“Why can other people’s networks access the internet scientifically, filter ads, and control devices globally?”
The answer may not lie in the speed of the internet itself, but in whether your router is smart enough.
This article will guide you step by step on how to upgrade an ordinary home router into a smart soft router hub using OpenWrt, enabling advanced network management, smart home integration, network acceleration, and privacy protection.
🧠 What is OpenWrt? How is it stronger than the factory firmware?
OpenWrt is an open-source Linux system designed for routers. It is not a “trimmed down system” from manufacturers, but a complete customizable embedded operating system.
✅ Compared to factory firmware, the advantages of OpenWrt are:
|
Functionality |
Factory Firmware |
OpenWrt |
|
Plugin Extension Capability |
❌ Extremely limited |
✅ Free to install plugins |
|
Multi-connection / Load Balancing Support |
❌ Supported by few models |
✅ Supports multiple solutions |
|
Ad Filtering, Home Firewall |
❌ None or rudimentary |
✅ AdGuardHome, etc. |
|
Scientific Internet Access / Traffic Management |
❌ Not supported |
✅ SSR+/PassWall |
|
QOS Traffic Control, Bandwidth Monitoring |
❌ Basic version |
✅ Precise to each device |
|
NAS / Docker / Virtual Machine Support |
❌ Not supported at all |
✅ High-end hardware can run |
📦 1. Preparation: Can your router be flashed?
🔍 Router Compatibility Check
✅ Recommended Hardware Selection:
|
Category |
Example Device Models |
Notes |
|
Entry-level Flashing Models |
Xiaomi Router 3G / 4A Gigabit Version / Newifi D2 |
Many mature community firmware, low cost |
|
Mid-range Soft Routers |
Intel N5105 / J4125 Motherboard + Dual NIC Mini Host |
Can be used as OpenWrt + Synology all-in-one |
|
All-rounder |
Raspberry Pi 4B + USB NIC / x86 High-performance Soft Router |
Completely free, high performance ceiling |
❗ Flashing carries risks; ensure your device has a recovery plan/TTL interface.
🛠️ 2. Flashing OpenWrt: Taking Xiaomi Router as an Example
📥 Obtaining Firmware
Visit OpenWrt.org or the Enshan Forum
Download the stable version firmware (.bin) corresponding to your model
🔄 Flashing Steps (slightly different for different models):
Log in to the factory backend, enter developer mode or enable SSH
Use scp / WinSCP to upload the OpenWrt firmware to /tmp/
After SSH login, execute:
mtd -r write /tmp/your_firmware.bin firmware
After rebooting the router, access the default address:
http://192.168.1.1 Username: root / Password: (leave blank)
🧩 3. Installing Common Plugins (The Soul of OpenWrt)
🔧 Plugin Management:
Enter the Web management backend LuCI → System → Software Packages
⭐ Recommended Common Useful Plugins:
|
Plugin Name |
Function Description |
|
AdGuardHome |
Ad-blocking tool, supports custom filtering rules |
|
SSR+/PassWall |
Scientific internet access tool, supports traffic splitting and rule updates |
|
SQM / QOS |
Smart speed limiting, ensuring priority for gaming/video |
|
DDNS |
Realizes dynamic public IP domain binding |
|
Samba / NFS |
Local network shared storage support, can connect to hard drives |
|
UPnP / ZeroTier |
Piercing the internal network, remote access to NAS, cameras, and other devices |
|
Docker |
Deploy any lightweight service, such as Home Assistant |
🔐 4. Advanced Play: OpenWrt Gives You Carrier-Level Network Experience
📡 Multi-connection Speed Boost & Bandwidth Aggregation
The multi-connection tool (MWAN3) can achieve “1 broadband connection dialed 3 times”, aggregating bandwidth to improve download speeds (effective in some regions)
🌍 Scientific Internet Access Traffic Splitting
Only allow specific devices (like Apple TV) or websites to go through the proxy, while others connect directly → Save node resources
🎯 Home Traffic Control + Device Speed Limiting
Precise speed control down to device MAC or IP, ensuring the main computer/TV does not lag
Can set sleep periods to disconnect the internet/block internet periods, a tool to prevent addiction
🎞️ Home Audio-Video Center
Router connected to a mobile hard drive + Samba/NFS → Create a lightweight NAS
Used with Kodi / Jellyfin clients for streaming high-definition video
🧱 5. Building the “Brain of the Home Network” with OpenWrt
Once you become familiar with OpenWrt, it is no longer just “router firmware”; it becomes your:
✅ Ad Blocker (AdGuard)
✅ Smart Home Hub (integrating Home Assistant)
✅ Private Cloud Access Point (mapping Synology/Nextcloud)
✅ Remote Access Jump Point (Tailscale / Zerotier)
✅ Anonymous Network Proxy (Tor / Shadowsocks)
✅ IoT Traffic Isolation Firewall (guest/smart device VLAN separation)
Truly achieving a “whole-house network center + privacy control hub”.
📈 Who is suitable for getting into OpenWrt?
🧑💻 Tech enthusiasts who love tinkering with devices
👨👩👧👦 Parents wanting to create a “smart network” for their family
🧳 People who travel frequently/remote workers
🎮 Gamers & audio-visual enthusiasts
🌐 Geeks pursuing privacy and security
✅ In summary: OpenWrt is the key to “intelligentizing cheap routers”
Don’t think that home networking is just about “plugging in to get online”; true network optimization starts with router intelligence. OpenWrt is not just about “flashing a system”; it allows you to achieve carrier-level network experience + data security + smart home control at a very low cost.
