1 Overview
Extended Kalman Filter SLAM Path Planning
Extended Kalman Filter (EKF) SLAM is an algorithm used for Simultaneous Localization and Mapping (SLAM). The principles and processes are as follows: 1 Initialization: Initially, the robot’s starting position is assumed to be known, but the map is empty. 2 Motion Model: By using the robot’s control inputs (such as speed and angle), the motion model predicts the robot’s position at the next time step. 3 Observation Model: The robot uses sensors (such as LiDAR or cameras) to observe the surrounding environment and extract the positions of feature points (such as landmark points). 4 Data Association: By matching the robot’s observation data with known landmark points on the map, it determines which landmark points are new and which are known. 5 EKF Filtering: Based on the robot’s observation data and the predictions from the motion model, the EKF filtering algorithm is used to estimate the robot’s current state (position and orientation). 6 Map Update: New landmark points are added to the map, and the positions of known landmark points are updated. 7 Path Planning: Based on the current map and the robot’s target position, path planning algorithms (such as A* algorithm) are used to generate the robot’s action path. 8 Repeat Steps 2-7: Steps 2-7 are repeatedly executed, continuously updating the robot’s position estimates and the map until the target position is reached or the process ends. Overall, the Extended Kalman Filter SLAM combines the robot’s motion model and observation model, using filtering algorithms to simultaneously localize the robot and build the map. By continuously updating the robot’s position estimates and the map, accurate path planning and navigation can be achieved.
2 Some Code and Running Steps
(1) Directly run main.m to generate the graph with one click
3Running Results
3Running Results
4Matlab Version and References
1 Matlab Version
2019b
2 References
[1] Sun Haibo, Tong Ziyuan, Tang Shoufeng, Tong Mingming, Ji Yuming. A Review of SLAM Research Based on Kalman Filtering and Particle Filtering[J]. Software Guide. 2018
3 Note
This part is excerpted from the Internet for reference only. If there is any infringement, please contact for deletion
5 Code Acquisition Method
Code Acquisition Method: Method for obtaining Matlab Poseidon Code
