MQTT is a lightweight messaging protocol (Message Queuing Telemetry Transport) designed for low bandwidth and high latency communication between devices. It is a message protocol based on the Publish/Subscribe model, originally developed by IBM, and has now become an open standard widely used in the Internet of Things (IoT) field.

Features of MQTT include:

  1. Lightweight: The MQTT protocol is designed simply, with lightweight message headers, suitable for constrained environments such as sensors and embedded devices.

  2. Easy to Use: MQTT uses a publish/subscribe model, decoupling the sender (publisher) and receiver (subscriber) of messages, making the communication process simple and easy to understand.

  3. Low Bandwidth, High Latency: The MQTT protocol is designed considering limited network bandwidth and high latency, maintaining stable message transmission in less than ideal network environments.

  4. Reliability: MQTT supports message persistence and acknowledgment mechanisms, ensuring reliable message transmission, and provides QoS (Quality of Service) levels that can be flexibly configured based on actual needs.

  5. Flexibility: MQTT supports various message formats and payload types, allowing the transmission of text, binary data, and more, while supporting SSL/TLS encryption to ensure communication security.

  6. Applicable to Various Scenarios: Due to its lightweight and flexibility, MQTT is widely used in IoT, sensor networks, remote monitoring, message notifications, and other scenarios, becoming one of the important communication protocols connecting devices.

The steps to integrate MQTT in RuoYi Frontend and Backend Separation are as follows:

1. Download the MQTT X testing tool and install it.

Official website: https://www.emqx.com/zh/try?product=emqx-ecp

Integrating MQTT in RuoYi Frontend and Backend Separation

2. Open MQTT X, create a new connection, enter the name, and click connect.

Integrating MQTT in RuoYi Frontend and Backend Separation

3. Add dependencies in the pom.xml under the ruoyi-common module.

<!--mqtt依衖-->
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-integration</artifactId>
</dependency>
<dependency>
    <groupId>org.springframework.integration</groupId>
    <artifactId>spring-integration-stream</artifactId>
</dependency>
<dependency>
    <groupId>org.springframework.integration</groupId>
    <artifactId>spring-integration-mqtt</artifactId>
</dependency>

4. Add relevant configurations in application.yml under Spring configuration.

# mqtt
  mqtt:
    username: admin # Username
    password: admin # Password
    hostUrl: tcp://broker.emqx.io:1883 # tcp://ip:port
    clientId: clientId # Client ID
    defaultTopic: topic,topic1 # Subscribed topics
    timeout: 100 # Timeout (seconds)
    keepalive: 60 # Heartbeat (seconds)
    enabled: true # Whether to use MQTT functionality

Integrating MQTT in RuoYi Frontend and Backend Separation

5. Create a mqtt folder under ruoyi-common/src/main/java/com/ruoyi/common/utils directory and add the following three files:

MqttConfig.java

package com.ruoyi.common.utils.mqtt;

import com.ruoyi.common.utils.StringUtils;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.boot.context.properties.ConfigurationProperties;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.stereotype.Component;

@Component
@ConfigurationProperties("spring.mqtt")
public class MqttConfig {
    @Autowired
    private MqttPushClient mqttPushClient;

    /**
     * Username
     */
    private String username;
    /**
     * Password
     */
    private String password;
    /**
     * Connection address
     */
    private String hostUrl;
    /**
     * Client ID
     */
    private String clientId;
    /**
     * Default connection topic
     */
    private String defaultTopic;
    /**
     * Timeout
     */
    private int timeout;
    /**
     * Keep alive
     */
    private int keepalive;
    /**
     * MQTT functionality enable
     */
    private boolean enabled;

    public String getUsername() {
        return username;
    }

    public void setUsername(String username) {
        this.username = username;
    }

    public String getPassword() {
        return password;
    }

    public void setPassword(String password) {
        this.password = password;
    }

    public String getHostUrl() {
        return hostUrl;
    }

    public void setHostUrl(String hostUrl) {
        this.hostUrl = hostUrl;
    }

    public String getClientId() {
        return clientId;
    }

    public void setClientId(String clientId) {
        this.clientId = clientId;
    }

