Ansible Playbook in Action: One Script Managing 1000 Servers, Boosting Operational Efficiency by 10 Times

Linux Cloud Computing | Daily Practice | Practical Tools | Career Development

💥 “Manually SSH logging into 100 servers to change configurations, working overtime until dawn and still missing some?”

“Inconsistent environments across different machines, crashing upon deployment?”

“Mistyping commands during late-night deployments and being held accountable?”

These operational “nightmare scenarios” are essentially due to “manual operations” failing to keep up with scaling demands!

As an automation operations “score”, Ansible Playbook allows you to conduct operations on thousands of servers with a single YAML script: batch initializing systems, deploying applications, and enhancing security, completing in 1 hour what used to take 10 people 3 days, with 100% consistent configurations!

This article will guide you step-by-step from environment setup to enterprise-level architecture, from basic scripts to error handling, teaching you how to write practical Playbooks that even beginners can master in 1 day and become proficient in 3 days!

01

Why is Ansible Playbook the “Efficiency Savior” for Operations?

🆚 Using the “Conductor of a Symphony Orchestra” analogy, instantly understand the core value of Playbook

Operation Method	Analogous Scenario	Time for 100 Servers	Core Pain Points	Playbook Solution
Manual SSH Operations	Each musician looks at the score and plays freely	10 hours	Prone to errors, inconsistent environments, no audit logs	One “score” conducts all servers “synchronously”
Traditional Shell Scripts	The conductor shouts commands, musicians forget	2 hours	Does not support idempotency (issues with repeated executions), poor cross-system compatibility	Declarative syntax (only states “what state is needed”), idempotency (executing 100 times = 1 time)
Other Automation Tools (e.g., Puppet)	The conductor must learn complex musical notation	1.5 hours	Requires client installation, complex configuration	No client required (just SSH), YAML syntax is like a “manual”, easy for beginners to understand

💡 Three “Operational Magic” Features of Playbook (Easy for Beginners)

1. Declarative Syntax: Only states “what is needed”, not “how to do it”

Traditional scripts: Must write “first apt update, then apt install vim”;

Playbook: Just write “ensure vim is installed (state: present)”, Ansible automatically

determines the current state (skips if installed, installs if not).

👉 Advantage: No need to worry about “intermediate steps”, focus on “final results”, making scripts simpler and less error-prone.

2. Idempotency: The effect of executing 100 times is exactly the same as executing once

For example, the task of “creating user ops” will create the user on the first execution, and on subsequent executions, it will detect that the user already exists and skip.

👉 Advantage: No need to worry about “repeated execution causing failures” (e.g., errors when trying to create a user again), can safely

schedule executions or manually retry.

3. No Client Required: Can be used with just SSH, zero deployment cost

No need to install any agents (clients) on target servers, just enable SSH service and configure passwordless

login;

Supports Linux/Windows/macOS, hybrid cloud environments (physical machines + virtual machines + cloud servers)

Unified management.

👉 Advantage: Can quickly connect to 1000 servers without spending a day installing clients first.

02

Write Your First Playbook in 1 Hour (From 0 to 1 Practical Example)

🛠️Taking “Batch Initialization of 10 Servers” as an example (including system updates, tool installations, user creation, and SSH security configuration) 💻Step 1: Environment Preparation (15 minutes, basic configuration) ① Install Ansible (Control Machine: 1 Linux server/computer) Ubuntu/Debian:

sudo apt update && sudo apt install ansible -y

CentOS/RHEL/OpenEuler:

sudo yum install epel-release -y  # CentOS needs to install EPEL source firstsudo yum install ansible -y

Verify installation:

ansible --version  # Output version number (e.g., ansible [core 2.14.2]) indicates success

② Configure the Host Inventory (Tell Ansible which servers to manage) The host inventory is a “server list” that can be grouped by roles (e.g., web servers, DB servers), facilitating subsequent batch operations. Edit Ansible’s default host inventory file:

sudo vim /etc/ansible/hosts

Add server information (replace with your actual IP, supports grouping):

# Group by role: Web server group[web_servers]web1 ansible_host=192.168.1.10  # Server 1: Alias web1, IP 192.168.1.10web2 ansible_host=192.168.1.11  # Server 2# Group by role: DB server group[db_servers]db1 ansible_host=192.168.1.20  # Database server# Parent group: includes all servers (for one-time operations on all machines)[cluster:children]web_serversdb_servers

