Why learn embedded Linux and embedded microcontrollers? Because AI will not be able to replace them in the next decade.

GCC, which stands for GNU Compiler Collection, is a compilation suite that supports various computer architectures such as X86, ARM, and MIPI. The GCC that we use is included by default in Ubuntu.GCC options filename-o parameter specifies the name of the generated fileExample: gcc hello.c -o helloIf we do not use the -o parameter to specify the name of the generated file, directly entering gcc hello.c will produce a file named a.out, and executing this a.out is the same as executing hello.02 File command:Function: View file typeFormat: file filename03

Compilation Process

To compile hello.c into hello or a.out, it goes through four steps: preprocessing, compilation, assembly, and linking.

• hello.i C language code obtained after preprocessing
• hello.s Assembly language file
• hello.o Object file

First stage: Preprocessing stage, the compiler will expand header files or macro definitions, or choose conditional compilation. We can use the -E parameter to obtain the preprocessed file.

• -E: Only preprocess the file, do not compile or link.

Use gcc -E hello.c -o hello.i to obtain the preprocessed file, enter the following command:

gcc -E hello.c -o hello.i

Second stage: Compilation, compiling the file into assembly code-S parameter compiles hello.i into hello.s file

gcc -S hello.i -o hello.s

Third stage: Assembly, compiling the assembly file into machine code-c parameter can compile hello.s into hello.o file

gcc -c hello.s -o hello.o

Fourth stage: LinkingDirectly compiles the object file into an executable fileLinking can be static linking and dynamic linking, with GCC defaulting to dynamic linkingCharacteristics: The generated program is smaller, but it requires library dependencies,Static linking: Using the -static parameter means static linking, as the program includes the required libraries, resulting in a larger size, the size of the statically linked executable file > dynamically linked executable file.

gcc hello.o -o hello

// Static linking gcc hello.c -o hello1 -static
