Microcontroller Basics

What is a Microcontroller?

A microcontroller (Microcontroller Unit, MCU) is a compact integrated circuit designed to govern a specific operation in an embedded system. It integrates a CPU, memory, and input/output peripherals, characterized by its small size, low power consumption, low cost, and high reliability, making it widely used in embedded systems.

Basic Components of a Microcontroller

  • CPU: Central Processing Unit, executes instructions
  • Memory: Program memory (Flash), data memory (RAM)
  • Input/Output Interfaces: GPIO, UART, SPI, I2C, etc.
  • Timer: Used for timing and counting
  • Interrupt System: Handles external events
  • ADC/DAC: Analog-to-Digital/Digital-to-Analog Conversion

Common Microcontroller Series

  1. 51 Microcontroller Series

  • Features: Easy to start, abundant resources
  • Representatives: AT89C51, STC89C52
  • Suitable for: Basic learning

  • AVR Series

    • Features: Good performance, moderate price
    • Representatives: ATmega328P, ATmega2560
    • Suitable for: Medium complexity projects

  • ARM Cortex-M Series

    • Features: Powerful performance, rich functionality
    • Representatives: STM32F103, STM32F407
    • Suitable for: Complex projects

  • ESP32 Series

    • Features: Integrated WiFi/Bluetooth
    • Representatives: ESP32-WROOM-32
    • Suitable for: IoT projects

    Development Environment Setup

    Hardware Preparation

    1. Development Board Selection

    • Beginner Recommendation: Arduino Uno or STM32F103C8T6
    • Advanced Recommendation: STM32F407 or ESP32
    • Professional Recommendation: STM32H7 Series

  • Essential Tools

    • USB Data Cable
    • Breadboard and Dupont Wires
    • Common Electronic Components (LEDs, Resistors, Buttons, etc.)
    • Multimeter and Oscilloscope (optional)

    Software Environment

    1. Arduino IDE (Recommended for beginners)

    • Download Link: https://www.arduino.cc/
    • Features: Simple and easy to use, suitable for beginners
    • Supports: Arduino, ESP32, etc.

  • Keil MDK (For STM32 development)

    • Download Link: https://www.keil.com/
    • Features: Powerful, professional-level development
    • Supports: ARM Cortex-M series

  • STM32CubeIDE (Free STM32 development)

    • Download Link: https://www.st.com/
    • Features: Free, fully functional
    • Supports: All STM32 series

  • IAR Embedded Workbench

    • Features: Professional-level development environment
    • Supports: Various MCUs
    • Price: Commercial software

    Environment Configuration Steps

    1. Install Development Software

    • Download and install the selected IDE
    • Configure compiler path
    • Install necessary library files

  • Connect Hardware

    • Connect the development board to the computer via USB
    • Install drivers
    • Confirm device recognition is normal

  • Test Environment

    • Compile a simple program
    • Download to the development board
    • Verify the program runs correctly

    Basic C Language

    Basic Syntax

    // Include header file
#include <stdio.h>

// Main function
int main() {
    // Variable declaration
    int a = 10;
    float b = 3.14;
    char c = 'A';

    // Output statement
    printf("Hello World!\n");

    return 0;
}

    Data Types

    1. Integer

    • <span>char</span>: 8 bits, -128 to 127
    • <span>int</span>: 16 bits or 32 bits
    • <span>long</span>: 32 bits or 64 bits
    • <span>unsigned</span>: Unsigned type

  • Floating Point

    • <span>float</span>: 32-bit floating point
    • <span>double</span>: 64-bit floating point

  • Pointer Types

    • <span>int *p</span>: Integer pointer
    • <span>void *ptr</span>: Generic pointer

    Control Structures

    // if statement
if (condition) {
    // Execute code
} else {
    // Other code
}

// for loop
for (int i = 0; i < 10; i++) {
    // Loop code
}

// while loop
while (condition) {
    // Loop code
}

    Function Definition

    // Function declaration
int add(int a, int b);

// Function definition
int add(int a, int b) {
    return a + b;
}

    Arrays and Pointers

    // Array definition
int array[10];

// Pointer operation
int *ptr = &array[0];
*ptr = 100;  // Assignment

    GPIO Programming

    Basic Concepts of GPIO

    GPIO (General Purpose Input/Output) is a general-purpose input/output interface that can be configured as input or output mode.