③ Configure Passwordless SSH Login (Control Machine → Target Machine)

Ansible communicates via SSH, and passwordless login avoids entering a password every time a script is executed:

Generate SSH keys on the control machine (just press enter, no password needed):

ssh-keygen -t rsa  # Generates ~/.ssh/id_rsa (private key) and ~/.ssh/id_rsa.pub (public key)

Push the public key to all target servers (replace with your server IP, first time requires entering a password):

ssh-copy-id [email protected]  # Push to web1ssh-copy-id [email protected]  # Push to web2ssh-copy-id [email protected]  # Push to db1

Verify passwordless login:

ssh [email protected]  # Login without entering a password, indicating successful configuration

💻Step 2: Write Your First Playbook (20 minutes, initialize servers)

Create init-server.yml to implement 4 core tasks: update system, install basic tools, create operation user, configure SSH security.

---# Playbook Name: Batch Initialization of Server Cluster- name: Initialize Linux Servers (Web+DB)  hosts: all  # Applies to all servers in the inventory (cluster group)  become: yes  # Switch to root privileges when executing tasks (similar to sudo)  gather_facts: yes  # Collect information about target servers (e.g., system version, IP, etc.)  # Task list: executed in order  tasks:    # Task 1: Update system packages (only for Debian/Ubuntu, CentOS automatically skips)    - name: Update package cache and upgrade Debian/Ubuntu system      apt:        update_cache: yes  # Equivalent to apt update        upgrade: dist      # Equivalent to apt upgrade -y        cache_valid_time: 3600  # Do not update cache again within 1 hour (speed optimization)      when: ansible_os_family == "Debian"  # Condition: only execute on Debian-based systems    # Task 2: Install basic tools (common to all systems: vim, curl, wget, etc.)    - name: Install basic operation tools      package:        name:  # List of software to install          - vim          - curl          - wget          - net-tools  # Includes commands like ifconfig          - chrony     # Time synchronization tool (to avoid inconsistent server times)        state: present  # Ensure software is installed (skip if already installed, install if not)    # Task 3: Create operation user ops (password stored encrypted, avoid plaintext)    - name: Create operation user ops      user:        name: ops                # Username        groups: sudo             # Add to sudo group (has root privileges)        shell: /bin/bash         # Default shell        createhome: yes          # Create home directory (/home/ops)        password: "{{ 'Ops@2024' | password_hash('sha512') }}"  # Password encryption (original password Ops@2024)        comment: "Operation-specific account, deletion prohibited"  # User comment    # Task 4: SSH security hardening (disable root login, disable password login)    - name: Configure sshd_config to disable root SSH login      lineinfile:        path: /etc/ssh/sshd_config  # Path to the file to modify        regexp: '^#?PermitRootLogin'  # Matching line (PermitRootLogin with or without #)        line: 'PermitRootLogin no'    # Replace with "disable root login"        state: present               # Ensure this line exists        backup: yes                  # Backup the file before modification (/etc/ssh/sshd_config.bak)    - name: Configure sshd_config to disable password login (only allow key login)      lineinfile:        path: /etc/ssh/sshd_config        regexp: '^#?PasswordAuthentication'        line: 'PasswordAuthentication no'        state: present        backup: yes      notify: Restart SSH Service  # Trigger the "Restart SSH Service" handler (restart needed after modifying configuration)  # Handlers: only executed when triggered by tasks (e.g., restart service after modifying sshd_config)  handlers:    - name: Restart SSH Service      service:        name: sshd        # Service name (both CentOS/Ubuntu are sshd)        state: restarted  # Status: restart        enabled: yes      # Ensure service starts on boot

💻Step 3: Execute Playbook (15 minutes, verify results)

Ansible provides a “syntax check → dry run → actual execution” process to avoid failures from direct execution.

