Introduction
📋📋📋 The table of contents is as follows: 🎁🎁🎁
Table of Contents
💥1 Overview
📚2 Partial Code and Running Steps
🎉3 Running Results
🌈4 MATLAB Version and References
🔎5 Code Acquisition Method
🍅6 Simulation Consultation
1 Overview
See CSDN “Sea God” with the same title
**1 IGBT Finite Element Thermal Calculation Analysis Principle** The thermal coupling analysis of IGBT (Insulated Gate Bipolar Transistor) is based on the theory of multiphysics coupling, involving the interaction of electric fields, thermal fields, and structural fields. The core principles are as follows: **Electric Field Analysis** The drift-diffusion model is used to describe the carrier transport process, solving the potential distribution and current density through Poisson’s equation and continuity equations: ∇·(ε∇φ) = -ρ ∂n/∂t = ∇·(J_n/q) – R ∂p/∂t = -∇·(J_p/q) – R **Thermal Field Analysis** The temperature field distribution is described by Fourier’s heat conduction equation, considering Joule heating and switching losses as heat sources: ρc_p ∂T/∂t = ∇·(k∇T) + Q_joule + Q_switching **Coupling Mechanism** The electric-thermal bidirectional coupling is realized through the temperature dependence of material parameters: Resistivity ρ(T), thermal conductivity k(T), and other parameters change with temperature, forming a nonlinear iterative solution system. **2 IGBT Finite Element Thermal Analysis Process** **Geometric Modeling and Mesh Division** Establish a three-dimensional model of a multilayer structure including the chip, solder layer, and substrate, using local refined mesh for key areas (such as the channel area). Typical element sizes are 10μm for the chip layer and 100μm for the substrate layer. **Material Property Definition** Set temperature-related material parameters: – Silicon Chip: ρ(T)=ρ_0[1+α(T-T_0)] – Copper Substrate: k(T)=398[1-0.0033(T-300)] W/(m·K) – Solder: Anisotropic thermal conductivity matrix **Boundary Condition Settings** Electrical boundary: Apply gate voltage V_ge and collector current I_c Thermal boundary: Heat sink convection coefficient h=500-5000 W/(m²·K) Initial temperature: T_0=300K **Solver Configuration** Use a transient coupling solver, with time steps set according to switching frequency (e.g., 1μs step). The convergence criterion is usually set to energy residual <1e-6. **Post-Processing Analysis** Extract key results: – Maximum chip temperature T_max – Thermal resistance R_th=junction-to-case – Temperature distribution cloud map and heat flow vector map **Validation Method** Compare the measured temperature from an infrared thermal imager with simulation results, with an error of <5%. Typical commercial tools include ANSYS Icepak, COMSOL Multiphysics, etc. **3 Key Influencing Factors** **Mesh Sensitivity** The mesh size in the channel area must be less than the carrier diffusion length (approximately 50μm), and the mesh aspect ratio should be <5 to avoid numerical oscillations. **Loss Model Accuracy** Switching losses are fitted using double pulse test data, and conduction losses must consider the temperature characteristics of the saturation voltage V_ce(sat). **Interface Thermal Resistance** The thermal resistance at the chip-solder interface significantly affects the results and needs to be calibrated through laser flash method measurements or literature data (typical values 1-10 mm²·K/W).
2 Partial Code and Running Steps
2.1 Partial Code2.2 Running Steps
(1) Directly run main.m to generate the graph with one click
3Running Results
4MATLAB Version and References
1 MATLAB Version
2019b
2 References
[1] Men Yunge. MATLAB Physical Calculation and Visualization [M]. Tsinghua University Press, 2013.
3 Note
This section is extracted from the internet for reference only. If there is any infringement, please contact for deletion.