    Basic Operations

    // Arduino example
void setup() {
    pinMode(13, OUTPUT);    // Set pin as output
    pinMode(2, INPUT);      // Set pin as input
}

void loop() {
    digitalWrite(13, HIGH); // Output high level
    delay(1000);
    digitalWrite(13, LOW);  // Output low level
    delay(1000);
}

    STM32 GPIO Example

    // STM32 GPIO configuration
void GPIO_Init(void) {
    // Enable GPIOA clock
    RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA, ENABLE);

    // Configure GPIO structure
    GPIO_InitTypeDef GPIO_InitStructure;

    // Configure PA0 as output
    GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0;
    GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP;
    GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;
    GPIO_Init(GPIOA, &GPIO_InitStructure);
}

// GPIO operations
void LED_On(void) {
    GPIO_SetBits(GPIOA, GPIO_Pin_0);
}

void LED_Off(void) {
    GPIO_ResetBits(GPIOA, GPIO_Pin_0);
}

    Button Input

    // Button detection
int buttonPressed(void) {
    if (digitalRead(2) == LOW) {
        delay(20);  // Debounce
        if (digitalRead(2) == LOW) {
            return 1;
        }
    }
    return 0;
}

    Project Practice: LED Control

    // LED blinking program
void setup() {
    pinMode(13, OUTPUT);
    pinMode(2, INPUT_PULLUP);
}

void loop() {
    if (buttonPressed()) {
        digitalWrite(13, !digitalRead(13));  // Toggle LED state
    }
    delay(100);
}

    Timer Applications

    Timer Basics

    Timers are important peripherals in microcontrollers used for timing, counting, and PWM generation.

    Timer Configuration

    // STM32 timer configuration
void Timer_Init(void) {
    // Enable timer clock
    RCC_APB1PeriphClockCmd(RCC_APB1Periph_TIM2, ENABLE);

    // Configure timer
    TIM_TimeBaseInitTypeDef TIM_TimeBaseStructure;
    TIM_TimeBaseStructure.TIM_Period = 999;  // Auto-reload value
    TIM_TimeBaseStructure.TIM_Prescaler = 7199;  // Prescaler value
    TIM_TimeBaseStructure.TIM_ClockDivision = TIM_CKD_DIV1;
    TIM_TimeBaseStructure.TIM_CounterMode = TIM_CounterMode_Up;
    TIM_TimeBaseInit(TIM2, &TIM_TimeBaseStructure);

    // Enable timer
    TIM_Cmd(TIM2, ENABLE);
}

    Timer Interrupts

    // Timer interrupt configuration
void Timer_Interrupt_Init(void) {
    NVIC_InitTypeDef NVIC_InitStructure;

    // Configure NVIC
    NVIC_InitStructure.NVIC_IRQChannel = TIM2_IRQn;
    NVIC_InitStructure.NVIC_IRQChannelPreemptionPriority = 0;
    NVIC_InitStructure.NVIC_IRQChannelSubPriority = 1;
    NVIC_InitStructure.NVIC_IRQChannelCmd = ENABLE;
    NVIC_Init(&NVIC_InitStructure);

    // Enable timer interrupt
    TIM_ITConfig(TIM2, TIM_IT_Update, ENABLE);
}

// Timer interrupt service function
void TIM2_IRQHandler(void) {
    if (TIM_GetITStatus(TIM2, TIM_IT_Update) != RESET) {
        TIM_ClearITPendingBit(TIM2, TIM_IT_Update);

        // Interrupt handling code
        LED_Toggle();
    }
}

    Arduino Timer

    // Arduino timer example
unsigned long previousMillis = 0;
const long interval = 1000;  // 1 second

void loop() {
    unsigned long currentMillis = millis();

    if (currentMillis - previousMillis >= interval) {
        previousMillis = currentMillis;

        // Code to execute at intervals
        digitalWrite(13, !digitalRead(13));
    }
}

    Interrupt System

    Interrupt Basics

    Interrupts are an important mechanism for microcontrollers to respond to external events, allowing timely handling of urgent events.