① Syntax Check (Check for YAML format errors)

ansible-playbook init-server.yml --syntax-check# Output "playbook: init-server.yml" indicates no syntax errors; errors will prompt specific line numbers

② Dry Run (Simulate execution, no actual changes to servers)

ansible-playbook init-server.yml --check# Output "changed=0" for each task (simulated execution, no actual changes), no errors means can execute formally

③ Formal Execution (Batch Initialize Servers)

ansible-playbook init-server.yml# Key output interpretation:# - ok=xx: Task executed and status correct (e.g., software installed)# - changed=xx: Task executed and modified status (e.g., first time creating ops user)# - failed=0: No failed tasks (failures will prompt specific reasons, such as SSH connection timeout)

④ Verify Execution Results (Ensure configuration is effective)

# 1. Check if ops user has been created on all serversansible all -m shell -a "id ops"  # Output uid=1001(ops) gid=1001(ops) ... indicates success# 2. Check if root can SSH login (should fail, indicating security hardening is effective)ssh [email protected]  # Output "Permission denied" indicates success (must log in with ops user: ssh [email protected])

💻Step 4: Advanced Practice: Role-Based Deployment (Differentiated Configuration for Web+DB Servers)

In actual operations, web servers need to install Nginx, and DB servers need to install MySQL, which can be achieved through “group tasks” for differentiated deployment, creating

<span>deploy-app.yml</span>:

---# First Part: Deploy Web Server (only applies to web_servers group)- name: Deploy Web Server (Install Nginx + Deploy Website Code)  hosts: web_servers  # Only for Web Server group  become: yes  vars:  # Variable definitions (unified management, easy to modify)    nginx_version: "1.24.0"  # Nginx version to install    web_root: "/var/www/html"  # Website root directory    index_content: "<h1>Welcome to {{ ansible_host }} (Web Server)</h1>"  # Dynamic content (includes server IP)  tasks:    # Task 1: Install Nginx (CentOS uses yum, Ubuntu uses apt, automatically adapts)    - name: Install Nginx      package:        name: nginx-{{ nginx_version }}  # Use variable to define version        state: present    # Task 2: Create website root directory    - name: Create website root directory {{ web_root }}      file:        path: "{{ web_root }}"        state: directory  # Ensure directory exists        owner: www-data   # Owner (Nginx default user)        group: www-data        mode: 0755        # Permissions: owner read/write/execute, others read/execute    # Task 3: Deploy homepage (dynamically generated, includes server IP)    - name: Generate homepage index.html      copy:        content: "{{ index_content }}"  # Use variable to dynamically generate content        dest: "{{ web_root }}/index.html"        owner: www-data        group: www-data        mode: 0644    # Task 4: Start Nginx and set to start on boot    - name: Start Nginx service      service:        name: nginx        state: started        enabled: yes# Second Part: Deploy DB Server (only applies to db_servers group)- name: Deploy DB Server (Install MySQL + Initialize Database)  hosts: db_servers  # Only for DB Server group  become: yes  vars:    mysql_root_pass: "DBroot@2024"  # MySQL root password (use Ansible Vault encryption in actual environment)    app_db: "app_prod"              # Application database name    app_user: "app_user"            # Application database user  tasks:    # Task 1: Install MySQL Server (CentOS uses mysql-server, Ubuntu uses mysql-server)    - name: Install MySQL Server      package:        name: mysql-server        state: present    # Task 2: Start MySQL and set to start on boot    - name: Start MySQL service      service:        name: mysqld  # CentOS service name; Ubuntu is mysql        state: started        enabled: yes    # Task 3: Initialize database (create application database and user)    - name: Initialize MySQL (create database and user)      mysql_db:        name: "{{ app_db }}"        state: present  # Ensure database exists        login_user: root        login_password: "{{ mysql_root_pass }}"        login_unix_socket: /var/lib/mysql/mysql.sock  # MySQL local socket path    - name: Create application database user {{ app_user }}      mysql_user:        name: "{{ app_user }}"        password: "AppPass@2024"  # Application user password        priv: "{{ app_db }}.*:ALL"  # Permissions: all permissions on all tables of app_db        host: "%"  # Allow connections from any IP (restrict to web server IP in production)        state: present        login_user: root        login_password: "{{ mysql_root_pass }}"        login_unix_socket: /var/lib/mysql/mysql.sock

Execute differentiated deployment:

ansible-playbook deploy-app.yml# Verify Web Server: Access http://192.168.1.10, displays "Welcome to 192.168.1.10 (Web Server)"# Verify DB Server: Log in mysql -u root -pDBroot@2024, execute show databases; can see app_prod database

03

Enterprise-Level Playbook Architecture: From “Single Script” to “Maintainable System”

When managing 1000 servers and 10 applications, a single script becomes bloated and hard to maintain, requiring organization by “roles (Roles) + variables + environment isolation” to achieve“modularity, reusability, and easy expansion”.

