Learning C++ Programming from Scratch, Day 415: 1196 – Corner I; Question Bank Answers; Second Method

1196 – Corner I

1. Problem Understanding Phase (Corner Matrix Problem)

We need to print a special N×N matrix characterized by:

1. The diagonal from the top left to the bottom right corner and the area above it, where each element’s value equals its column index

2. The area below the diagonal, where each element’s value equals its row index

3. Implementing the matrix printing using recursion

2. Core Idea of the Recursive Algorithm

The program adopts the row-column recursion method:

1. Recursively process in row-major order

2. Recursively process each column within a row

3. The termination condition for recursion is when the row index exceeds N

3. Detailed Execution Process (Example with N=3)

Output Matrix:
1  1  1
1  2  2
1  2  3

Reference Code

#include <bits/stdc++.h> // Include all standard library headers
using namespace std;    // Use standard namespace
/** * Recursively print the corner matrix * @param row Current row index being processed * @param col Current column index being processed * @param N Size of the matrix */
void printMatrix(int row, int col, int N) {    // Termination condition: row index exceeds matrix size    if (row > N) return;
    // When column index exceeds matrix size, move to the next line and process the next row    if (col > N) {        cout << endl;                // Output newline        printMatrix(row + 1, 1, N);  // Recursively process the next row        return;    }
    // Output the current element: if column index ≤ row index, output column index, otherwise output row index    cout << setw(3) << (col <= row ? col : row);
    // Recursively process the next column in the current row    printMatrix(row, col + 1, N);}
int main() {    int N; // Size of the matrix    cin >> N; // Read input
    // Start recursive printing from row 1, column 1    printMatrix(1, 1, N);
    return 0; // End of program}

1. Program Function Description

This program prints a special N×N matrix:

• Above and including the diagonal: element value = column index

• Below the diagonal: element value = row index

• Using recursion to achieve row and column traversal

• Each number occupies a width of 3 characters

2. Core Algorithm Analysis

Recursive Control Flow:

1. Row Recursion:

• When all N columns are processed, move to the next line

• Recursively call to process the next row

Column Recursion:

• Recursively process each column from left to right within a row

• Decide whether to output the row index or column index based on position

Termination Condition for Recursion:

• Terminate when row index row > N

3. Variable Role Description

• <span>row</span>: Current row index being processed (starting from 1)

• <span>col</span>: Current column index being processed (starting from 1)

• <span>N</span>: Dimension of the matrix

• <span>setw(3)</span>: Sets output width to 3 characters

4. Execution Process Example (N=3)

1. printMatrix(1,1,3)

• Output 1

• printMatrix(1,3,3)

• Output 1

• printMatrix(1,4,3) → New line

• Output 1

• printMatrix(1,2,3)

printMatrix(2,1,3)

• Output 2

• printMatrix(2,3,3)

• Output 2

• printMatrix(2,4,3) → New line

• Output 1

• printMatrix(2,2,3)

printMatrix(3,1,3)

• Output 2

• printMatrix(3,3,3)

• Output 3

• printMatrix(3,4,3) → New line

• Output 1

• printMatrix(3,2,3)

printMatrix(4,1,3) → Termination

5. Recursive Call Visualization

printMatrix(1,1,3)
│
├── Output 1
├── printMatrix(1,2,3)
│   ├── Output 1
│   ├── printMatrix(1,3,3)
│   │   ├── Output 1
│   │   └── printMatrix(1,4,3) → New line
│   │       └── printMatrix(2,1,3)
│           ...
└── ...

6. Important Notes

1. Order of Recursion:

• Process in row-major order

• Process each row from left to right

Output Format:

• setw(3) ensures alignment

• Use conditional operators to select output values

Boundary Conditions:

• Row and column indices start from 1

• The termination condition for recursion is row > N

7. Reference Test Cases

Input N	Output Matrix
1	1
2	1 11 2
3	1 1 11 2 21 2 3
4	1 1 1 11 2 2 21 2 3 31 2 3 4

This explanation is entirely based on the original code, providing a detailed analysis of the execution process and visualizing the call relationships to help beginners deeply understand the principles of recursively printing matrices.
