Introduction

Recently, I wrote a web scraper for work to extract information from the National Standards website, which naturally involved Python. When it comes to parsing HTML, XPath undoubtedly stands out as the top weapon.

You may have heard of or used other parsing methods, such as Beautiful Soup, which seems to have a lot of users. However, compared to XPath:

• The syntax is simpler

• The parsing speed is faster

Like regular expressions, it requires some learning at first, but over time, the rules become second nature, and once you are proficient, they are hard to forget.

Installing lxml

XPath is just a parsing rule; it requires a corresponding library to implement its functionality.

In Python, <span>lxml</span> is the library that implements XPath parsing.

Installing <span>lxml</span> is very simple:

pip install lxml

Next, let’s see how to leverage its power in a real project.

Loading HTML Content

First, import the <span>lxml</span> library:

from lxml import etree

Loading HTML content is done through the <span>etree</span> method, which has three specific methods:

• <span>parse()</span> – loads from a file

• <span>fromstring()</span> – loads from a string

• <span>HTML()</span> – also loads from a string, but in an HTML-compatible way

Which method should you choose?

Don’t hesitate, choose <span>etree.HTML()</span>, even if your HTML content comes from a file. Why is that?

First, it’s important to note that HTML is a type of XML, and the XML standard requires it to have a root tag; otherwise, the XML is invalid. The HTML content we load:

may not be complete, just a fragment, and lacks a root tag

or the loaded HTML may appear complete from start to finish, but some nodes in between may be missing closing tags.

These situations are actually invalid XML. Therefore, when using <span>parse()</span> or <span>fromstring()</span> to load such incomplete HTML, errors will occur; however, using <span>etree.HTML()</span> will not.

This is because <span>etree.HTML()</span> has excellent HTML compatibility; it will complete the incomplete HTML, turning it into a complete, valid HTML.

Example: Loading HTML from a file

from lxml import etree

with open('test.html', 'r') as f:
    html = etree.HTML(f.read())
    print(html, type(html))

Output:

<Element html at 0x7f7efa762040> <class 'lxml.etree._Element'>

The loaded HTML string has already been transformed into an <span>Element</span> object. We will later use XPath to find HTML nodes, all operations will be performed on this <span>Element</span> object.

Finding the HTML Nodes You Need

Assuming we have the following HTML structure:

<table>
    <tbody>...</tbody>  <!-- Table Header -->
    <tbody>...</tbody>  <!-- Table Content -->
</table>

How to locate the second tbody?

We typically call the <span>Element</span> object’s <span>xpath()</span> method to search using the provided XPath path. There are two ways to write the path:

1. <span>/</span> at the beginning – searches down from the root HTML tag along child nodes

2. <span>//</span> at the beginning – finds the node regardless of its position (most commonly used)

Example:

html.xpath('//table/tbody')  # Find all direct child tbody nodes under table
html.xpath('//table/tbody[2]')  # Find the second tbody (index starts from 1)

Powerful Attribute Selectors

If the HTML content contains more than one table, we can use attribute selectors to locate elements more precisely.

Example:

<div class="table-responsive">
    <table>...</table>
</div>

XPath syntax:

html.xpath('//div[@class="table-responsive"]/table/tbody[2]')

Note: In XPath, all HTML attribute matches start with <span>@</span>.

Fuzzy Matching: If the class is not unique, you can use the <span>contains()</span> function:

html.xpath('//table[contains(@class, "result_list")]/tbody[2]')

Tip:

XPath returns a list of elements, so you need to access elements by index.

Relative Positioning

Assuming we want to iterate through all content rows in the table to get the standard number and standard name:

from lxml import etree

with open('test.html', 'r') as f:
    html = etree.HTML(f.read())
    rows = html.xpath('//table[contains(@class, "result_list")]/tbody[2]/tr')

    for row in rows:
        td_list = row.xpath('...')  # How should this be written?

Question:

If you use <span>row.xpath('//td')</span>, you will find that it returns all td nodes, not just the current row’s td. This is because <span>//</span> is absolute positioning, starting from the root node.

Solution:

Use relative positioning (<span>.</span> represents the current node):

td_list = row.xpath('./td')  # Correct syntax

Getting Attributes and Text

Getting Attributes:

a1 = td.xpath('./a')[0]
onclick = a1.get('onclick')  # Get onclick attribute

Getting Text:

text = a1.text  # Directly get node text

Sibling Node Selector

If a row has 1000 td elements but you only need 2, you can optimize using sibling node selectors:

Finding the preceding sibling node:

title_td = row.xpath('./td[@class="mytxt"]')[0]
id_td = title_td.xpath('./preceding-sibling::td[2]')[0]  # Find the 2nd preceding sibling node

Finding the following sibling node:

following_td = title_td.xpath('./following-sibling::td[1]')[0]  # Find the 1st following sibling node

Complete Example Code

from lxml import etree

with open('test.html', 'r') as f:
    html = etree.HTML(f.read())
    rows = html.xpath('//table[contains(@class, "result_list")]/tbody[2]/tr')

    for row in rows:
        title_td = row.xpath('./td[@class="mytxt"]')[0]
        title_link = title_td.xpath('./a')[0]
        title_onclick = title_link.get('onclick')

        print(title_onclick, title_link.text)

        id_td = title_td.xpath('./preceding-sibling::td[2]')[0]
        id_link_text = id_td.xpath('./a/text()')[0]

        print(id_link_text)

XPath Quick Reference

The rules of XPath are not complicated; the commonly used ones are just those. Once you get familiar with them, you will naturally remember them. Here is a highly recommended quick reference: https://devhints.io/xpath

Although the content may not seem rich, it is clear at a glance, and using CSS syntax as a comparison helps better understand the practical use of each XPath rule.
