Explaining Assembly Language: Converting Logical Addresses to Linear Addresses

Memory Isolation Issues in a Multitasking Environment

In a multitasking operating system, multiple programs run simultaneously, each with its own data area. Suppose there are three programs, each with a variable offset address of 200h. The system needs a mechanism to distinguish these variables to prevent them from interfering with each other.

x86 Solution: Segmentation Mechanism

The x86 processor uses a segmentation mechanism to solve this problem, converting logical addresses to physical addresses in one or two steps.

Step One: Logical Address → Linear Address

Linear Address = Segment Base Address + Offset Address

Components of a Logical Address:

• Segment Selector: Specifies the segment to be used
• Offset Address: Position within the segment

Conversion Process:

1. Find the corresponding segment descriptor in the descriptor table based on the segment selector
2. Obtain the segment base address from the segment descriptor
3. Add the segment base address to the offset address to get the linear address

Assembly Language Example

; Assume the DS register contains the segment selector pointing to the current data segment
MOV AX, [200h]    ; Logical Address: DS:200h

; Conversion Process:
; 1. Get the segment selector from DS
; 2. Find the corresponding segment descriptor in GDT or LDT
; 3. Get the segment base address (assumed to be 10000h)
; 4. Calculate the linear address: 10000h + 200h = 10200h

Example of Variable Distinction for Three Programs

Assume there are three tasks (programs), each with its own Local Descriptor Table (LDT):

Configuration of Task 1:

; Segment descriptor in LDT1
; Segment Base Address = 30000h, Segment Limit = 1000h

MOV AX, 200h      ; Offset Address
; Linear Address = 30000h + 200h = 30200h

Configuration of Task 2:

; Segment descriptor in LDT2
; Segment Base Address = 40000h, Segment Limit = 1000h

MOV AX, 200h      ; Offset Address
; Linear Address = 40000h + 200h = 40200h

Configuration of Task 3:

; Segment descriptor in LDT3
; Segment Base Address = 50000h, Segment Limit = 1000h

MOV AX, 200h      ; Offset Address
; Linear Address = 50000h + 200h = 50200h

Results: Although all three programs access the offset address 200h, they obtain different linear addresses due to using different segment descriptors (different segment base addresses):

• Task 1: 30200h
• Task 2: 40200h
• Task 3: 50200h

Detailed Structure of Segment Descriptors

A segment descriptor contains the following important fields:

31                23                15                7               0
+-----------------+-----------------+-----------------+-----------------+
| Base 31:24      | Flags           | Base 23:16      | Access Rights    | High 32 bits
+-----------------+-----------------+-----------------+-----------------+
| Segment Base 15:0                     | Segment Limit 15:0                     | Low 32 bits
+-----------------+-----------------+-----------------+-----------------+

Key Field Descriptions:

• Base (32 bits): Defines the starting position of the segment in the linear address space
• Segment Limit (20 bits): Defines the size of the segment
• Type Field: Specifies the type of segment (code segment, data segment, etc.) and access rights
• Privilege Level (DPL): Levels 0-3, with level 0 being the highest privilege
• Segment Present Flag (P): Indicates whether the segment is in memory
• Granularity Flag (G): 0=byte granularity, 1=4KB page granularity

Complete Address Conversion Process

; Example: Accessing Logical Address DS:200h

; 1. Get the segment selector from DS
;    Assume DS = 001Bh (binary: 0000000000011011)
;    - Index = 0011b = 3 (index in the descriptor table)
;    - TI = 1 (using LDT instead of GDT)
;    - RPL = 11b = 3 (Requested Privilege Level)

; 2. Select the descriptor table based on the TI bit
;    TI=1, using the current task's LDT

; 3. Look up the 3rd descriptor in the LDT
;    Descriptor Location = LDT Base Address + Index × 8

; 4. Read the segment base address from the descriptor (assumed to be 30000h)

; 5. Calculate the linear address
;    Linear Address = Segment Base Address 30000h + Offset Address 200h = 30200h

Paging Mechanism (Optional Second Step)

If paging is enabled, the linear address needs to be further converted to a physical address:

Logical Address → Linear Address → Physical Address

Paging Conversion Process:

1. Split the linear address into: Page Directory Index (10 bits) + Page Table Index (10 bits) + Page Offset (12 bits)
2. Find the page directory using the CR3 register
3. Find the page table based on the page directory index
4. Find the physical page frame based on the page table index
5. Add the page offset to get the physical address

Conclusion

Through the segmentation mechanism, the x86 processor achieves:

• Memory Isolation: Each task has its own address space
• Address Conversion: Logical addresses are converted to linear addresses via segment descriptors
• Access Protection: Protects system resources through privilege levels and type fields
• Virtual Memory: Supports a larger address space than physical memory through paging

This mechanism ensures that in a multitasking environment, even if multiple programs use the same offset address, they access different memory locations, thus achieving true memory isolation.
