How to Achieve Sequential Control with PLC? A Beginner’s Guide

In industrial automation, sequential control is a very common task, such as product assembly on an assembly line or multi-step operation control of packaging machines. Today we will discuss how to achieve sequential control using PLC, guiding you step by step from concepts to practical cases to master this skill.

1.

What is Sequential Control?

In simple terms, sequential control refers to executing a series of actions in a specific order, such as the switching of traffic lights: Red light on → Red light off, Yellow light on → Yellow light off, Green light on, where each step needs to switch according to a predetermined logic.

In PLC, we can use relay output coils, timers, and counters to achieve sequential control. Each “step” can be seen as a state, and the PLC determines whether to proceed to the next step by monitoring input signals (such as buttons and sensors).

2.

Basic Concept Explanation

Before we begin, we need to understand a few key points:

1. State Switching

   : Sequential control in PLC is completed by switching between states. For example, after completing state 1, it moves to state 2.
2. Trigger Conditions

   : Each state transition needs to meet specific conditions, such as pressing a button or timers expiring.
3. Memory Function

   : The PLC needs to “remember” the current state to continue operation.

Analogy Understanding

You can think of sequential control as the steps to cook instant noodles:

1. Boil water (State 1).
2. Add noodle cake after the water boils (State 2).
3. Wait for 3 minutes (State 3).
4. Add seasoning and serve (State 4).

Each step has a trigger condition, such as water boiling or the 3-minute timer completing.

3.

Hardware Circuit Diagram

Example: Hardware Wiring for Three-Step Sequential Control

Assuming we want to implement a simple three-step sequential control, with an input of a start button (X0) and a stop button (X1), and outputs for three indicator lights (Y0, Y1, Y2), representing state 1, state 2, and state 3 respectively.

• X0

  : Start button
• X1

  : Stop button
• Y0

  : First state indicator light
• Y1

  : Second state indicator light
• Y2

  : Third state indicator light

Wiring diagram:

X0 (Start Button) ------ PLC Input Point X0
X1 (Stop Button) ------ PLC Input Point X1
Y0 (State 1 Light) ------- PLC Output Point Y0
Y1 (State 2 Light) ------- PLC Output Point Y1
Y2 (State 3 Light) ------- PLC Output Point Y2

Notes:

• Pay attention to using normally open (NO) or normally closed (NC) contacts for button wiring, depending on actual needs.
• The output load (indicator lights) current should not exceed the rated current of the PLC output points.

4.

Ladder Diagram Example

The following is a ladder diagram using three-step sequential control:

| Input/Trigger Condition | Output |
-----------------------
| X0                    | Y0   |
| Y0 + T1               | Y1   |
| Y1 + T2               | Y2   |

Specific code explanation is as follows:

1. Start button controls the first state (Y0):

* When the start button (X0) is pressed, Y0 outputs to start, and indicator light 1 turns on.

1. The first state controls the second state (Y1):

* After Y0 outputs, start timer T1 (for example, 3 seconds), and when the time is up, switch to Y1, and indicator light 2 turns on.

1. The second state controls the third state (Y2):

* Similarly, after Y1 outputs, start timer T2 (for example, 5 seconds), and when the time is up, switch to Y2, and indicator light 3 turns on.

5.

Practical Application Case

Case Study: Sequential Control of an Automatic Filling System

Assuming an automatic filling system needs the following operations:

1. Press the start button to activate the water pump (State 1).
2. After filling is complete (detected by a level sensor), turn off the water pump and start the mixer (State 2).
3. After mixing is complete (controlled by a timer), open the drainage valve (State 3).

Implementation logic:

• Input signals: Start button (X0), Level sensor (X1).
• Output signals: Water pump (Y0), Mixer (Y1), Drain valve (Y2).

Ladder diagram implementation:

1. X0 → Y0 (Water pump running).
2. X1 (Full signal) + Y0 → Y1 (Mixer starts).
3. T1 (Mixing time up) + Y1 → Y2 (Drain valve opens).

6.

Common Problems and Solutions

1. Problem: Sequence disorder, states skipped.Cause:

   Input signal jitter or false triggering.Solution:

* Add filtering or delay processing to the input signals.
* Use state registers or auxiliary relays to "lock" the current state.

1. Problem: Timer inaccuracies affect control effectiveness.Cause:

   Incorrect timer settings or PLC clock errors.Solution:

* Check timer parameters.
* For scenarios with high timing requirements, it is recommended to use external hardware timers.

1. Problem: PLC loses state after stopping operation.Cause:

   State not saved to persistent registers.Solution:

* Use data registers or EEPROM to save state.

7.

Precautions

• Pay attention to the reliability of input signals, especially sensor signals. Redundant design or signal filtering can improve reliability.
• Wiring and load capacity of output devices

  must comply with the rated parameters of the PLC; otherwise, it may damage the PLC module.
• In complex systems, it is recommended to add manual recovery functions to each step to prevent the entire system from failing due to a stuck step.

8.

Practical Exercise Suggestions

• Use actual PLCs (such as Mitsubishi FX series, Siemens S7-200) to set up a simple sequential control experiment, completing the switching of three states.
• Try adding an emergency stop button and implement a function that stops the entire process when the button is pressed at any state.
• Use timer parameters T1 and T2 to adjust the timing for state switching and observe the effects.

Through these practices, you will gain a deeper understanding of the sequential control logic of PLC.