    External Interrupt Configuration

    // STM32 external interrupt configuration
void EXTI_Init(void) {
    // Enable AFIO clock
    RCC_APB2PeriphClockCmd(RCC_APB2Periph_AFIO, ENABLE);

    // Configure GPIO as input
    GPIO_InitTypeDef GPIO_InitStructure;
    GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0;
    GPIO_InitStructure.GPIO_Mode = GPIO_Mode_IPU;
    GPIO_Init(GPIOA, &GPIO_InitStructure);

    // Configure external interrupt
    GPIO_EXTILineConfig(GPIO_PortSourceGPIOA, GPIO_PinSource0);

    EXTI_InitTypeDef EXTI_InitStructure;
    EXTI_InitStructure.EXTI_Line = EXTI_Line0;
    EXTI_InitStructure.EXTI_Mode = EXTI_Mode_Interrupt;
    EXTI_InitStructure.EXTI_Trigger = EXTI_Trigger_Falling;
    EXTI_InitStructure.EXTI_LineCmd = ENABLE;
    EXTI_Init(&EXTI_InitStructure);

    // Configure NVIC
    NVIC_InitTypeDef NVIC_InitStructure;
    NVIC_InitStructure.NVIC_IRQChannel = EXTI0_IRQn;
    NVIC_InitStructure.NVIC_IRQChannelPreemptionPriority = 0;
    NVIC_InitStructure.NVIC_IRQChannelSubPriority = 0;
    NVIC_InitStructure.NVIC_IRQChannelCmd = ENABLE;
    NVIC_Init(&NVIC_InitStructure);
}

// External interrupt service function
void EXTI0_IRQHandler(void) {
    if (EXTI_GetITStatus(EXTI_Line0) != RESET) {
        EXTI_ClearITPendingBit(EXTI_Line0);

        // Interrupt handling code
        LED_Toggle();
    }
}

    Arduino Interrupt

    // Arduino interrupt example
void setup() {
    pinMode(13, OUTPUT);
    pinMode(2, INPUT_PULLUP);

    // Configure external interrupt
    attachInterrupt(digitalPinToInterrupt(2), buttonISR, FALLING);
}

void loop() {
    // Main loop code
}

// Interrupt service function
void buttonISR() {
    digitalWrite(13, !digitalRead(13));
}

    Serial Communication

    Serial Basics

    Serial communication (UART) is an important interface for microcontrollers to communicate with external devices.

    Serial Configuration

    // STM32 serial configuration
void UART_Init(void) {
    // Enable GPIO and UART clock
    RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA, ENABLE);
    RCC_APB1PeriphClockCmd(RCC_APB1Periph_USART2, ENABLE);

    // Configure GPIO
    GPIO_InitTypeDef GPIO_InitStructure;
    GPIO_InitStructure.GPIO_Pin = GPIO_Pin_2;  // TX
    GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP;
    GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;
    GPIO_Init(GPIOA, &GPIO_InitStructure);

    GPIO_InitStructure.GPIO_Pin = GPIO_Pin_3;  // RX
    GPIO_InitStructure.GPIO_Mode = GPIO_Mode_IN_FLOATING;
    GPIO_Init(GPIOA, &GPIO_InitStructure);

    // Configure UART
    USART_InitTypeDef USART_InitStructure;
    USART_InitStructure.USART_BaudRate = 115200;
    USART_InitStructure.USART_WordLength = USART_WordLength_8b;
    USART_InitStructure.USART_StopBits = USART_StopBits_1;
    USART_InitStructure.USART_Parity = USART_Parity_No;
    USART_InitStructure.USART_HardwareFlowControl = USART_HardwareFlowControl_None;
    USART_InitStructure.USART_Mode = USART_Mode_Rx | USART_Mode_Tx;
    USART_Init(USART2, &USART_InitStructure);

    USART_Cmd(USART2, ENABLE);
}

// Send data
void UART_SendByte(uint8_t data) {
    while (USART_GetFlagStatus(USART2, USART_FLAG_TXE) == RESET);
    USART_SendData(USART2, data);
}

// Receive data
uint8_t UART_ReceiveByte(void) {
    while (USART_GetFlagStatus(USART2, USART_FLAG_RXNE) == RESET);
    return USART_ReceiveData(USART2);
}

    Arduino Serial

    // Arduino serial example
void setup() {
    Serial.begin(115200);
    Serial.println("Hello World!");
}

void loop() {
    if (Serial.available()) {
        char c = Serial.read();
        Serial.print("Received: ");
        Serial.println(c);
    }
    delay(100);
}

    Serial Communication Project

    // Serial control LED
void setup() {
    Serial.begin(115200);
    pinMode(13, OUTPUT);
}

void loop() {
    if (Serial.available()) {
        char command = Serial.read();

        switch (command) {
            case '1':
                digitalWrite(13, HIGH);
                Serial.println("LED ON");
                break;
            case '0':
                digitalWrite(13, LOW);
                Serial.println("LED OFF");
                break;
        }
    }
}

    ADC Applications

    ADC Basics

    ADC (Analog-to-Digital Converter) converts analog signals into digital signals.