1. Role-Based Organization (Roles): Split modules by function

Ansible Roles are a “standardized directory structure” that splits tasks, variables, templates, etc., by role (e.g., common role, nginx role, mysql role), facilitating collaboration and reuse.

① Create Roles Directory Structure

Use <span>ansible-galaxy</span> (Ansible’s built-in tool) to automatically generate the standard structure:

# Create 3 roles: common (general configuration), nginx (web service), mysql (db service)ansible-galaxy init roles/commonansible-galaxy init roles/nginxansible-galaxy init roles/mysql

The generated directory structure is as follows (core directory explanation):

roles/├── common/          # Common role (needs to be executed on all servers: time synchronization, security hardening)│   ├── tasks/       # Task files (main.yml: entry task)│   ├── handlers/    # Handlers (main.yml: e.g., restart service)│   ├── vars/        # Variables (main.yml: role-specific variables)│   └── templates/   # Template files (e.g., sshd_config.j2, supports variable replacement)├── nginx/           # Nginx role (specific to web servers)│   ├── tasks/│   ├── handlers/│   ├── vars/│   └── templates/   # e.g., nginx.conf.j2 (Nginx configuration template)└── mysql/           # MySQL role (specific to db servers)    ├── tasks/    ├── handlers/    └── vars/

② Split Tasks into Roles (using common role as an example)Edit<span>roles/common/tasks/main.yml</span><span> (common task entry):</span>

# common role: common configuration for all servers- name: Install basic tools  package:    name: [vim, curl, wget, chrony]    state: present- name: Configure time synchronization (chrony)  template:    src: templates/chrony.conf.j2  # Template file (in roles/common/templates/)    dest: /etc/chrony.conf  notify: Restart chrony service

Edit roles/common/handlers/main.yml (handlers):

- name: Restart chrony service  service:    name: chronyd    state: restarted    enabled: yes

③ Call Roles (Write Main Playbook site.yml)

---# Main Playbook: Call all roles for full cluster deployment- name: Execute common configuration on all servers (common role)  hosts: all  become: yes  roles:    - common  # Call common role- name: Execute Nginx configuration on web servers (nginx role)  hosts: web_servers  become: yes  roles:    - nginx  # Call nginx role- name: Execute MySQL configuration on db servers (mysql role)  hosts: db_servers  become: yes  roles:    - mysql  # Call mysql role

Execute the main Playbook:

ansible-playbook site.yml

2. Environment Isolation: Distinguish between Development/Testing/Production EnvironmentsIn enterprises, it is necessary to distinguish between dev (development), test (testing), and prod (production) environments (e.g., production environment MySQL passwords are more complex), which can be achieved through “inventory environment directories” for isolation.① Create Environment Directory Structure

mkdir -p inventory/{dev,test,prod}  # 3 environment directories

② Write Production Environment Host Inventory (inventory/prod/hosts)

[web_servers]prod-web1 ansible_host=10.0.1.10prod-web2 ansible_host=10.0.1.11[db_servers]prod-db1 ansible_host=10.0.2.10

③ Write Production Environment Variables (inventory/prod/group_vars/all.yml)

# Global variables for production environment (more stringent than development environment)timezone: Asia/Shanghaiport: 2222  # Production environment SSH port is not 22 (security hardening)mysql_root_pass: "ProdDB@2024!"  # Production environment password is more complexnginx_access_log: "/var/log/nginx/access.log"

④ Execute Playbook for Specified Environment

# Execute production environment deployment (use -i to specify environment directory)ansible-playbook -i inventory/prod site.yml# Execute development environment deploymentansible-playbook -i inventory/dev site.yml

3. Best Practices: Make Playbooks More Robust and Efficient① Tag Execution (Only Execute Part of Tasks, Avoid Full Deployment)Add <span>tags</span>, and use <span>--tags</span> to specify only running certain types of tasks (e.g., only execute security hardening, not software installation):

- name: Security hardening task (tag: security)  tags: security  tasks:    - name: Disable root SSH login      lineinfile:        path: /etc/ssh/sshd_config        regexp: '^#?PermitRootLogin'        line: 'PermitRootLogin no'- name: Performance optimization task (tag: performance)  tags: performance  tasks:    - name: Adjust kernel parameters (increase TCP connection count)      sysctl:        name: net.core.somaxconn        value: "65535"        state: present

