Practical Optimization Techniques in Embedded Development

Source | Embedded Miscellaneous

In embedded development, resources are always scarce. Insufficient memory, slow execution speed, high power consumption… do these issues often trouble you?

Today, I will share several code optimization techniques that have been validated in practice!

1. Time Efficiency Optimization

Avoid Floating Point Operations

// Slow version: floating point operation
float calculate_voltage(int adc_value) {
    return adc_value * 3.3f / 4096.0f;
}

// Fast version: fixed-point operation
int calculate_voltage_fast(int adc_value) {
    return (adc_value * 3300) >> 12;  // Replace division by 4096 with right shift
}

Reduce Function Calls

// Slow version: frequent function calls
for(int i = 0; i < 1000; i++) {
    set_led_state(i % 2);
}

// Fast version: inline expansion
for(int i = 0; i < 1000; i++) {
    if(i % 2) {
        GPIO_SetBits(GPIOA, GPIO_Pin_5);
    } else {
        GPIO_ResetBits(GPIOA, GPIO_Pin_5);
    }
}

2. Space Efficiency Optimization

Select Appropriate Data Types

// Memory-wasting approach
struct sensor_data {
    int temperature;     // Only needs -40 to 125
    int humidity;        // Only needs 0 to 100
    int pressure;        // Only needs 300 to 1100
};

// Memory-saving approach
struct sensor_data_optimized {
    int8_t temperature;   // -128 to 127, sufficient
    uint8_t humidity;     // 0 to 255, sufficient
    uint16_t pressure;    // 0 to 65535, sufficient
};
// Memory saving: reduced from 12 bytes to 4 bytes

Use Unions to Save Space

// Communication protocol data packet
typedef union {
    struct {
        uint8_t header[4];
        uint8_t cmd;
        uint8_t data[32];
        uint8_t checksum;
    } packet;
    uint8_t raw_data[38];
} comm_frame_t;

// Can be accessed by byte or by structure
comm_frame_t frame;
frame.packet.cmd = 0x01;           // Structured access
send_data(frame.raw_data, 38);     // Byte array access

3. Trade Space for Time

Scenario

You need to count how many 1s are in a 4-bit data (0x0~0xF), the traditional method is to loop through each bit.

Regular Approach

int count_ones_slow(unsigned char data) {
    int cnt = 0;
    unsigned char temp = data & 0xf;

    for (int i = 0; i < 4; i++) {
        if (temp &amp; 0x01) {
            cnt++;
        }
        temp >>= 1;
    }
    return cnt;
}

Optimized Approach

// Pre-computed lookup table
static int ones_table[16] = {
    0, 1, 1, 2, 1, 2, 2, 3,
    1, 2, 2, 3, 2, 3, 3, 4
};

int count_ones_fast(unsigned char data) {
    return ones_table[data & 0xf];
}

Performance Comparison:

• Traditional method: requires 4 loops + 4 bit operations
• Lookup method: only requires 1 array access

Applicable Scenarios: complex calculations, trigonometric functions, CRC checks, etc.

4. Use Flexible Arrays

Problems with Traditional Pointer Method

typedef struct {
    uint16_t head;
    uint8_t id;
    uint8_t type;
    uint8_t length;
    uint8_t *value;  // Pointer method
} protocol_old_t;

Problems:

• Requires two memory allocations
• Memory is not contiguous, access efficiency is low
• Memory release is prone to errors

The Elegance of Flexible Arrays

typedef struct {
    uint16_t head;
    uint8_t id;
    uint8_t type;
    uint8_t length;
    uint8_t value[];  // Flexible array
} protocol_new_t;

Advantages:

• Single allocation, contiguous memory
• Faster access speed
• Simpler memory management
• Avoids memory leak risks

Usage Example:

// Allocate struct + data space
protocol_new_t *p = malloc(sizeof(protocol_new_t) + data_len);

5. Use Bit Manipulation

Bit Fields: A Memory-Saving Trick

How would you manage 8 flag bits?

Memory-Wasting Approach:

struct flags_waste {
    unsigned char flag1;
    unsigned char flag2;
    unsigned char flag3;
    unsigned char flag4;
    unsigned char flag5;
    unsigned char flag6;
    unsigned char flag7;
    unsigned char flag8;  // Total 8 bytes!
};

Memory-Efficient Approach:

struct flags_smart {
    unsigned char flag1:1;  // Only uses 1 bit
    unsigned char flag2:1;
    unsigned char flag3:1;
    unsigned char flag4:1;
    unsigned char flag5:1;
    unsigned char flag6:1;
    unsigned char flag7:1;
    unsigned char flag8:1;  // Total 1 byte!
} flags;

Memory Saving: reduced from 8 bytes to 1 byte!