    ADC Configuration

    // STM32 ADC configuration
void ADC_Init(void) {
    // Enable ADC clock
    RCC_APB2PeriphClockCmd(RCC_APB2Periph_ADC1, ENABLE);

    // Configure GPIO
    GPIO_InitTypeDef GPIO_InitStructure;
    GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0;
    GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AIN;
    GPIO_Init(GPIOA, &GPIO_InitStructure);

    // Configure ADC
    ADC_InitTypeDef ADC_InitStructure;
    ADC_InitStructure.ADC_Mode = ADC_Mode_Independent;
    ADC_InitStructure.ADC_ScanConvMode = DISABLE;
    ADC_InitStructure.ADC_ContinuousConvMode = DISABLE;
    ADC_InitStructure.ADC_ExternalTrigConv = ADC_ExternalTrigConv_None;
    ADC_InitStructure.ADC_DataAlign = ADC_DataAlign_Right;
    ADC_InitStructure.ADC_NbrOfChannel = 1;
    ADC_Init(ADC1, &ADC_InitStructure);

    // Configure ADC channel
    ADC_RegularChannelConfig(ADC1, ADC_Channel_0, 1, ADC_SampleTime_7Cycles5);

    // Enable ADC
    ADC_Cmd(ADC1, ENABLE);

    // ADC calibration
    ADC_StartCalibration(ADC1);
    while (ADC_GetCalibrationStatus(ADC1));
}

// ADC read
uint16_t ADC_Read(void) {
    ADC_SoftwareStartConvCmd(ADC1, ENABLE);
    while (!ADC_GetFlagStatus(ADC1, ADC_FLAG_EOC));
    return ADC_GetConversionValue(ADC1);
}

    Arduino ADC

    // Arduino ADC example
void setup() {
    Serial.begin(115200);
}

void loop() {
    int sensorValue = analogRead(A0);
    float voltage = sensorValue * (5.0 / 1023.0);

    Serial.print("ADC Value: ");
    Serial.print(sensorValue);
    Serial.print(", Voltage: ");
    Serial.println(voltage);

    delay(1000);
}

    Temperature Sensor Project

    // LM35 temperature sensor
void setup() {
    Serial.begin(115200);
}

void loop() {
    int sensorValue = analogRead(A0);
    float voltage = sensorValue * (5.0 / 1023.0);
    float temperature = voltage * 100;  // LM35: 10mV/°C

    Serial.print("Temperature: ");
    Serial.print(temperature);
    Serial.println(" °C");

    delay(1000);
}

    PWM Control

    PWM Basics

    PWM (Pulse Width Modulation) is used to control motors, LED brightness, etc.

    PWM Configuration

    // STM32 PWM configuration
void PWM_Init(void) {
    // Enable clock
    RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA, ENABLE);
    RCC_APB1PeriphClockCmd(RCC_APB1Periph_TIM2, ENABLE);

    // Configure GPIO
    GPIO_InitTypeDef GPIO_InitStructure;
    GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0;
    GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP;
    GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;
    GPIO_Init(GPIOA, &GPIO_InitStructure);

    // Configure timer
    TIM_TimeBaseInitTypeDef TIM_TimeBaseStructure;
    TIM_TimeBaseStructure.TIM_Period = 999;
    TIM_TimeBaseStructure.TIM_Prescaler = 71;
    TIM_TimeBaseStructure.TIM_ClockDivision = TIM_CKD_DIV1;
    TIM_TimeBaseStructure.TIM_CounterMode = TIM_CounterMode_Up;
    TIM_TimeBaseInit(TIM2, &TIM_TimeBaseStructure);

