1 Overview
Extended Kalman Filter Multi-Robot State Estimation
The Extended Kalman Filter (EKF) is a filtering algorithm used for multi-robot state estimation. It is an extension of the Kalman filter that can handle nonlinear system models and nonlinear measurement models. The principle of EKF is to approximate nonlinear models by using linearized state transition and observation models in the Kalman filter. Specifically, EKF uses Taylor series expansion to linearize nonlinear functions, allowing the Kalman filter’s recursive formulas to be applied to nonlinear systems. The process of EKF is as follows: 1 Initialization: Set the initial state estimate and covariance matrix. 2 Prediction: Predict the state based on the system model while calculating the covariance matrix of the state prediction. 3 Update: Obtain measurement data, correct the predicted value based on the measurement model, and update the state estimate and covariance matrix. 4 Repeat steps 2 and 3 until convergence. It is important to note that the accuracy and performance of EKF are affected by linearization errors. Therefore, when using EKF for multi-robot state estimation, careful selection of the linearization point based on the specific application scenario is necessary to minimize the impact of linearization errors.
2 Code and Running Steps
(1) Directly run main.m to generate the plot with one click
3Running Results
3Running Results
4Matlab Version and References
1 Matlab Version
2019b
2 References
[1] Sun Haibo, Tong Ziyuan, Tang Shoufeng, Tong Mingming, Ji Yuming. Review of SLAM Research Based on Kalman Filtering and Particle Filtering [J]. Software Guide. 2018
3 Note
This part is extracted from the internet for reference only. If there is any infringement, please contact for deletion.
5 Code Acquisition Method
Code Acquisition Method: Matlab Poseidon Code Acquisition Method