Execute tasks with specified tags:

# Only execute security hardening tasks (suitable for urgent security patches)ansible-playbook site.yml --tags "security"

② Encrypt Sensitive Data (Use Ansible Vault to Avoid Plaintext Passwords)In production environments, sensitive data such as MySQL passwords, SSH keys, etc., should not be written in plaintext in Playbooks, and can be encrypted using <span>ansible-vault</span>:

# 1. Encrypt variable file (e.g., inventory/prod/group_vars/all.yml)ansible-vault encrypt inventory/prod/group_vars/all.yml# Enter encryption password (remember, need to enter for subsequent executions)# 2. View the encrypted file (garbled, cannot be read directly)cat inventory/prod/group_vars/all.yml# 3. Execute Playbook while decrypting (need to enter encryption password)ansible-playbook -i inventory/prod site.yml --ask-vault-pass

③ Performance Optimization (Manage 1000 Servers Without Lag)Edit <span>/etc/ansible/ansible.cfg</span>, adjust concurrency and SSH connection parameters:

[defaults]forks = 50  # Number of processes for concurrent task execution (default 5, set to 50-100 for 1000 servers)host_key_checking = False  # Disable SSH host key checking (avoid pop-up on first connection)gathering = smart  # Smartly collect server information (do not re-collect if already collected)[ssh_connection]ssh_args = -o ControlMaster=auto -o ControlPersist=60s  # Reuse SSH connections (reduce connection establishment time)pipelining = True  # Enable SSH pipelining (reduce data transfer times, improve speed)

04

Common Questions in Operations: Three Core Issues of Ansible Playbook Practice

📊 Q1: Is Playbook difficult to learn? How long does it take for beginners to get started?

Syntax Difficulty: YAML syntax is simpler than JSON, like “lists + key-value pairs”, can learn basic syntax (e.g., – name: task name, hosts: all) in 1 hour;

Getting Started Time: Can write basic Playbooks for “installing software, creating users” in 1 day, master Roles and environment isolation in 3 days, and handle enterprise-level scenarios in 1 week;

Learning Resources: Ansible official documentation (docs.ansible.com) has detailed module descriptions, and example code can be copied directly.

📊 Q2: Does it support Windows servers? Can it manage hybrid environments?

Yes! Ansible manages Windows servers via WinRM (Windows Remote Management), just enable WinRM service on Windows;

Hybrid environments (Linux + Windows + macOS) can be managed uniformly, using

when: ansible_os_family == “Windows” to distinguish systems;

Example (Installing IIS service on Windows):

- name: Install IIS on Windows Server  hosts: windows_servers  tasks:    - name: Install IIS      win_feature:        name: Web-Server        state: present

📊 Q3: What if a task fails? How to troubleshoot?

Failure Prompt: Ansible outputs the specific line number and reason for failed tasks (e.g., “SSH connection timed out” “insufficient permissions”);

Log Troubleshooting: Add -v (detailed log) or -vvv (debug log) when executing to view the complete execution process:

ansible-playbook site.yml -vvv  # Outputs detailed logs, including SSH commands, return results

Common Failure Reasons:

SSH Connection Failure: Check if the target server IP is correct, if the SSH port is open, and if passwordless login is configured;

Insufficient Permissions: Ensure become: yes is enabled (use root privileges to execute tasks);

Software Package Does Not Exist: Check if the software name is correct (e.g., mysql-server in CentOS is called mysql-server in Ubuntu).

05

【Practical Challenge】Write Your First Playbook

Tasks (Choose Any One)

1. Basic Task:

Write a Playbook to install Docker on 3 servers and take a screenshot of the output of

ansible all -m shell -a “docker –version”;

2. Advanced Task:

Use Roles to split “common role (time synchronization) + nginx role (install Nginx)”, take a screenshot of the Roles directory structure and execution results;

3. High-Level Task:

Create dev and prod environments, achieving “dev environment Nginx port 80, prod environment Nginx port 8080”, take screenshots of the different environment Nginx configuration files.

👉 Share your results in the comments section

🎁 The first 3 will receive an electronic book of “Ansible Authority Guide” (including enterprise-level Playbook templates and troubleshooting tips)!
