The Volatile Keyword You Might Overlook in MCUs

Click 👆👆👆 the blue text

Follow “Passion Embedded”

In embedded development, especially in the development of microcontrollers like STM32, the <span>volatile</span> keyword is a very important concept.

1. Concept of the volatile Keyword

<span>volatile</span> is a type modifier in C/C++ that tells the compiler:

1. The variable may be modified unexpectedly (e.g., by hardware, interrupts, or multithreading)
2. Prevents the compiler from optimizing (e.g., caching to registers, instruction reordering)
3. Forces every access to read/write from memory

This feature is crucial in STM32 development for the following scenarios:

• Accessing peripheral registers
• Variables shared between interrupt service routines (ISRs) and the main program
• Shared variables in a multitasking environment
• Memory areas modified by DMA

2. Mechanism of volatile

1. Preventing Compiler Optimization

Dangerous scenario without using volatile:

uint32_t sensor_value = 0;

void main() {
    while(1) {
        if(sensor_value > 100) {
            // Trigger action
        }
    }
}

// Modified in interrupt
void ADC_IRQHandler() {
    sensor_value = ADC1->DR;
}

The compiler may cache <span>sensor_value</span> in a register, causing the main loop to never detect changes.

After using volatile:

volatile uint32_t sensor_value = 0;

This forces every access to read the latest value from memory.

2. Preventing Instruction Reordering

The compiler/processor may change the order of instructions for optimization.<span>volatile</span> ensures:

• The order of operations on volatile variables remains unchanged
• Code before and after will not be reordered around volatile operations

3. Scenarios in STM32 that Must Use volatile

1. Accessing Peripheral Registers

All peripheral registers should be declared as volatile:

#define GPIOA_ODR (*(volatile uint32_t *)(0x40020014))

Reason: The GPIO state may be changed automatically by hardware.

2. Shared Variables in Interrupts

volatile bool data_ready = false;

void USART1_IRQHandler() {
    data_ready = true; // Modified in interrupt
}

void main() {
    while(!data_ready); // Main loop checks
}

3. DMA Buffers

volatile uint8_t dma_buffer[256];

DMA transfers are independent of the CPU, requiring volatile to ensure data visibility.

4. Shared Variables in Multitasking

In RTOS:

volatile int shared_counter;

5. Watchdog Feed Operations

volatile uint32_t *const WDG_KR = (uint32_t*)0x40003000;
*WDG_KR = 0xAAAA; // Feed the watchdog

4. Comparison of Using and Not Using volatile

Scenario	Using volatile	Not Using volatile
Reading Interrupt Flags	Always gets the latest value	May read a cached old value
Accessing GPIO Input Registers	Correctly reflects pin status	May return historical values
Detecting DMA Transfer Completion	Timely detection of completion status	May fail to detect status changes
Shared Counters in Multitasking	Ensures value visibility	May lead to data inconsistency
Configuring Peripheral Control Registers	Ensures configuration executes in order	May be optimized out of order by the compiler

5. In-Depth Principles

1. Role of Memory Barriers

In the STM32 Cortex-M core, <span>volatile</span> generates specific memory access instructions:

• <span>LDR</span>/<span>STR</span> replaces regular load instructions
• Prevents the compiler from reordering memory access

2. Comparison of Compiler Optimization

volatile int *pReg = (int*)0x1234;
int *pNormal = (int*)0x5678;

void func() {
    *pReg = 1;   // Generates STR instruction
    *pReg = 2;   // Generates STR again
    *pNormal = 3; // May be optimized away
    *pNormal = 4; // Only the last one is kept
}

3. Relationship with Caching

Although STM32 does not have CPU caching,:

• Register caching still exists (due to compiler optimization)
• DMA and CPU memory access need synchronization

6. Practical Development Cases

Case 1: GPIO Input Detection

// Incorrect writing
if(GPIOA->IDR & GPIO_PIN_5) {
    // May be optimized to a single read
}

// Correct writing
volatile uint32_t *pIDR = &GPIOA->IDR;
if(*pIDR & GPIO_PIN_5) {
    // Will actually read the register every time
}

Case 2: Delay Loop Optimization

volatile uint32_t delay;

for(delay=0; delay<1000000; delay++);
// Without volatile, the loop may be completely optimized away

7. Precautions

1. Cannot replace atomic operations

   volatile int i = 0;
   i++; // This is not an atomic operation!

   Needs to be combined with critical sections or atomic instructions

2. Do not misuse unnecessary volatile will degrade performance

3. Use in conjunction with const

   volatile const uint32_t *pReg = 0x40021000;

4. Debugging Tips Observe disassembly in MDK/IAR:

   LDR R0, [R1]  ; volatile access
   MOV R0, #5    ; non-volatile may directly use immediate value

8. Performance Impact Analysis

Tested on STM32F103 (Cortex-M3):

Operation	No volatile (cycles)	With volatile (cycles)
Single variable read	2	4
Loop 100 times access	200	400
Continuous register write operations	May be merged into 1 write	Each write is independent

9. Best Practice Recommendations

1. All peripheral register pointers must include volatile
2. Variables shared between ISR and main program must be volatile
3. Use CMSIS-defined registers (which already include volatile)
4. Use volatile for memory areas that may be modified by hardware
5. Shared variables in multitasking need to be used with mutex mechanisms
6. Pay special attention in highly optimized code (-O2/-O3)
