Introduction

The NXP i.MX6ULL is favored in industrial control and IoT fields due to its excellent performance-to-power ratio and rich peripheral resources. Establishing a complete development environment is a crucial foundation for embedded Linux development. This article will detail how to set up a professional i.MX6ULL development environment suitable for engineers engaged in low-level driver development and application programming.

Hardware and Software Requirements

Hardware Requirements:

• i.MX6ULL Development Board
• Power Adapter (12V/2A)
• USB to Serial Module (TTL Level)
• SD Card (8GB or more, Class 10)

Software Requirements:

• Host System: Ubuntu 20.04 LTS
• U-Boot Source Code (2023.07)
• Linux Kernel (5.15 LTS)
• Yocto Project (kirkstone)
• NXP Official Toolchain (gcc-arm-none-eabi-10)

Development Environment Overview

The development environment uses the officially supported NXP toolchain, combined with the Yocto Project to build a complete embedded Linux system. It supports TFTP network booting through U-Boot, facilitating development and debugging. The system is constructed using a layered architecture, making it easier for future customization and maintenance.

Preparing the Host Development Environment

# Install basic development packages
sudo apt-get update
sudo apt-get install -y gawk wget git diffstat unzip texinfo gcc-multilib \
     build-essential chrpath socat cpio python3 python3-pip python3-pexpect \
     xz-utils debianutils iputils-ping python3-git python3-jinja2 libegl1-mesa \
     libsdl1.2-dev pylint3 xterm

# Create working directory
mkdir -p ~/imx6ull-project
cd ~/imx6ull-project

Cross-Compilation Toolchain Configuration

# Download and configure NXP toolchain
wget https://developer.arm.com/-/media/Files/downloads/gnu-rm/10-2020q4/gcc-arm-none-eabi-10-2020-q4-major-x86_64-linux.tar.bz2
tar xjf gcc-arm-none-eabi-10-2020-q4-major-x86_64-linux.tar.bz2

# Set environment variables
export PATH=~/imx6ull-project/gcc-arm-none-eabi-10-2020-q4-major/bin:$PATH
export CROSS_COMPILE=arm-none-eabi-
export ARCH=arm

U-Boot Compilation Configuration

# Get U-Boot source code
git clone https://source.denx.de/u-boot/u-boot.git
cd u-boot
git checkout v2023.07

# Configure and compile U-Boot
make mx6ull_14x14_evk_defconfig
make -j4

Kernel Configuration and Compilation

# Get Linux kernel source code
git clone https://git.kernel.org/pub/scm/linux/kernel/git/stable/linux.git
cd linux
git checkout v5.15

# Configure and compile kernel
make imx_v6_v7_defconfig
make -j4 zImage dtbs modules

Yocto Environment Configuration

# Get Yocto base environment
git clone -b kirkstone git://git.yoctoproject.org/poky.git
cd poky

# Initialize build environment
source oe-init-build-env build-imx6ull

# Add NXP BSP layer
git clone -b kirkstone git://source.codeaurora.org/external/imx/meta-imx
bitbake-layers add-layer ../meta-imx/meta-bsp

System Image Build

# Modify conf/local.conf
echo 'MACHINE = "imx6ull14x14evk"' >> conf/local.conf
echo 'DISTRO = "fsl-imx-fb"' >> conf/local.conf

# Build system image
bitbake core-image-minimal

Flashing and Booting the Development Board

# Flash SD card
sudo dd if=tmp/deploy/images/imx6ull14x14evk/core-image-minimal-imx6ull14x14evk.wic \
     of=/dev/sdX bs=1M status=progress

Common Issues and Solutions

1. Missing Compilation Dependencies: Execute<span>sudo apt-get install -y [missing package name]</span>
2. Device Tree Loading Failure: Check if the DTB file is correctly compiled and copied to the boot partition
3. Network Configuration Issues: Ensure the corresponding network drivers are enabled in the kernel configuration

Development Environment Optimization Suggestions

• Configure Eclipse CDT IDE to support remote debugging
• Use NFS root filesystem to speed up development and debugging efficiency
• Set up a TFTP server to support network booting

Conclusion

After completing the above configurations, you will have a professional i.MX6ULL development environment. This environment supports kernel development, driver writing, and application development. It is recommended to further study device tree configuration, boot process optimization, and other professional skills.
