The T820 (T9100) utilizes advanced 6nm EUV process technology, integrating a high-performance application processor with a built-in financial-grade security solution, delivering a new performance experience in the 5G era.
Additionally, the T820 (T9100) supports 4K ultra-high-definition video recording, 108MP ultra-high pixel photography, and 120Hz high refresh rate display, significantly enhancing multimedia and entertainment experiences on devices.
Overview of the main features of the Unisoc T810/T9100 platform: The Unisoc T820/T9100 features a 1+3+4 tri-cluster octa-core CPU architecture, consisting of 1x 2.7GHz Arm Cortex-A76 big core + 3x 2.3GHz Arm Cortex-A76 big cores + 4x 2.1GHz Arm Cortex-A55, supporting up to 3MB of L3 cache, further enhancing performance. The T820/T9100 is equipped with an Arm Mali-G57 MC4 GPU, with a clock frequency of up to 850MHz.
The T820/T9100 is built using a 6nm EUV advanced process, combined with AI intelligent adjustment technology, resulting in a 40% reduction in power consumption compared to the first-generation Unisoc 5G mobile platform.
Furthermore, the T820/T9100 utilizes LPDDR4X memory and UFS3.1 flash storage, achieving lower power consumption design and smarter real-time temperature control, providing performance support for gaming applications while keeping power consumption at a lower level.
In addition, the T820/T9100 employs AI noise reduction and Smart PA intelligent amplifier technology, offering users a clearer calling experience while providing portable devices such as smartphones and tablets with richer bass and superior sound quality, especially increasing the average volume of the device without exceeding the speaker’s capacity.
Based on Unisoc’s innovative digital audio technology, it can accurately suppress environmental noise, providing users with a professional recording effect that integrates audio and video. Equipped with a low-power voice wake-up system, it will better empower voice assistant applications.
Detailed specifications of the Unisoc T810/T9100 platform:Detailed specifications:
| Product | T820/T9100 |
| Package Type | 360LGA |
| Dimensions (mm) | 45±0.15×48±0.15×2.5±0.15mm |
| Weight (g) | Approximately 17.5 |
| Frequency Bands | NR:N1/N28A/N41/N77/N78/N79 FDD-LTE:B1/B3/B5/B8/B28A TDD-LTE:B34/B38/B39/B40/B41 WCDMA:B1/B5/B8 TD-SCDMA:B34/B39 EVDO/CDMA:BCO GSM/EDGE:850/900/1800MHZ |
| Satellite Positioning(GNSS) | GPS/GLONASS/BEIDOU/QZSS/GALILEO |
| WIFI | 2.4GHZ/5GHz |
| Application Processor | 1xCortex-A76 up to 2.7GHz+3xCortex-A76 up to 2.3GHz+4xCortex-A55 up to 2.1GHz |
| Graphics Processor | Arm MaliTM-G57 cores, up to 850MHz |
| Memory | 4GB+64GB |
| Voltage Characteristics | 3.55~4.4V, typical value 4V |
| Operating Temperature | -20℃~+65℃ |
| Sleep Current | <10mA |
| Operating Current | TBD |
| Data Transmission | |
| NR Features | Supports 5G Sub-6GHz, 3GPP Release 15; 5G NSA and SA modes Supports 5-100MHz bandwidth; supports DL (4×4) MIMO Max rate 2.4Gbps (DL), max 575Mbps (UL) |
| LTE Features | Supports 3GPP R15 CAT15 FDD and TDD Supports 1.4-20 MHz bandwidth Supports downlink (4×4) MIMO max 800Mbps (DL)max 150Mbps (UL) |
| WCDMA Features | Supports 3GPP R9 DC-HSPA+ Supports 16-0AM.64-QAM and QPSK modulation 3GPP R6 HSUPA: Max 11.5Mbps (UL) 3GPP R8 DC-HSPA+: Max 42.2Mbps (DL) |
| TD-SCDMA Features | Supports 3GPP R9 TD-HSDPA: Max 2.8Mbps (DL) TD HSDPA: Max 2.2Mbps (UL) |
| CDMA Features | MAX 3.1MBPS (DL), 1.8 MBPS (UL) |
| WLAN Features | Dual-band 2.4GHz/5GHz, supports 802.11a/b/g/n/ac, supports AP mode |
| Bluetooth Features | BT5.0 |
| Multimedia | |
| Display | QHD+(3360×1440) @60 fps/FHD+(2520×1080)@120 fps HDR+ |
| Video Codec | Encoding: H.265 up to 4K@60 fps, H.264 up to 4K@24 fps Decoding: H.265 up to 4K@60 fps, H.264/VP9 up to 4K@30 fps |
| Interfaces | |
| USIM | Supports USIM/SIM cards; 1.8V and 3V; supports dual SIM dual standby |
| USB | USB3.0 or USB2.0 OTG mode |
| SDIO | Supports SD3.0, 4-bit SDIO, SD/EMMC cards; supports hot swapping |
| LCM | 2 sets of 4-lane MIPI DSI, supports up to QHD+@60 fps/FHD+@120 fps Supports DisplayPort 1.4, up to 4K (3840×2160) @60 fps |
| I2C | 8 sets of I2C, maximum rate up to 400K, maximum speed up to 3.4Mbps |
| ADC | 2 channels, for general-purpose 12BIT ADC. INPUT RANGE=0.01~1.2V |
| PCIe | 1 set, 1-lane PCIe Gen 3, supports NVMe |
| UART | 5 sets, where UART0 is used for debugging, 1 UART is multiplexed with I2C5 |
| I2S | 2 sets, 1 set is default configured for I2S function, 1 set is multiplexed with other functions |
| SPI | 2 sets, 1 set is default configured for I2S function, 1 set is multiplexed with other functions |
| Antenna | 7 RF antennas, WIFI/BT antenna, GNSS antenna, FMRX antenna interfaces |
| Camera | 4x MIPI CSI (4 DATA LANES) 64MP @30FPS |
| Software Features | |
| Operating System | Android 13 |
| Charging Function | 5V2A |
| Software Upgrade | Via USB |
| Certification | |
| RoHS | Complies with RoHS standards |
