After the iTOP-RK3588 development board supports Preemption and the Xenomai kernel, Beijing Xunwei has joined forces with Wanghuo Real-time Linux system, achieving new breakthroughs in the field of industrial control. The iTOP-RK3588 development board has successfully adapted to Wanghuo Real-time Linux, and this update will provide stronger support for applications requiring higher real-time performance.
Testing has shown that this solution performs well in terms of real-time capabilities. The maximum system latency is 7us (based on cyclictest testing), and the maximum jitter for the EtherCAT 125us periodic task is 5 microseconds (based on Anycontrol testing). Additionally, after prolonged CPU stress testing, the system remains stable under high load conditions, with temperature and power consumption kept within normal ranges, without any crashes or freezes. The test results indicate that the Xunwei iTOP-RK3588 and Wanghuo Real-time Linux hardware and software solution demonstrates good performance in terms of real-time capabilities and reliability.
01
Application Scenarios
02
About Wanghuo OS
★ Advantage 1: Enables real-time Ethernet software stack applications at the microsecond level, supporting 125 microsecond EtherCAT periodic synchronization.
Moreover, the product is optimized for lightweight performance, with a startup speed of up to 0.9s, a minimum system size of 4.4MB, and a minimum memory usage of 6MB.
★ Advantage 2: Perfect compatibility with industrial middleware such as AnyControl, CODESYS, vPLCNext Control, and EC-Master. AnyControl IDE tests the EtherCAT task jitter interface:
★ Advantage 3: Meets the requirements of ISO26262 ASIL B for Linux operating systems.
03
About RK3588
The Xunwei RK3588 development board uses the Rockchip RK3588 processor, a new generation of AloT application chip, built on an 8nm LP process, featuring an octa-core 64-bit CPU.>>>【New Product Release】Xunwei RK3588 Artificial Intelligence AI Mainboard
