Key Considerations for PCBA Repair

As an important component of electronic devices, the repair process of PCBA needs to strictly adhere to a series of technical specifications and operational requirements to ensure the quality of the repair and the stability of the equipment. This article will explore various key points that need to be considered during the PCBA repair process, hoping to assist our friends.

1. Baking RequirementsDuring the PCBA repair process, baking treatment is very important. First, for new components to be installed, they must be baked and dehumidified according to their moisture sensitivity level and storage conditions, in accordance with the relevant requirements in the “Moisture Sensitive Components Usage Specification”. This can effectively remove moisture from the components and avoid issues such as cracks and bubbles during the soldering process. Secondly, if the repair process requires heating to above 110℃, or if there are other moisture-sensitive components around the repair area, baking and dehumidification treatment must also be performed as per the specifications to prevent damage to the components from high temperatures and ensure the smooth progress of the repair process. Finally, for moisture-sensitive components that need to be reused after repair, if the repair process uses hot air reflow, infrared, or similar heating methods for solder joints, they also need to undergo baking and dehumidification treatment; if a manual soldering iron is used for heating solder joints, the pre-baking step can be omitted provided that the heating process is controlled.

2. Storage Environment RequirementsAfter baking treatment, the storage environment of moisture-sensitive components and PCBA must also be noted. If the storage conditions exceed the time limit, these components and PCBA boards must be re-baked to ensure good performance and stability during use. Therefore, during the repair process, it is essential to closely monitor the temperature, humidity, and other parameters of the storage environment to ensure compliance with the specifications, and also regularly check the baking to prevent potential quality issues.

3. Repair Heating Frequency RequirementsAccording to the specifications, the cumulative heating frequency for component repairs should not exceed 4 times, the allowable heating frequency for new components should not exceed 5 times, and the allowable heating frequency for reused components should not exceed 3 times. These limits are to ensure that components and PCBA are not excessively damaged during multiple heating processes, affecting their performance and reliability. Therefore, the heating frequency must be strictly controlled during the repair process. Additionally, for components and PCBA boards that are close to or have exceeded the heating frequency limit, their quality status should be cautiously evaluated to avoid using them in critical areas or high-reliability equipment.