    // Configure PWM
    TIM_OCInitTypeDef TIM_OCInitStructure;
    TIM_OCInitStructure.TIM_OCMode = TIM_OCMode_PWM1;
    TIM_OCInitStructure.TIM_OutputState = TIM_OutputState_Enable;
    TIM_OCInitStructure.TIM_Pulse = 500;  // 50% duty cycle
    TIM_OCInitStructure.TIM_OCPolarity = TIM_OCPolarity_High;
    TIM_OC1Init(TIM2, &TIM_OCInitStructure);

    TIM_OC1PreloadConfig(TIM2, TIM_OCPreload_Enable);
    TIM_Cmd(TIM2, ENABLE);
}

// Set PWM duty cycle
void PWM_SetDuty(uint16_t duty) {
    TIM_SetCompare1(TIM2, duty);
}

    Arduino PWM

    // Arduino PWM example
void setup() {
    pinMode(9, OUTPUT);
}

void loop() {
    // Fade in
    for (int i = 0; i <= 255; i++) {
        analogWrite(9, i);
        delay(10);
    }

    // Fade out
    for (int i = 255; i >= 0; i--) {
        analogWrite(9, i);
        delay(10);
    }
}

    Servo Control

    // Servo control example
#include <Servo.h>

Servo myservo;

void setup() {
    myservo.attach(9);
}

void loop() {
    myservo.write(0);    // 0 degrees
    delay(1000);
    myservo.write(90);   // 90 degrees
    delay(1000);
    myservo.write(180);  // 180 degrees
    delay(1000);
}

    Sensor Interfaces

    Common Sensors

    1. Temperature Sensors: DS18B20, LM35, DHT11
    2. Humidity Sensors: DHT11, DHT22
    3. Distance Sensors: HC-SR04 Ultrasonic
    4. Accelerometer Sensors: MPU6050
    5. Light Sensors: Photoresistor

    DS18B20 Temperature Sensor

    #include <OneWire.h>
#include <DallasTemperature.h>

OneWire oneWire(2);
DallasTemperature sensors(&oneWire);

void setup() {
    Serial.begin(115200);
    sensors.begin();
}

void loop() {
    sensors.requestTemperatures();
    float temperature = sensors.getTempCByIndex(0);

    Serial.print("Temperature: ");
    Serial.print(temperature);
    Serial.println(" °C");

    delay(1000);
}

    HC-SR04 Ultrasonic Sensor

    const int trigPin = 9;
const int echoPin = 10;

void setup() {
    Serial.begin(115200);
    pinMode(trigPin, OUTPUT);
    pinMode(echoPin, INPUT);
}

void loop() {
    // Send ultrasonic wave
    digitalWrite(trigPin, LOW);
    delayMicroseconds(2);
    digitalWrite(trigPin, HIGH);
    delayMicroseconds(10);
    digitalWrite(trigPin, LOW);

    // Read echo time
    long duration = pulseIn(echoPin, HIGH);

    // Calculate distance
    float distance = duration * 0.034 / 2;

    Serial.print("Distance: ");
    Serial.print(distance);
    Serial.println(" cm");

    delay(1000);
}

    MPU6050 Accelerometer Sensor

    #include <Wire.h>

const int MPU_ADDR = 0x68;

void setup() {
    Wire.begin();
    Serial.begin(115200);

    // Initialize MPU6050
    Wire.beginTransmission(MPU_ADDR);
    Wire.write(0x6B);
    Wire.write(0);
    Wire.endTransmission(true);
}

void loop() {
    Wire.beginTransmission(MPU_ADDR);
    Wire.write(0x3B);
    Wire.endTransmission(false);
    Wire.requestFrom(MPU_ADDR, 6, true);

    int16_t AcX = Wire.read() << 8 | Wire.read();
    int16_t AcY = Wire.read() << 8 | Wire.read();
    int16_t AcZ = Wire.read() << 8 | Wire.read();

    Serial.print("AcX: "); Serial.print(AcX);
    Serial.print(" | AcY: "); Serial.print(AcY);
    Serial.print(" | AcZ: "); Serial.println(AcZ);

    delay(1000);
}

    Comprehensive Projects

    Project 1: Smart Temperature Monitoring System

    #include <DallasTemperature.h>
#include <LiquidCrystal.h>

OneWire oneWire(2);
DallasTemperature sensors(&oneWire);
LiquidCrystal lcd(12, 11, 5, 4, 3, 2);

const int ledPin = 13;
const int buzzerPin = 8;
const float tempThreshold = 30.0;

void setup() {
    Serial.begin(115200);
    sensors.begin();
    lcd.begin(16, 2);
    pinMode(ledPin, OUTPUT);
    pinMode(buzzerPin, OUTPUT);
}

void loop() {
    sensors.requestTemperatures();
    float temperature = sensors.getTempCByIndex(0);

