Hello everyone! Today, I will guide you through implementing one of the most important features in Excel using C++—the cell reference system.
1. Basic Characteristics of Excel Cell References
Excel cell references mainly have three characteristics:
- Coordinate Representation: Row and column identifiers like A1, B2
- Relative/Absolute References: Mixed references like 1 or A$1
- Range References: Area references like A1:B5
To implement this functionality in C++, we need:
- Coordinate Conversion: Converting letters and numbers into row and column indices
- Reference Types: Handling relative and absolute references
- Dependency Management: Tracking the reference relationships between cells
2. Basic Data Structure Design
1. Cell Coordinate Class
#include <string>
#include <utility> // for std::pair
class CellReference {
private:
int row; // Row number (0-based)
int col; // Column number (0-based)
bool isAbsRow; // Is it an absolute row reference
bool isAbsCol; // Is it an absolute column reference
public:
// Parse references like "A1", "$B$2"
CellReference(const std::string& ref) {
size_t colEnd = ref.find_first_of("0123456789");
std::string colPart = ref.substr(0, colEnd);
// Determine if the column is an absolute reference
if(!colPart.empty() && colPart[0] == '$') {
isAbsCol = true;
colPart = colPart.substr(1);
}
col = 0;
for(char c : colPart) {
col = col * 26 + (toupper(c) - 'A' + 1);
}
col--; // Convert to 0-based
// Handle the row part
std::string rowPart = ref.substr(colEnd);
if(!rowPart.empty() && rowPart[0] == '$') {
isAbsRow = true;
rowPart = rowPart.substr(1);
}
row = std::stoi(rowPart) - 1; // Convert to 0-based
}
std::pair<int, int> toAbsolute(int currentRow, int currentCol) const {
return {
isAbsRow ? row : currentRow + row,
isAbsCol ? col : currentCol + col
};
}
// Convert to string representation
std::string toString() const {
std::string result;
if(isAbsCol) result += "$";
result += colToLetters(col);
if(isAbsRow) result += "$";
result += std::to_string(row + 1);
return result;
}
private:
static std::string colToLetters(int col) {
std::string result;
while(col >= 0) {
result = char('A' + (col % 26)) + result;
col = col / 26 - 1;
}
return result;
}
};
Tips:
- Excel column numbers are represented as A=1, Z=26, AA=27 in base 26
- Row and column numbers are converted to 0-based for easier processing
- Absolute references are indicated with
<span>$</span>, such as<span>$A$1</span>
3. Cell Class Implementation
1. Basic Cell Class
#include <memory>
#include <set>
class Spreadsheet; // Forward declaration
class Cell {
private:
std::string rawValue; // Raw value or formula
double computedValue; // Computed value
Spreadsheet* sheet; // Associated spreadsheet
std::set<CellReference> references; // Referenced other cells
std::set<Cell*> dependents; // Cells that depend on this cell
public:
Cell(Spreadsheet* s) : sheet(s), computedValue(0.0) {}
void setValue(const std::string& value);
double getValue() const { return computedValue; }
const auto& getReferences() const { return references; }
void addDependent(Cell* cell) { dependents.insert(cell); }
void updateReferences();
void notifyDependents();
};
2. Formula Parsing and Reference Extraction
void Cell::setValue(const std::string& value) {
rawValue = value;
references.clear();
if(value.empty()) {
computedValue = 0.0;
return;
}
if(value[0] == '=') { // Formula
// Simple parsing for formulas like SUM(A1:B2)
size_t start = 1;
while(start < value.size()) {
size_t refStart = value.find_first_of("A-Za-z$", start);
if(refStart == std::string::npos) break;
size_t refEnd = value.find_first_not_of("A-Za-z0-9$", refStart);
if(refEnd == std::string::npos) refEnd = value.size();
std::string refStr = value.substr(refStart, refEnd - refStart);
references.insert(CellReference(refStr));
start = refEnd;
}
} else { // Regular value
try {
computedValue = std::stod(value);
} catch(...) {
computedValue = 0.0;
}
}
updateReferences();
notifyDependents();
}
4. Spreadsheet Class Implementation
1. Basic Spreadsheet Class
#include <vector>
#include <unordered_map>
class Spreadsheet {
private:
std::vector<std::vector<std::unique_ptr<Cell>>> cells;
// Convert coordinate string like "A1" to row and column indices
std::pair<int, int> parseCoord(const std::string& coord) const {
CellReference ref(coord);
return ref.toAbsolute(0, 0); // Here 0,0 does not affect absolute references
