Jasmine

Jasmine is a lightweight MQTT Broker for Android, developed using Kotlin and based on Netty.

Features

• Support for MQTT 3.1/3.1.1 protocol
• Full support for QoS 0, 1, 2 messages
• Support for Last Will and Testament messages, and retained messages
• Support for subscription topic wildcards
• Dual protocol support for WebSocket
• Default in-memory message persistence
• No support for anonymous access, but authentication is not required by default
• Support for custom authentication logic
• Support for SSL/TLS, one-way/two-way authentication

Integration

implementation("com.sunxiaodou.android:jasmine:[latest-version]")

Usage

Basic Usage

val jasmine = Jasmine.Builder().start() // Default port 1883

After successful startup, use any MQTT client to access <span>tcp://{IP}:1883</span> to connect to the Broker.

Advanced Usage

val jasmine = Jasmine.Builder()
 .port(1883) // Specify port, default 1883
 .enableSSL(true) // Enable SSL/TLS
 .sslPort(1884) // Specify SSL/TLS port, default 1884
 .serverCertFile(File("")) // Specify server certificate, must be specified when enabling SSL/TLS
 .privateKeyFile(File("")) // Specify server private key, PKCS#8 format, must be specified when enabling SSL/TLS
 .enableTwoWayAuth(true) // Enable two-way authentication
 .caCertFile(File("")) // Specify CA certificate for client certificate, must be specified when enabling two-way authentication
 .enableWebsocket(true) // Enable WebSocket
 .websocketPort(8083) // Specify WebSocket port, default 8083
 .websocketSSLPort(8084) // Specify WebSocket SSL/TLS port, default 8084
 .websocketPath("/mqtt") // Specify WebSocket path, default /mqtt
 .keepAliveInSeconds(5) // Specify client keep-alive duration, in seconds, default 5s, disconnect if no interaction with Broker
 .retryInterval(3_000) // Specify QoS1/QoS2 message resend interval, in milliseconds, default 3_000 milliseconds
 .maxRetries(5) // Specify maximum resend attempts for QoS1/QoS2 messages, default 5 times
 .maxContentLength(65536) // Specify maximum content length for a single message, default 65536 bytes
 .maxClientIdLength(255) // Specify maximum length for client ClientId, default 255
 .jasmineCallback(this) // Inject Jasmine callback
 .clientListener(this) // Inject client listener
 .addAuthenticator(this) // Add custom authenticator
 .start()

Future Features

• Data forwarding

Reference Articles

• Setting up an MQTT Broker on Android
