(English Full Name Meaning): Instruction Meaning
1
LD (Load): Active Contact
2
LDN (Load Not): Inactive Contact
3
A (And): Used for Series Connection of Active Contacts
4
AN (And Not): Used for Series Connection of Inactive Contacts
5
O (Or): Used for Parallel Connection of Active Contacts
6
ON (Or Not): Used for Parallel Connection of Inactive Contacts
7
= (Out): Used for Coil Output
8
OLD (Or Load): Block Or
9
ALD (And Load): Block And
10
LPS (Logic Push): Logic Stack
11
LRD (Logic Read): Logic Read Stack
12
LPP (Logic Pop): Logic Pop Stack
13
NOT (Not): Inverse
14
NOP (No Operation Performed): No Operation
15
AENO (And ENO): Instruction Box Output ENO AND
16
S (Set): Set to 1
17
R (Reset): Reset to Zero
18
P (Positive): Rising Edge
19
N (Negative): Falling Edge
20
TON (On_Delay Timer): Turn On Delay Timer
21
TONR (Retentive On_Delay Timer): Memory Retentive On Delay Timer
22
TOF (Off_Delay Timer): Turn Off Delay Timer
23
CTU (Count Up): Increment Counter
24
CTD (Count Down): Decrement Counter
25
CTDU (Count Up/Count Down): Increment/Decrement Counter
26
ADD (Add): Add Attention//ADD_I (I indicates Integer)ADD_DI (DI indicates Double Integer)ADD_R (R indicates Real Number)
They are all addition operations, just the size of the numbers differs.
27
SUB (Subtract): Subtract
28
MUL (Multiply): Multiply
29
DIV (Divide): Divide
30
SQRT (Square root): Calculate Square Root
31
LN (Napierian Logarithm): Calculate Natural Logarithm
32
EXP (Exponential): Calculate Exponential
33
INC_B (Increment): Increase by 1 // Where _B represents data type, W (Byte), DW (Double Word), etc.
34
DEC_B (Decrement): Decrease by 1
35
WAND_B (Word and): Logical AND
36
WOR_B (Word or): Logical OR
37
WXOR_B (Word exclusive or): Logical XOR
38
INV_B (Inverse): Negate
39
MOV_B (Move): Data Transfer
40
BLKMOV_B (Block Move): Data Block Transfer
41
SWAP (Swap): Byte Swap
42
FILL (Fill): Fill Data
43
ROL_B (Rotate Left): Rotate Left
44
ROR_B (Rotate Right): Rotate Right
45
SHL_B (Shift Left): Shift Left
46
SHR_B (Shift Right): Shift Right
47
SHRB (Shift Buffer): Register Shift
48
STOP (Stop): Pause
49
END /MEND (End/Mend): Conditional/Unconditional End
50
WDR (Watch Dog Reset): Watchdog Reset
51
JMP (Jump): Jump
52
LBL (Label): Jump Label
53
FOR (For Loop): Loop
54
NEXT (Next): End of Loop
55
SBR (Subprogram Regulating): Subprogram Call
56
SBR_T (Subprogram Regulating Take): Subprogram Call with Parameters
57
SCR (Sequence Control): Step Start
58
SCRT (Sequence Control Transfer): Step Transfer
59
SCRE (Sequence Control End): Step End
60
AD_T_TBL (Add data to table): Fill Data Table
61
FIFO (First in First out): First In First Out
62
LIFO (Last in First out): Last In First Out
63
TBL_FIND (Table Find): Table Lookup
64
BCD_I (Binary Coded Decimal _I): BCD Code to Integer
65
I_BCD (I_Binary Coded Decimal): Integer to BCD Code
66
B_I (Bit to int): Byte to Integer
67
I_B (int to bit): Integer to Byte
68
DI_I (Double int to int): Double Integer to Integer
69
I_DI (int to double int): Integer to Double Integer
70
ROUND (Round): Real to Double Integer
71
TRUNC (Trunc): Convert 32-bit Real to Integer (Discard Decimal)
72
DI_I (double int to int): Double Integer to Real
73
ENCO (Encode): Encoding
74
DECO (Decode): Decoding
75
SEG (Segment decoder): Seven Segment Display Decoder
76
ATH (ASCII to Hex): ASCII to Hexadecimal
77
HTA (Hexadecimal to ASCII): Hexadecimal to ASCII
78
ITA (Integer to ASCII): Integer to ASCII
79
DTA (Double Integer to ASCII): Double Integer to ASCII
80
RTA (Real to ASCII): Real to ASCII
81
ATCH (Attach): Interrupt Connection
82
DTCH (Detach): Interrupt Separation
83
HDEF (High Speed Counter Definition): High Speed Counter Definition
84
HSC (High Speed Counter): Start High Speed Counter
85
PLS (Pulse): Pulse Output
86
READ_RTC (Read Real Time Clock): Read Real Time Clock
87
SET_RTC (Set Real Time Clock): Write Real Time Clock
88
XMT (Transmitter): Free Sending
89
RCV (Receive): Free Receiving
90
NETR (Net Read): Network Read
91
NETW (Net Write): Network Write
92
GET_ADDR (Get Address): Get Port Address
93
SET_ADDR (Set Address): Set Port Address
94
PID (Proportional Integral Differential): Proportional-Integral-Derivative Controller.
