Introduction to IT6335 WiFi Module

Introduction to IT6335 WiFi Module

WIFI/BT/FM 3-in-1 Module:

This module supports dual-band 2.4G + 5G, and is compliant with 802.11a/b/g/n/ac; it also supports Bluetooth 4.0.

It has the following advantages:

• 1. Fast Speed: Supports the latest WIFI standards, 802.11a/b/g/n/ac, and Bluetooth 4.0;

• 2. Strong Signal: Supports 5G WIFI, with less interference and faster speed, avoiding interference from Bluetooth, Zigbee, and regular 2.4G WIFI signals;

• 3. Bandwidth: 20T/40T/80T;

• 4. Rate: 433.3Mbit/s 1T1R;

• 5. Size: 12mm x 12mm x 2.1mm;

• 6. Low Power Consumption: Widely applied in smartphones and tablets, meeting the most stringent mobile power consumption standards;

• 7. High Quality: The module uses top-tier Broadcom WIFI chips and Japanese Murata chip packaging technology;

• 8. Competitive Price: Compared to similar specifications of Taiwan’s AP6255 and AP6335 series, it offers significant price advantages;

• 9. Stable Performance: The module integrates a built-in crystal oscillator, saving costs and avoiding frequency calibration issues in production, as well as problems caused by external crystal oscillators;

• 10. Good Compatibility: Compatible with the Zhengji AP series modules, allowing customers to produce without modifying hardware design files.

Broadcom BCM4335 Chip + Japanese Murata Chip Packaging Technology:

• Supports IEEE802.11a/b/g/n/ac;

• Supports Bluetooth V4.0 + HS;

• SDIO V3.0, V2.0 interfaces;

• Ultra-small size: 8.7mm * 5.4mm * 1.3mm, weight 158mg;

• ROHS certified;

• Built-in FM;

• Supports dual-band 2.4G/5G;

• Bandwidth: 20T/40T/80T;

• Rate: 433.3Mbit/s 1T1R;

• Supports WIFI/BT simultaneous operation;

• Compatible with AP6255/AP6330/AP6335 and Qualcomm 9377 pin adapter board;

• Provides Android and Linux drivers.

Application Platforms:

• Amlogic: S905 S905X S905X2 S905W S905D S912;

• Rockchip: RK3128 RK3288 RK3328 RK3368 RK3399;

• Allwinner: H6 H8;

• Freescale: iMX6 series;

• Samsung

Main Applications:

OTT boxes, set-top boxes, projectors, tablets, and WiFi-enabled smart devices.

Contact Information

For inquiries regarding the WiFi module, contactMr. Wu 15999663534

0755-25839333
