In the critical stage of integrated circuit (IC) design before tape-out, the routing layout becomes a crucial factor in determining the chip’s performance, power consumption, and reliability. A reasonable routing strategy not only optimizes signal integrity but also effectively reduces noise interference, ensuring the correct implementation of chip functions.
1. Control Wire Length and Enhance Drive
Metal connections should be kept as short as possible to reduce delay and signal attenuation; long connections need to add buffers to enhance driving capability and ensure signal quality.
2. Optimize Line Width
The width of long connections should be appropriately increased to lower resistance, reduce voltage drop and heat generation, while improving signal integrity.
3. Avoid Routing Over Sensitive Areas
Avoid routing over the channel of transistors to minimize potential impacts on transistor performance.
4. Ensure Connection Reliability
Connection joints must overlap to ensure a solid physical connection and avoid open circuit risks.
5. Digital-Analog Separation Principle
Digital and analog circuit routing must be strictly separated to prevent high-frequency noise from digital signals from interfering with analog signals, and vice versa.
6. Use Guard Ring Isolation
Set up a guard ring around the analog circuit, and if necessary, ground it separately or connect it to the power supply voltage to enhance anti-interference capability.
7. Optimize Corner Design
Set up a guard ring around the analog circuit, and if necessary, ground it separately or connect it to the power supply voltage to enhance anti-interference capability.
8. Separate Power and Ground Lines
Power and ground lines between the chip and digital-analog signals should be designed independently to reduce mutual interference and improve power stability.
9. High-Frequency Signal Isolation
Power and ground lines between the chip and digital-analog signals should be designed independently to reduce mutual interference and improve power stability.
10. Shape Optimization
Power and ground lines between the chip and digital-analog signals should be designed independently to reduce mutual interference and improve power stability.
11. Inter-layer Planning
Power and ground lines between the chip and digital-analog signals should be designed independently to reduce mutual interference and improve power stability.
12. Thermal Management
For areas with high power consumption, route lines reasonably to reduce heat concentration, and add heat dissipation structures if necessary to ensure that the chip temperature is maintained within a reasonable range.
