Common Makefile Templates for Linux Development

1. Introduction

For development on Windows, many IDEs integrate compilers, such as Visual Studio, which provide a “one-click compile” feature. After coding, a single operation can complete the compilation, linking, and generation of target files.

Linux development differs from Windows; typically, the gcc/g++ compiler is used. If developing Linux programs for ARM, the arm-linux-gcc/arm-linux-g++ cross-compiler is also required.

Linux can also achieve a “one-click compile” feature, necessitating a compilation script, the Makefile. The Makefile can be manually written or generated using automated build tools (such as scons, CMake). Manually writing a Makefile is one distinction between Linux and Windows programmers; generally, a universal Makefile can fit most Linux project programs.

2. Three Makefile Templates

2.1 Compile Executable File Makefile

VERSION  =1.00
CC   =gcc
DEBUG   =-DUSE_DEBUG
CFLAGS  =-Wall
SOURCES   =$(wildcard ./source/*.c)
INCLUDES   =-I./include
LIB_NAMES  =-lfun_a -lfun_so
LIB_PATH  =-L./lib
OBJ   =$(patsubst %.c, %.o, $(SOURCES))
TARGET  =app

#links
$(TARGET):$(OBJ)
 @mkdir -p output
 $(CC) $(OBJ) $(LIB_PATH) $(LIB_NAMES) -o output/$(TARGET)$(VERSION)
 @rm -rf $(OBJ)

#compile
%.o: %.c
 $(CC) $(INCLUDES) $(DEBUG) -c $(CFLAGS) $< -o $@

.PHONY:clean
clean:
 @echo "Remove linked and compiled files......"
 rm -rf $(OBJ) $(TARGET) output

Key Points:

1. Program Version

Multiple program versions may be generated during development and debugging; a version number can be added after (or before) the target file.

VERSION = 1.00
$(CC) $(OBJ) $(LIB_PATH) $(LIB_NAMES) -o output/$(TARGET)$(VERSION)

2. Compiler Selection

On Linux, use gcc/g++; for ARM, use arm-linux-gcc; different CPU vendors may provide custom cross-compiler names, such as Hisilicon’s arm-hisiv300-linux-gcc.

CC = gcc

3. Macro Definitions

During development, special code often adds macro conditions to choose whether to compile, such as debugging print output code. -D is a marker, followed by the macro.

DEBUG =-DUSE_DEBUG

4. Compilation Options

Compilation conditions can be specified, such as showing warnings (-Wall) and optimization levels (-O).

CFLAGS =-Wall -O

5. Source Files

Specify the source file destination path, using “wildcard” to get all dependent source files in the path.

SOURCES =$(wildcard ./source/*.c)

6. Header Files

Include the necessary header files, including those for source files and libraries.

INCLUDES =-I./include

7. Library File Names

Specify library file names; library files have a fixed format: static libraries are libxxx.a; dynamic libraries are libxxx.so. To specify a library file name, only the “xxx” part is needed.

LIB_NAMES =-lfun_a -lfun_so

8. Library File Paths

Specify the storage path for dependent library files. Note that if a dynamic library is referenced, it may need to be copied to the /lib or /usr/lib directory, as the system defaults to indexing dynamic libraries from that path when executing applications.

LIB_PATH =-L./lib

9. Target Files

Use patsubst to compile source files (.c) into target files (.o).

OBJ =$(patsubst %.c, %.o, $(SOURCES))

10. Executable File

Specify the executable file name.

TARGET =app

11. Compilation

%.o: %.c
 $(CC) $(INCLUDES) $(DEBUG) $(CFLAGS) $< -o $@

12. Linking

A folder named output can be created to store the target executable file. After linking and outputting the target executable file, temporary files (.o) generated during compilation can be deleted.

$(TARGET):$(OBJ)
 @mkdir -p output
 $(CC) $(OBJ) $(LIB_PATH) $(LIB_NAMES) -o output/$(TARGET)$(VERSION)
 @rm -rf $(OBJ)

13. Clear Compilation Information

Execute make clean to clear temporary files generated during compilation.

.PHONY:clean
clean:
 @echo "Remove linked and compiled files......"
 rm -rf $(OBJ) $(TARGET) output

2.2 Compile Static Library Makefile

VERSION     =
CC          =gcc
DEBUG   =
CFLAGS  =-Wall
AR   =ar
ARFLAGS     =rv
SOURCES   =$(wildcard *.c)
INCLUDES    =-I.
LIB_NAMES   =
LIB_PATH  =
OBJ         =$(patsubst %.c, %.o, $(SOURCES))
TARGET      =libfun_a

#link
$(TARGET):$(OBJ)
 @mkdir -p output
 $(AR) $(ARFLAGS) output/$(TARGET)$(VERSION).a $(OBJ)
 @rm -rf $(OBJ)

#compile
%.o: %.c
 $(CC) $(INCLUDES) $(DEBUG) -c $(CFLAGS) $< -o $@

.PHONY:clean
clean:
 @echo "Remove linked and compiled files......"
 rm -rf $(OBJ) $(TARGET) output

Key Points:

The basic format is consistent with the “Compile Executable Makefile”; the differences include the following.