    // Display temperature
    lcd.setCursor(0, 0);
    lcd.print("Temp: ");
    lcd.print(temperature);
    lcd.print("C");

    // Temperature alarm
    if (temperature > tempThreshold) {
        digitalWrite(ledPin, HIGH);
        tone(buzzerPin, 1000);
        lcd.setCursor(0, 1);
        lcd.print("ALARM!");
    } else {
        digitalWrite(ledPin, LOW);
        noTone(buzzerPin);
        lcd.setCursor(0, 1);
        lcd.print("Normal");
    }

    Serial.print("Temperature: ");
    Serial.println(temperature);

    delay(1000);
}

    Project 2: Smart Car

    // Motor control pins
const int leftMotor1 = 5;
const int leftMotor2 = 6;
const int rightMotor1 = 9;
const int rightMotor2 = 10;

// Ultrasonic sensor
const int trigPin = 7;
const int echoPin = 8;

void setup() {
    pinMode(leftMotor1, OUTPUT);
    pinMode(leftMotor2, OUTPUT);
    pinMode(rightMotor1, OUTPUT);
    pinMode(rightMotor2, OUTPUT);
    pinMode(trigPin, OUTPUT);
    pinMode(echoPin, INPUT);
    Serial.begin(115200);
}

void loop() {
    float distance = getDistance();

    if (distance < 20) {
        // Obstacle detected, stop and turn
        stop();
        turnRight();
        delay(500);
    } else {
        // Move forward
        forward();
    }

    delay(100);
}

void forward() {
    analogWrite(leftMotor1, 200);
    analogWrite(leftMotor2, 0);
    analogWrite(rightMotor1, 200);
    analogWrite(rightMotor2, 0);
}

void backward() {
    analogWrite(leftMotor1, 0);
    analogWrite(leftMotor2, 200);
    analogWrite(rightMotor1, 0);
    analogWrite(rightMotor2, 200);
}

void turnLeft() {
    analogWrite(leftMotor1, 0);
    analogWrite(leftMotor2, 200);
    analogWrite(rightMotor1, 200);
    analogWrite(rightMotor2, 0);
}

void turnRight() {
    analogWrite(leftMotor1, 200);
    analogWrite(leftMotor2, 0);
    analogWrite(rightMotor1, 0);
    analogWrite(rightMotor2, 200);
}

void stop() {
    analogWrite(leftMotor1, 0);
    analogWrite(leftMotor2, 0);
    analogWrite(rightMotor1, 0);
    analogWrite(rightMotor2, 0);
}

float getDistance() {
    digitalWrite(trigPin, LOW);
    delayMicroseconds(2);
    digitalWrite(trigPin, HIGH);
    delayMicroseconds(10);
    digitalWrite(trigPin, LOW);

    long duration = pulseIn(echoPin, HIGH);
    return duration * 0.034 / 2;
}

    Project 3: IoT Data Collection

    #include <WiFi.h>
#include <HTTPClient.h>
#include <DHT.h>

const char* ssid = "YourWiFi";
const char* password = "YourPassword";
const char* serverUrl = "http://your-server.com/api/data";

#define DHTPIN 4
#define DHTTYPE DHT11
DHT dht(DHTPIN, DHTTYPE);

void setup() {
    Serial.begin(115200);
    dht.begin();

    // Connect to WiFi
    WiFi.begin(ssid, password);
    while (WiFi.status() != WL_CONNECTED) {
        delay(1000);
        Serial.println("Connecting to WiFi...");
    }
    Serial.println("WiFi connected");
}

void loop() {
    float temperature = dht.readTemperature();
    float humidity = dht.readHumidity();

    if (WiFi.status() == WL_CONNECTED) {
        HTTPClient http;
        http.begin(serverUrl);
        http.addHeader("Content-Type", "application/json");