Bit Operations: Replacing Multiplication and Division

Slow Version:

uint32_t val = 1024;
uint32_t doubled = val * 2;    // Multiplication instruction
uint32_t halved = val / 2;     // Division instruction

Fast Version:

uint32_t val = 1024;
uint32_t doubled = val << 1;   // Left shift 1 bit = multiply by 2
uint32_t halved = val >> 1;    // Right shift 1 bit = divide by 2

6. Loop Unrolling – Reducing Jumps

Overhead of Traditional Loops

// Each loop has jump overhead
for (int i = 0; i < 4; i++) {
    process(array[i]);
}

Efficient Version After Unrolling

// Direct execution, no jump overhead
process(array[0]);
process(array[1]);
process(array[2]);
process(array[3]);

Advanced Unrolling: Parallel Computation

Regular Version:

long calc_sum_slow(int *arr0, int *arr1) {
    long sum = 0;
    for (int i = 0; i < 1000; i++) {
        sum += arr0[i] * arr1[i];  // Serial computation
    }
    return sum;
}

Optimized Version:

long calc_sum_fast(int *arr0, int *arr1) {
    long sum0 = 0, sum1 = 0, sum2 = 0, sum3 = 0;

    for (int i = 0; i < 250; i += 4) {
        sum0 += arr0[i+0] * arr1[i+0];  // Parallel computation
        sum1 += arr0[i+1] * arr1[i+1];
        sum2 += arr0[i+2] * arr1[i+2];
        sum3 += arr0[i+3] * arr1[i+3];
    }

    return sum0 + sum1 + sum2 + sum3;
}

7. Inline Functions – Eliminating Function Call Overhead

The Hidden Cost of Function Calls

Each function call has overhead:

• Parameter stack pushing
• Jump instructions
• Stack frame management
• Return address saving

The Magic of Inline Functions

static inline void toggle_led(uint8_t pin) {
    PORT ^= 1 << pin;
}

// Directly expanded after compilation, no function call overhead
toggle_led(LED_PIN);

Applicable Scenarios:

• Frequently called small functions
• Functions on critical paths
• Simple utility functions

8. Data Type Optimization

The Art of Loop Variables

Inefficient Approach:

char i;  // May overflow, compiler needs extra checks
for (i = 0; i < N; i++) {
    // ...
}

Efficient Approach:

int i;   // Better compiler optimization
for (i = 0; i < N; i++) {
    // ...
}

Data Type Selection Principles

• Loop Index: Prefer using int
• Storage Optimization: Use char if possible instead of int
• Compute Intensive: Avoid unnecessary floating-point operations
• Type Conversion: Reduce implicit type conversions

9. Loop Optimization Strategies

The Art of Nested Loop Arrangement

Inefficient Arrangement (long loop on the outer layer):

for (row = 0; row < 100; row++) {      // Outer loop 100 times
    for (col = 0; col < 5; col++) {    // Inner loop 5 times
        sum += a[row][col];
    }
}
// Total jump count: 100 outer jumps

Efficient Arrangement (long loop on the inner layer):

for (col = 0; col < 5; col++) {       // Outer loop 5 times
    for (row = 0; row < 100; row++) {  // Inner loop 100 times
        sum += a[row][col];
    }
}
// Total jump count: 5 outer jumps

Early Exit Strategy

Inefficient Method (execute complete loop):

bool found = false;
for (int i = 0; i < 10000; i++) {
    if (list[i] == target) {
        found = true;  // Continue looping even after found!
    }
}

Efficient Method (exit immediately upon finding):

bool found = false;
for (int i = 0; i < 10000; i++) {
    if (list[i] == target) {
        found = true;
        break;  // Exit immediately
    }
}

10. Structure Memory Alignment Optimization

The Impact of Memory Alignment

Unoptimized Version:

struct waste_memory {
    char a;      // 1 byte
    short b;     // 2 bytes, needs alignment
    char c;      // 1 byte
    int d;       // 4 bytes, needs alignment
    char e;      // 1 byte
};
// Actual usage: 16 bytes

Optimized Version:

struct save_memory {
    char a;      // 1 byte
    char c;      // 1 byte
    short b;     // 2 bytes, perfectly aligned
    int d;       // 4 bytes, perfectly aligned
    char e;      // 1 byte
};
// Actual usage: 12 bytes, saving 25%!

Notes

Optimization Principles

Do not optimize for the sake of optimization; do not sacrifice code readability.

1. Measure first, then optimize: Use tools to find the real bottlenecks
2. Trade-offs: Performance vs readability vs maintainability
3. Incremental optimization: Optimize hotspot code first
4. Validate results: Test correctness after optimization

Good optimization is not about showing off skills, but finding the best balance under constraints.

What other optimization techniques have you used in embedded development?