1. Using the “ar” command to link target files (.o) into a static library file (.a). Static library files have a fixed naming format: libxxx.a.

2.3 Compile Dynamic Library Makefile

VERSION   =
CC        =gcc
DEBUG     =
CFLAGS    =-fPIC -shared
LFLAGS   =-fPIC -shared
SOURCES   =$(wildcard *.c)
INCLUDES  =-I.
LIB_NAMES =
LIB_PATH  =
OBJ       =$(patsubst %.c, %.o, $(SOURCES))
TARGET    =libfun_so

#link
$(TARGET):$(OBJ)
 @mkdir -p output
 $(CC) $(OBJ) $(LIB_PATH) $(LIB_NAMES) $(LFLAGS) -o output/$(TARGET)$(VERSION).so
 @rm -rf $(OBJ)

#compile
%.o: %.c
 $(CC) $(INCLUDES) $(DEBUG) -c $(CFLAGS) $< -o $@

.PHONY:clean
clean:
 @echo "Remove linked and compiled files......"
 rm -rf $(OBJ) $(TARGET) output

Key Points:

The basic format is consistent with the “Compile Executable Makefile”; the differences include the following.

1. Compilation options and linking options add -fPIC -shared. Dynamic library files have a fixed naming format: libxxx.so.

3. Demo

3.1 Compile Application Program

Write a test routine, with the file storage directory structure as follows: header files in the include directory, library files in the lib directory, source files in the source directory, and the Makefile in the current directory.

Source Code 1:

/*Header file*/
#ifndef _FUN0_H_
#define _FUN0_H_
#endif

extern void fun0_printf(void);
extern void fun1_printf(void);

/*Source file*/
#include <stdio.h>
#include "fun0.h"

void fun0_printf(void)
{
    printf("Call 'fun0'. \r\n");
}
</stdio.h>

Source Code 2:

/*Header file*/
#ifndef _FUN1_H_
#define _FUN1_H_
#endif

extern void fun1_printf(void);

/*Source file*/
#include <stdio.h>
#include "fun1.h"

void fun1_printf(void)
{
    printf("Call 'fun1'.\r\n");
}
</stdio.h>

Main Function Source Code:

/*Source file*/
#include <stdio.h>
#include "fun0.h"
#include "fun1.h"
#include "fun_lib_a.h"
#include "fun_lib_so.h"

int main(void)
{
    #ifdef USE_DEBUG
        printf("Debug Application startup.\r\n");
    #endif

        fun0_printf();
        fun1_printf();
        fun_lib_a_printf();
        fun_lib_so_printf();
        return 0;
}
</stdio.h>

Library files, with one static library libfun_a.a and one dynamic library libfun_so.so stored in the ./lib directory.

The Makefile file is the same as the Makefile template in section 2.1.

Test run:

[If the executable file prompts that there is no libfun_so.so, it needs to copy libfun_so.so to the /lib or /usr/lib directory, as the system executes the program, defaulting to pull dynamic libraries from that path]

3.2 Generate Static Library

Write a test routine, the generated library file is the same as the library file called in section 3.1 (libfun_a.a). The file storage directory structure is as follows:

Source Code:

/*Header file*/
#ifndef _FUN_LIB_A_H_
#define _FUN_LIB_A_H_
#endif

extern void fun_lib_a_printf(void);

/*Source file*/
#include <stdio.h>
#include "fun_lib_a.h"

void fun_lib_a_printf(void)
{
    printf("Call 'fun_lib_a'.\r\n");
}
</stdio.h>

The Makefile file is the same as the Makefile template in section 2.2.

Compile to generate static library:

3.3 Generate Dynamic Library

Write a test routine, the generated library file is the same as the library file called in section 3.1 (libfun_so.so). The file storage directory structure is as follows:

Source Code:

/*Header file*/
#ifndef _FUN_LIB_SO_H_
#define _FUN_LIB_SO_H_
#endif

extern void fun_lib_so_printf(void);

/*Header file*/

#include <stdio.h>
#include "fun_lib_so.h"

void fun_lib_so_printf(void)
{
    printf("Call 'fun_lib_so'.\r\n");
}
</stdio.h>

Compile to generate dynamic library:
