1.Hardware Security
Physical Interface Protection
Test whether physical ports such as USB and JTAG can be maliciously accessed or debugged, ensuring that unauthorized physical contact cannot tamper with the device.
Check if the device disables debugging interfaces (e.g., turning off JTAG) to prevent firmware or key extraction through hardware means.
Side-Channel Attack Defense
Verify whether the device leaks sensitive information during operation (e.g., through power analysis, electromagnetic radiation).
Hardware Anti-Theft and Tamper Resistance
Test whether the device has physical protection measures such as anti-theft locks and tamper switches.
Verify the stability and security of the device under extreme temperatures, humidity, and electromagnetic interference.
2.Firmware and Software Security
Firmware Update Mechanism
Test whether firmware is transmitted through encrypted channels (e.g., TLS), verify the signature mechanism to prevent tampering, and ensure the integrity of the update process.
Check if the firmware supports a secure rollback mechanism to prevent the device from becoming unusable due to update failures.
Vulnerability Scanning
Use static analysis tools (e.g., Checkmarx, Coverity) to detect known vulnerabilities in the firmware (e.g., buffer overflow, SQL injection).
Perform dynamic analysis of abnormal behaviors at runtime, such as memory leaks and illegal operations.
Malicious Code Detection
Check if the firmware contains backdoors or malicious code to ensure supply chain security.
Use tools (e.g., ClamAV, YARA) to scan firmware images.
3.Communication Security
Protocol Security
Verify whether the communication protocols used by the device (e.g., MQTT, CoAP, Wi-Fi, Bluetooth) comply with security standards, and whether there are unencrypted transmissions or weak encryption (e.g., WEP).
Check if the protocol implementation follows the latest versions (e.g., Wi-Fi using WPA3, Bluetooth using BLE 5.0+).
Man-in-the-Middle Attack Defense
Test whether the device can withstand man-in-the-middle attacks during transmission, ensuring data integrity.
Use tools (e.g., Wireshark, Scapy) to capture and analyze communication traffic.
API Security
Check whether cloud interfaces and device APIs enable authentication (e.g., OAuth 2.0, JWT), authorization, and input validation to prevent unauthorized access or injection attacks.
Test whether the API limits request frequency to prevent DDoS attacks.
4.Authentication and Authorization
Strong Authentication Mechanisms
Test whether multi-factor authentication (MFA) is supported, strong password policies (e.g., length ≥ 12 characters, including uppercase, lowercase, numbers, symbols), prohibition of default passwords, and mandatory periodic password changes.
Verify the anti-spoofing capabilities of biometric authentication (e.g., fingerprint, facial recognition).
Permission Management
Verify whether role-based access control (RBAC) is effective, ensuring users can only access authorized resources.
Check if administrator permissions are segmented to prevent abuse of privileges.
Session Management
Check whether session tokens are securely generated (e.g., using random numbers), stored (e.g., encrypted storage), and destroyed (e.g., automatic expiration), to prevent session hijacking.
5.Data Security and Privacy
Data Encryption
Test whether sensitive data (e.g., user credentials, device logs) is encrypted during storage (e.g., using AES-256 encryption) and transmission (e.g., TLS 1.3).
Verify the management of encryption keys (e.g., using HSM hardware security modules to store keys).
Privacy Protection
Verify whether the device follows the principle of minimal data collection, whether users are clearly informed of the data usage and consent is obtained, and whether data deletion features are supported (e.g., GDPR’s “right to be forgotten”).
Check whether data anonymization processes (e.g., data masking, differential privacy) are effective.
Compliance
Ensure compliance with privacy regulations such as GDPR, CCPA, and data protection requirements in target markets (e.g., China’s Personal Information Protection Law).
6.Cloud and Mobile Security
Cloud Interface Security
Test whether cloud APIs enable HTTPS, whether there are vulnerabilities such as XSS, CSRF, and whether high-strength passwords are enforced.
Verify whether cloud logs are stored encrypted and whether auditing functions are comprehensive.
Mobile Security
Check whether mobile applications use encrypted transmission (e.g., TLS), whether they contain malicious code, and whether they follow secure coding practices (e.g., input validation, output encoding).
Test whether the communication between mobile applications and devices is secure (e.g., using device certificate authentication).
Logging and Auditing
Verify whether the device records security events (e.g., login failures, configuration changes) and provides audit logs for analysis (e.g., SIEM system integration).
7.Compliance and Standards Conformance
International Standards
Ensure the device complies with standards such as EN18031 (EU Radio Equipment Network Security), NIST SP 800-183 (IoT Device Network Security Guidelines), IEC 62443 (Industrial IoT Security), etc.
Regional Regulations
Verify whether certifications such as CE (EU), FCC (USA), CCC (China) have been obtained, complying with regulatory requirements in target markets.
Industry-Specific Standards
For scenarios in healthcare, industry, etc., check compliance with industry regulations such as HIPAA (health data), GDPR (general data protection), etc.
IoT device security testing must cover hardware, firmware, communication, data, authentication, cloud, physical environment, and compliance across eight major areas, combining automated tools and manual testing to ensure the device’s ability to withstand attacks throughout its lifecycle. Through a systematic testing process, the risk of device attacks can be effectively reduced, safeguarding user privacy and ensuring reliable device operation.
