color_format,
lv_display_render_mode_t mode) {
uint32_t pixel_size = lv_color_format_get_size(color_format);
uint32_t base_size = width * height * pixel_size;
switch(mode) {
case PARTIAL: return base_size / 10; // 1/10 screen size
case DIRECT/FULL: return base_size; // Full screen size
default: return 0;
}
}3. Dynamic Memory Allocation
// Dynamic allocation for double buffering
void init_display_buffers(lv_display_t *disp) {
uint32_t buf_size = width * height * pixel_size;
void *buf1 = lv_mem_alloc(buf_size); // LVGL dedicated allocator (ensures alignment)
void *buf2 = lv_mem_alloc(buf_size);
if(buf1 && buf2) {
lv_display_set_buffers(disp, buf1, buf2, buf_size, DIRECT);
}
}3. Hardware Acceleration + Callback Optimization
1. DMA Transfer Instead of Software Copy
Traditional software pixel-by-pixel writing is inefficient; using DMA for bulk transfers directly frees up the CPU:
void optimized_flush_cb(lv_display_t *disp, const lv_area_t *area, uint8_t *px_map) {
my_display_data_t *dev_data = lv_display_get_driver_data(disp);
if(dev_data->dma_available) {
// DMA bulk transfer of pixel data
start_dma_transfer(dev_data->dma_channel, px_map, area, dev_data->display_address);
} else {
// Software transfer fallback
......
}
}2. Multi-Screen Display Optimization Strategies
- Independent Buffers: Use double buffering for the main screen (high performance) and partial rendering for the secondary screen (memory-saving)
-
// Main screen (800x480 double buffering) static uint8_t main_buf1[800*480*2]; static uint8_t main_buf2[800*480*2]; lv_display_set_buffers(main_disp, main_buf1, main_buf2, sizeof(main_buf1), DIRECT); // Secondary screen (240x240 partial rendering) static uint8_t sec_buf[240*240/10*2]; lv_display_set_buffers(secondary_disp, sec_buf, NULL, sizeof(sec_buf), PARTIAL); - Memory Sharing: When resources are tight, shared memory can be split (caution required to avoid conflicts)
4. Case Study: UI Optimization for Smartwatch
Scenario Conditions
-
Screen: 240×240 RGB565 (16-bit color)
-
Memory: Only 256KB RAM
-
Requirements: Smooth animations + low power consumption
Optimization Plan
void setup_smartwatch_display() {
lv_display_t *disp = lv_display_create(240, 240);
#define BUF_ROWS 60 // Buffer occupies only 1/4 of the screen (240/4)
static uint8_t buf1[240 * BUF_ROWS * 2];
static uint8_t buf2[240 * BUF_ROWS * 2];
// Partial rendering mode + double buffering (balance performance and memory)
lv_display_set_buffers(disp, buf1, buf2, sizeof(buf1), PARTIAL);
lv_display_set_refr_period(disp, 33); // 30Hz refresh rate (low power)
}Memory Usage Details (Perfect Control Budget)
| Component | Memory Usage | Description |
|---|---|---|
| Double Buffer | 57.6KB | 240x60x2x2B |
| LVGL Core | ~50KB | Base library overhead |
| Font + Image Resources | ~80KB | Chinese and English fonts + UI materials |
| Application Data | ~68.4KB | Remaining available memory |
| Total | ~256KB | No memory overflow |
5. Common Issues Quick Resolution
| Issue | Cause | Solution |
|---|---|---|
| Screen Flickering | Single buffer rendering conflicts with display | Enable double buffering (DIRECT mode) |
| Insufficient Memory | Buffer too large / improper color format | Switch to PARTIAL mode + RGB565 |
| Animation Stuttering | Flush callback efficiency is low | Enable DMA accelerated transfer |
| Poor Multi-Screen Performance | All screens use the same configuration | Differentiated buffer configuration for main and secondary screens |
LVGL Display Optimization Practices
-
Memory Priority: For resource-constrained devices, choose “Partial Rendering + RGB565”
-
Performance Priority: For complex animations, choose “Double Buffering / Triple Buffering + DMA”
-
Dynamic Adjustment: Use monitoring tools to view buffer usage in real-time (optimize if over 80%)
-
Hardware Adaptation: Fully utilize hardware features such as DMA and shared video memory
The core of optimizing LVGL display is to find the balance between “memory usage” and “performance smoothness” under hardware constraints.
