1. Low Power Design
With the promotion of handheld portable devices, the issue of low power design has become increasingly important. Lower chip power consumption means longer usage time for handheld portable devices, reduced power consumption extends the lifespan of chips, controls heat dissipation issues, and allows devices to be smaller, among other benefits. Low power design is a holistic concept, meaning that power consumption can be optimized at every design level—algorithm level optimization, RTL code optimization, gate-level netlist optimization, layout optimization, and so on. Moreover, the higher the abstraction level, the greater the degree of power optimization; for example, algorithm level optimization can reduce power consumption by over 70%, while layout optimization might only achieve about 10% optimization.
There are many methods for low power design, which can be roughly divided into the following categories based on the author’s understanding: a. Multi-threshold technology method: different circuit modules use basic gate-level circuits with different thresholds; b. Power gating: controlling the power of a part of the circuit through special logic gates, activating the circuit’s power only when needed to reduce power consumption; c. Multi-voltage domains: different areas of circuit modules use different supply voltages; for instance, high-frequency circuits use high voltage, while low-frequency circuits use low voltage; d. Gated clocks: using logic gates to control the stopping or starting of module clocks, gated clocks can be directly inserted through DC commands; e. Operand separation; f. Gate-level circuit optimization; g. Layout optimization; and so on. For ASIC designers, the optimization methods vary depending on different job positions. a-c are optimization methods for system-level designers, d-f are for RTL and gate-level designers, and g is an analytical method that layout personnel can master. These concepts are too broad, and without personally participating in a project that applies this low power technology, it is difficult to have a deep understanding; for ASIC designers, it is challenging to comprehensively grasp these low power technologies.
In the books recommended by the author, there are power optimization processes based on Power Compiler (part of DC) and PTPX (Prime Time-PX) software. The theoretical learning generally requires mastering the types of power consumption, which are: 1. Static power consumption – leakage power, 2. Dynamic power consumption – switching power, transition power, with total power consumption equal to the sum of these three types of power. How does the software analyze these three types of power? The answer is still the technology library. In the synthesis library .lib file, many parameters relate to these three types of power, as shown below.
Leakage power of a certain cell:
cell_leakage_power : 330.503175;
leakage_power() {
when :”!A & !B & !CI”;
value : 318.529800;
}
leakage_power() {
when :”!A & !B & CI”;
value : 375.946200;
}
leakage_power() {
when :”!A & B & !CI”;
value : 347.668200;
}
leakage_power() {
when :”!A & B & CI”;
value : 309.481200;
}
leakage_power() {
when :”A & !B & !CI”;
value : 312.384600;
}
leakage_power() {
when :”A & !B & CI”;
value : 352.481400;
}
leakage_power() {
when :”A & B & !CI”;
value : 324.199800;
}
leakage_power() {
when :”A & B & CI”;
value : 303.334200;
}
Internal power under certain conditions (!A & B) | (A & !B), rising edge, falling edge power:
internal_power() {
related_pin : “CI”;
equal_or_opposite_output : “CO”;
when : “(!A & B) | (A & !B)”;
rise_power(energy_template_7x3x3) {
index_1 (“0.03, 0.1, 0.4, 0.9, 1.5, 2.2, 3”);
index_2 (“0.00035, 0.0385, 0.3115”);
index_3 (“0.00035, 0.0385, 0.3115”);
values ( \\
“0.067236, 0.068853, 0.068513”, “0.071757, 0.070275, 0.070806”, “0.080913, 0.079223, 0.078953”, \\
“0.067380, 0.068914, 0.068524”, “0.071910, 0.070393, 0.070843”, “0.081073, 0.079343, 0.079093”, \\
“0.072993, 0.073749, 0.073240”, “0.077639, 0.075163, 0.075587”, “0.086943, 0.084212, 0.084302”, \\
“0.088698, 0.085346, 0.084064”, “0.090733, 0.087112, 0.086360”, “0.100492, 0.096672, 0.095842”, \\
“0.104666, 0.099420, 0.097897”, “0.105970, 0.100660, 0.100035”, “0.115422, 0.109742, 0.108342”, \\
“0.123420, 0.117165, 0.114921”, “0.125151, 0.118985, 0.116790”, “0.133612, 0.127112, 0.125132”, \\
“0.145380, 0.138042, 0.134921”, “0.147057, 0.139940, 0.136555”, “0.155522, 0.148222, 0.145332”);
}
fall_power(energy_template_7x3x3) {
index_1 (“0.03, 0.1, 0.4, 0.9, 1.5, 2.2, 3”);
index_2 (“0.00035, 0.0385, 0.3115”);
index_3 (“0.00035, 0.0385, 0.3115”);
values ( \\
“0.050492, 0.055945, 0.064903”, “0.053891, 0.055156, 0.063903”, “0.053922, 0.056074, 0.063853”, \\
“0.050468, 0.055859, 0.064843”, “0.053846, 0.055057, 0.063833”, “0.053880, 0.056027, 0.063783”, \\
“0.055162, 0.059927, 0.068953”, “0.058462, 0.058987, 0.067812”, “0.058500, 0.059918, 0.067832”, \\
“0.071414, 0.070694, 0.079333”, “0.069997, 0.069600, 0.078113”, “0.069993, 0.070503, 0.078113”, \\
“0.087095, 0.085894, 0.093292”, “0.085467, 0.084469, 0.091692”, “0.085322, 0.084670, 0.091722”, \\
“0.105947, 0.103948, 0.110322”, “0.104070, 0.102399, 0.108522”, “0.103914, 0.102131, 0.108572”, \\
“0.127727, 0.124621, 0.130342”, “0.125641, 0.122880, 0.128522”, “0.125412, 0.122591, 0.128302”);
}
}
Information is sourced from the previously provided simc technology library.
For more information on the contents of the synthesis library .lib file, please refer to “Digital IC System Design,” which will not be elaborated here.
This once again verifies what was mentioned in the previous article about the technology library—the synthesis library .lib file is indeed very important. Using software to perform power analysis on RTL code and gate-level netlists requires the involvement of these synthesis libraries to analyze the chip’s power consumption and subsequently optimize it.
2. Recommended Books:
“Practical Tutorial on Application-Specific Integrated Circuit Design”
“SoC Design Methods and Implementation”
“Digital IC System Design”
“PTPX User Guide 2016”
3. Tools
During synthesis, preliminary optimization of the generated gate-level netlist can be performed using the built-in program Power Compiler in DC, which activates the power optimization function through relevant commands. For examples of using this tool, please refer to “Practical Tutorial on Application-Specific Integrated Circuit Design.”
Gate-level netlist optimization tool, PrimeTime PX. For examples of using this tool, please refer to “PTPX User Guide 2016.”
4. Examples
As low power related technologies have not been utilized yet, the understanding of the low power analysis process based on Power Compiler (part of DC) and PTPX (Prime Time-PX) software is limited and will be filled in later.