        String jsonData = "{\"temperature\":" + String(temperature) + ",\"humidity\":" + String(humidity) + "}";

        int httpResponseCode = http.POST(jsonData);

        if (httpResponseCode > 0) {
            Serial.println("Data sent successfully");
        } else {
            Serial.println("Error sending data");
        }

        http.end();
    }

    Serial.print("Temperature: ");
    Serial.print(temperature);
    Serial.print("°C, Humidity: ");
    Serial.print(humidity);
    Serial.println("%\n");

    delay(5000);  // Send data every 5 seconds
}

    Advanced Technologies

    RTOS Applications

    #include <FreeRTOS.h>
#include <task.h>

// Task 1: LED control
void LEDTask(void *pvParameters) {
    while (1) {
        digitalWrite(13, HIGH);
        vTaskDelay(1000 / portTICK_PERIOD_MS);
        digitalWrite(13, LOW);
        vTaskDelay(1000 / portTICK_PERIOD_MS);
    }
}

// Task 2: Sensor reading
void SensorTask(void *pvParameters) {
    while (1) {
        float temperature = dht.readTemperature();
        Serial.print("Temperature: ");
        Serial.println(temperature);
        vTaskDelay(2000 / portTICK_PERIOD_MS);
    }
}

void setup() {
    Serial.begin(115200);
    pinMode(13, OUTPUT);
    dht.begin();

    // Create tasks
    xTaskCreate(LEDTask, "LED", 1000, NULL, 1, NULL);
    xTaskCreate(SensorTask, "Sensor", 1000, NULL, 1, NULL);
}

void loop() {
    // Empty loop, tasks are scheduled by RTOS
}

    Low Power Design

    #include <avr/sleep.h>
#include <avr/power.h>

void setup() {
    Serial.begin(115200);
    pinMode(2, INPUT_PULLUP);

    // Configure external interrupt
    attachInterrupt(digitalPinToInterrupt(2), wakeUp, FALLING);
}

void loop() {
    Serial.println("Going to sleep...");
    delay(1000);

    // Enter sleep mode
    set_sleep_mode(SLEEP_MODE_PWR_DOWN);
    sleep_enable();
    sleep_mode();

    // Continue execution after waking up
    sleep_disable();
    Serial.println("Woke up!");
}

void wakeUp() {
    // Interrupt wake-up handling
}

    Firmware Upgrade

    #include <Update.h>

void setup() {
    Serial.begin(115200);

    // Check for firmware updates
    if (checkForUpdate()) {
        performUpdate();
    }
}

bool checkForUpdate() {
    // Check if there is new firmware on the server
    HTTPClient http;
    http.begin("http://your-server.com/firmware");
    int httpCode = http.GET();

    if (httpCode == HTTP_CODE_OK) {
        return true;
    }
    return false;
}

void performUpdate() {
    HTTPClient http;
    http.begin("http://your-server.com/firmware");
    int httpCode = http.GET();

    if (httpCode == HTTP_CODE_OK) {
        int contentLength = http.getSize();

        if (Update.begin(contentLength)) {
            size_t written = Update.writeStream(http.getStream());

            if (written == contentLength) {
                if (Update.end()) {
                    Serial.println("Update successful");
                    ESP.restart();
                }
            }
        }
    }
}

    Learning Suggestions

    Learning Path

    1. Basic Stage: Master basic C language, familiarize with GPIO operations
    2. Intermediate Stage: Learn about timers, interrupts, and serial communication
    3. Application Stage: Master ADC, PWM, and sensor interfaces
    4. Project Stage: Complete comprehensive projects, accumulate practical experience
    5. Professional Stage: Learn about RTOS, low power design, and firmware upgrades

    Practical Suggestions

    1. Hands-On Practice: Timely practice after theoretical learning
    2. Project-Driven: Learn relevant skills through projects
    3. Problem-Oriented: Look for solutions promptly when encountering problems
    4. Continuous Learning: Stay updated with new technologies and trends

    Recommended Resources

    1. Official Documentation: Technical documents provided by manufacturers
    2. Online Tutorials: Official tutorials for Arduino, STM32, etc.
    3. Technical Forums: Electronics enthusiasts, 21ic, etc.
    4. Open Source Projects: Open source projects on GitHub

    END

    Follow Stephen, learn together, and grow together.

    Click “” to support.

    Leave a Comment
