1. Preparations Before Running the Code: Environment and File Configuration
Before executing the code, three key preparations must be completed to avoid failures due to missing configurations:
1. Folder Structure and File Placement
The code relies on specific path model files and ACMI data files, which must be organized in the following structure:
TypeScriptDisable auto line breakCopy
Your working directory/
├─ trajectory_vers2/ # Model folder (must be created manually)
│ └─ 80jet.mat # Aircraft3D model file (must be placed here)
└─ control.txt.acmi # TacvieexportedACMI data file (at the same level as the working directory)
- Model file acquisition:80jet.mat is a 3D model file of a jet aircraft, containing vertex (V), face (F), and color (C) data. If it cannot be obtained, it can be generated in the following ways:
- Create the aircraft model using 3D modeling software like SolidWorks and export it in STL format;
- Use MATLAB’s stlread function to read the STL file, extract vertex and face data, and manually construct V(n×3), F (m×3) matrices, and the color matrix C can be set to a uniform RGB value (e.g., C = ones(n,3)*[0.8,0.2,0.2] represents red).
- ACMI file format verification: Ensure control.txt.acmi contains aircraft position and attitude data, with a typical valid line format as follows:
TypeScriptDisable auto line breakCopy
1,Time=116.4074|39.9042|500|5|0|30,Name=F-16,Color=red
Where “1” is the aircraft ID, and after “Time=” are “Longitude | Latitude | Altitude | Pitch Angle (degrees) | Roll Angle (degrees) | Yaw Angle (degrees)”, followed by name and color.
2. MATLAB Version and Toolbox Dependencies
- Version Requirements: The code uses startsWith, split and other functions, requiring MATLAB 2016b or later (recommended 2017b+, better compatibility);
- Toolbox Dependencies: No additional toolboxes are required, only basic MATLAB functions ( fopen, patch, time r etc.), the default environment can run.
3. Key Parameter Pre-Adjustment
Based on the actual scale of the ACMI data, adjust the “coordinate scaling factor” in the code in advance to avoid overly dense or sparse aircraft trajectories during visualization:
- Latitude and Longitude Scaling:If the latitude and longitude range of the ACMI data is small (e.g., within 1km), reduce x_m and y_m scaling factors (e.g., change 150 to 50, 50 to 20);
- Height Scaling:If the height data unit is “meters” and the range is 0-1000m, z_m = z * 290 may cause excessive height in the vertical direction, it can be adjusted to z_m = z * 0.5;
- Model Scaling:If the 80jet.mat model is too large or too small, modify scale_factor (e.g., change 9000 to 5000 or 12000), ensuring the aircraft model is clearly visible in the 3D view.
