1 Overview

See CSDN Poseidon with the same title

**1 Point Cloud Human Positioning Principle** Point cloud human positioning is mainly based on point cloud data in three-dimensional space, identifying and locating humans through geometric features, deep learning, or statistical methods. The core principles include: – **Geometric Feature Analysis**: Utilizing the geometric characteristics of body parts (e.g., head is approximately spherical, torso is cylindrical) for segmentation and matching. – **Deep Learning Models**: Using 3D Convolutional Neural Networks (CNN) or point cloud-specific networks (e.g., PointNet++) to directly process point cloud data and extract human features. – **Clustering Segmentation**: Separating human point clouds from other objects using Euclidean distance or density clustering (e.g., DBSCAN). – **Temporal Information Fusion**: In dynamic scenes, combining multi-frame point cloud data (e.g., through Kalman filtering) to enhance positioning stability. **2 Point Cloud Human Positioning Process** **Data Acquisition** Using depth cameras (e.g., Kinect), LiDAR, or structured light devices to obtain three-dimensional point cloud data of the scene. The data typically includes XYZ coordinates, RGB color (optional), and reflectivity information. **Preprocessing** – Noise Reduction: Removing outliers through statistical filtering or radius filtering. – Ground Removal: Using RANSAC or plane fitting to separate ground point clouds. – Downsampling: Reducing data volume and improving processing speed through voxel grid filtering. **Human Detection** – Based on Deep Learning: Inputting point clouds into pre-trained models (e.g., PointNet++, VoxelNet) to output human bounding boxes or key points. – Based on Traditional Methods: Clustering segmentation of candidate regions, combined with human size priors to filter targets. **Positioning and Pose Estimation** – Center Point Calculation: The detected human point cloud determines the position through the centroid or bounding box center. – Key Point Detection: Predicting the three-dimensional coordinates of key joints (e.g., head, limbs) through the model to reconstruct human posture. **Postprocessing** – Coordinate Transformation: Converting human positions from the camera coordinate system to the world coordinate system. – Tracking: Using the Hungarian algorithm or Kalman filtering to associate the same target across multiple frames, avoiding jitter. **3 Key Algorithm Examples** **Euclidean Clustering Segmentation (PCL Library Example)** “`cpp pcl::EuclideanClusterExtraction<pcl::PointXYZ> ec; ec.setClusterTolerance(0.02); // Set clustering distance threshold ec.setMinClusterSize(100); // Minimum point cloud size ec.setMaxClusterSize(25000); // Maximum point cloud size ec.setInputCloud(cloud_filtered); ec.extract(cluster_indices); // Output clustering results “` **PointNet++ Key Point Detection** “`python import torch model = PointNet2SSG(num_classes=17) # 17 human key points points = torch.randn(1, 3, 2048) # Input point cloud pred_keypoints = model(points) # Output key point coordinates “` **4 Application Scenarios** – **Security Monitoring**: Locating suspicious individuals in complex environments. – **Autonomous Driving**: Identifying pedestrian locations to avoid collisions. – **Virtual Reality**: Real-time capturing of user actions for interaction.

2 Partial Code and Running Steps

2.1 Partial Code2.2 Running Steps

(1) Directly run main.m to generate the output with one click

3Running Results

4MATLAB Version and References

1 MATLAB Version

2019b

2 References

[1] Ni Yiyang, Zhu Hongbo, Wang Yuxi. Overview of Millimeter Wave D2D Communication Technology for 5G [J]. Modern Electronic Technology. 2019

[2] Wan Yuan, Li Xingguo, Wang Hong. Application of Channel Coding Technology in Millimeter Wave Communication [J]. Journal of Ordnance and Guidance. 2006

3 Note

This section is excerpted from the internet for reference only. If there is any infringement, please contact for removal.