}
public:
Spreadsheet(int rows, int cols) {
cells.resize(rows);
for(auto& row : cells) {
row.resize(cols);
for(auto& cell : row) {
cell = std::make_unique<Cell>(this);
}
}
}
Cell* getCell(int row, int col) {
return cells[row][col].get();
}
Cell* getCell(const std::string& coord) {
auto [row, col] = parseCoord(coord);
return getCell(row, col);
}
// Update all cell dependencies
void rebuildDependencies() {
// First clear all dependencies
for(auto& row : cells) {
for(auto& cell : row) {
cell->clearDependents();
}
}
// Rebuild dependencies
for(int r = 0; r < cells.size(); ++r) {
for(int c = 0; c < cells[r].size(); ++c) {
cells[r][c]->updateReferences();
}
}
}
};
2. Dependency Management
void Cell::updateReferences() {
if(!sheet) return;
// Notify old dependencies that they are no longer needed
for(auto& ref : references) {
auto [refRow, refCol] = ref.toAbsolute(/*current row and column*/);
Cell* refCell = sheet->getCell(refRow, refCol);
if(refCell) {
refCell->removeDependent(this);
}
}
// Establish new dependencies
for(auto& ref : references) {
auto [refRow, refCol] = ref.toAbsolute(/*current row and column*/);
Cell* refCell = sheet->getCell(refRow, refCol);
if(refCell) {
refCell->addDependent(this);
}
}
}
void Cell::notifyDependents() {
for(Cell* dependent : dependents) {
dependent->recalculate();
}
}
void Cell::recalculate() {
if(rawValue.empty() || rawValue[0] != '=') return;
// Here should implement complete formula calculation
// Simplified version only handles simple cell references
double sum = 0.0;
for(auto& ref : references) {
auto [refRow, refCol] = ref.toAbsolute(/*current row and column*/);
Cell* refCell = sheet->getCell(refRow, refCol);
if(refCell) {
sum += refCell->getValue();
}
}
computedValue = sum;
notifyDependents(); // Notify dependent cells after value change
}
5. Range Reference Implementation
1. Range Reference Class
class CellRange {
private:
CellReference topLeft;
CellReference bottomRight;
public:
CellRange(const std::string& range) {
size_t colon = range.find(':');
if(colon == std::string::npos) {
topLeft = CellReference(range);
bottomRight = topLeft;
} else {
topLeft = CellReference(range.substr(0, colon));
bottomRight = CellReference(range.substr(colon + 1));
}
}
// Get all cell coordinates within the range
std::vector<std::pair<int, int>> getCoordinates(int currentRow, int currentCol) const {
auto [startRow, startCol] = topLeft.toAbsolute(currentRow, currentCol);
auto [endRow, endCol] = bottomRight.toAbsolute(currentRow, currentCol);
std::vector<std::pair<int, int>> coords;
for(int r = startRow; r <= endRow; ++r) {
for(int c = startCol; c <= endCol; ++c) {
coords.emplace_back(r, c);
}
}
return coords;
}
};
2. Range Reference Functions (e.g., SUM)
double sumRange(Spreadsheet* sheet, const std::string& range, int currentRow, int currentCol) {
CellRange cellRange(range);
auto coords = cellRange.getCoordinates(currentRow, currentCol);
double sum = 0.0;
for(auto [r, c] : coords) {
Cell* cell = sheet->getCell(r, c);
if(cell) {
sum += cell->getValue();
}
}
return sum;
}
6. Considerations
-
Cycle Reference Detection:
class Cell { bool inCalculation = false; void recalculate() { if(inCalculation) { throw std::runtime_error("Cycle reference detected"); } inCalculation = true; // Calculation logic... inCalculation = false; } }; -
Performance Optimization:
- Use smart pointers for memory management
- Only recalculate affected cells
- Consider using the observer pattern to optimize notification mechanisms
Extension Suggestions:
- Add cross-sheet references
- Support named ranges
- Implement a more complete formula parser
7. Hands-On Practice
Try these interesting exercises:
- Implement a copy-paste feature that supports relative references
- Add support for R1C1 style references
- Create a reference tracking visualization tool
- Implement function calls in formulas (e.g., SUM, AVERAGE)
Conclusion
Today we delved into:
- The implementation principles of Excel-style cell references
- Methods for converting row and column coordinates
- Management of dependencies between cells
- Techniques for handling range references
Cell references are a core feature of spreadsheets, mastering this technology can make your program more professional. It is recommended to start with simple absolute references and gradually implement relative and range references.
