Comprehensive Analysis of Linux Firewall! Securing the Operating System (Part 2)

firewall-cmd --list-service[root@localhost ~]# firewall-cmd --set-default-zone=publicsuccess[root@localhost ~]# firewall-cmd --list-servicessh dhcpv6-client[root@localhost ~]# firewall-cmd --set-default-zone=homesuccess[root@localhost ~]# firewall-cmd --list-servicessh mdns samba-client dhcpv6-client# This allows for a more intuitive view of the services supported in different zones

firewall-cmd --add-service=service_name --zone=zone_name[root@localhost ~]# firewall-cmd --add-service=http --zone=homesuccess      # Add the http service to the home zone policy[root@localhost ~]# firewall-cmd --list-servicessh mdns samba-client dhcpv6-client http  # Check if the http service was successfully added[root@localhost ~]# firewall-cmd --add-service=http --zone=publicsuccess        # Add the http service to the public zone policy[root@localhost ~]# firewall-cmd --list-service --zone=publicssh dhcpv6-client http         # Check if the http service was successfully added

firewall-cmd --remove-servic=service_name --zone=zone_name[root@localhost ~]# firewall-cmd --remove-servic=http --zone=publicsuccess        # Remove the newly added http service from the public zone[root@localhost ~]# firewall-cmd --list-service --zone=publicssh dhcpv6-client    # Now the http service is no longer present

The commands for adding or removing services are temporary; after a firewall restart, the services will revert to their default configurations. Firewall restart command: firewall-cmd --reload or systemctl restart firewalld[root@localhost ~]# firewall-cmd --reloadsuccess[root@localhost ~]# firewall-cmd --list-service --zone=homessh mdns samba-client dhcpv6-client    # The http service in the home zone did not get removed, and after restart, it returned to its default state

firewall-cmd --runtime-to-permanent (use after executing the add service command)[root@localhost ~]# firewall-cmd --add-service=http --zone=publicsuccess              # Add http service to public zone[root@localhost ~]# firewall-cmd --list-service --zone=publicssh dhcpv6-client http      # Check services in the public zone[root@localhost ~]# firewall-cmd --runtime-to-permanentsuccess              # Write the current running configuration rules to the configuration file to make them permanent[root@localhost ~]# firewall-cmd --reloadsuccess              # Restart the firewall service to verify if the permanent settings are successful[root@localhost ~]# firewall-cmd --list-service --zone=publicssh dhcpv6-client http      # Check the public zone services again, and find that the http service still exists after restarting the firewall service

firewall-cmd --zone=zone_name --add-port=port_number/protocol_name[root@localhost ~]# firewall-cmd --get-default-zonehome            # View the current default zone[root@localhost ~]# firewall-cmd --zone=home --add-port=443/tcpsuccess            # Add port 443 to the home zone; the port must be followed by the protocol name, otherwise an error will occur[root@localhost ~]# firewall-cmd --zone=home --add-port=6600/tcpsuccess            # Add port 6600 to the home zone[root@localhost ~]# firewall-cmd --list-port --zone=home443/tcp 6600/tcp      # View ports in the home zone[root@localhost ~]# firewall-cmd --zone=public --add-port=3000-3010/udpsuccess            # If adding multiple ports to a zone, a '-' can be used to indicate a range[root@localhost ~]# firewall-cmd --list-port --zone=public3000-3010/udp        # View the newly opened ports in the public zone

Need to add ‘–permanent’ option to remove portfirewall-cmd --zone=zone_name --remove-port=port_number/protocol_name[root@localhost ~]# firewall-cmd --zone=public --remove-port=3000-3010/udpsuccess            # Remove ports 3000-3010 just added to the public zone; the port number must also be followed by the service name[root@localhost ~]# firewall-cmd --list-port --zone=public# At this point, check that the 3000-3010 ports no longer exist in the public zone

# 1. Start/stop commandsystemctl status firewalld          # Check the running status of the firewall systemctl start firewalld          # Start the firewalld service systemctl restart firewalld          # Restart the firewalld service systemctl stop firewalld          # Stop the firewalld service firewall-cmd --reload            # Restart the firewall # 2. Zone commands firewall-cmd --get-default-zone        # Show the current default zone firewall-cmd --set-default-zone=<zone>    # Modify the default zone firewall-cmd --get-active-zones        # Show currently active zones and their corresponding network interfaces firewall-cmd --get-zones          # Show all available zones firewall-cmd --zone=<zone> --add-interface=<interface># Bind a specified interface to a zone firewall-cmd --zone=<zone> --remove-interface=<interface>   # Remove the binding of a network interface from a specified zone firewall-cmd --list-all-zones        # Show all zones and their policies # 3. Service commands firewall-cmd --list-service          # View all services allowed in the default zone firewall-cmd --add-service=<service_name> --zone=<specified_zone># Add the corresponding service to the specified zone firewall-cmd --add-service=http --zone=public# Add the httpd service to the public zone firewall-cmd --remove-service=<service_name> --zone=<specified_zone># Remove the service from the specified zone firewall-cmd --add-service=<service_name> --zone=<specified_zone> --permanent                                          # Add the corresponding service to the specified zone and make it permanent # 4. Port commands firewall-cmd --zone=<zone_name> --add-port=<port_name>/<protocol_name># Add port to specified zone, must follow with protocol name firewall-cmd --zone=home --add-port=443/tcp# Add TCP protocol port 443 to home zone firewall-cmd --zone=home --add-port=443/tcp --permanent# Permanently add TCP protocol port 443 to home zone firewall-cmd --list-port --zone=<port_name>    # View the opened ports in the specified zone firewall-cmd --zone=<zone_name> --remove-port=<port_name>/<protocol_name># Remove port from specified zone firewall-cmd --zone=home --remove-port=443/tcp# Remove TCP port 443 from the home zone</protocol_name></port_name></zone_name></port_name></protocol_name></port_name></zone_name></specified_zone></service_name></specified_zone></service_name></specified_zone></service_name></interface></zone></interface></zone></zone>