    public String getDefaultTopic() {
        return defaultTopic;
    }

    public void setDefaultTopic(String defaultTopic) {
        this.defaultTopic = defaultTopic;
    }

    public int getTimeout() {
        return timeout;
    }

    public void setTimeout(int timeout) {
        this.timeout = timeout;
    }

    public int getKeepalive() {
        return keepalive;
    }

    public void setKeepalive(int keepalive) {
        this.keepalive = keepalive;
    }

    public boolean isEnabled() {
        return enabled;
    }

    public void setEnabled(boolean enabled) {
        this.enabled = enabled;
    }

    @Bean
    public MqttPushClient getMqttPushClient() {
        if(enabled == true){
            String mqtt_topic[] = StringUtils.split(defaultTopic, ",");
            mqttPushClient.connect(hostUrl, clientId, username, password, timeout, keepalive);//connect
            for(int i=0; i<mqtt_topic.length; i++){
                mqttPushClient.subscribe(mqtt_topic[i], 0);//subscribe topic
            }
        }
        return mqttPushClient;
    }
}

MqttPushClient.java

package com.ruoyi.common.utils.mqtt;

import com.ruoyi.common.core.domain.AjaxResult;
import org.eclipse.paho.client.mqttv3.*;
import org.eclipse.paho.client.mqttv3.persist.MemoryPersistence;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;

import static com.ruoyi.common.core.domain.AjaxResult.error;
import static com.ruoyi.common.core.domain.AjaxResult.success;

@Component
public class MqttPushClient {
    private static final Logger logger = LoggerFactory.getLogger(MqttPushClient.class);

    @Autowired
    private PushCallback pushCallback;

    private static MqttClient client;

    private static MqttClient getClient() {
        return client;
    }

    private static void setClient(MqttClient client) {
        MqttPushClient.client = client;
    }

    /**
     * Client connection
     *
     * @param host      ip+port
     * @param clientID  Client ID
     * @param username  Username
     * @param password  Password
     * @param timeout   Timeout
     * @param keepalive Keep alive
     */
    public void connect(String host, String clientID, String username, String password, int timeout, int keepalive) {
        MqttClient client;
        try {
            client = new MqttClient(host, clientID, new MemoryPersistence());
            MqttConnectOptions options = new MqttConnectOptions();
            options.setCleanSession(true);
            options.setUserName(username);
            options.setPassword(password.toCharArray());
            options.setConnectionTimeout(timeout);
            options.setKeepAliveInterval(keepalive);
            MqttPushClient.setClient(client);
            try {
                client.setCallback(pushCallback);
                client.connect(options);
            } catch (Exception e) {
                e.printStackTrace();
            }
        } catch (Exception e) {
            e.printStackTrace();
        }
    }

    /**
     * Publish
     *
     * @param qos         Connection method
     * @param retained    Whether to retain
     * @param topic       Topic
     * @param pushMessage Message body
     */
    public AjaxResult publish(int qos, boolean retained, String topic, String pushMessage) {
        MqttMessage message = new MqttMessage();
        message.setQos(qos);
        message.setRetained(retained);
        message.setPayload(pushMessage.getBytes());
        MqttTopic mTopic = MqttPushClient.getClient().getTopic(topic);
        if (null == mTopic) {
            logger.error("topic not exist");
        }
        MqttDeliveryToken token;
        try {
            token = mTopic.publish(message);
            token.waitForCompletion();
            return success();
        } catch (MqttPersistenceException e) {
            e.printStackTrace();
            return error();
        } catch (MqttException e) {
            e.printStackTrace();
            return error();
        }
    }

    /**
     * Subscribe to a topic
     *
     * @param topic Topic
     * @param qos   Connection method
     */
    public void subscribe(String topic, int qos) {
        logger.info("Starting to subscribe to topic " + topic);
        try {
            MqttPushClient.getClient().subscribe(topic, qos);
        } catch (MqttException e) {
            e.printStackTrace();
        }
    }

}

PushCallback.java

package com.ruoyi.common.utils.mqtt;

import com.alibaba.fastjson2.JSONObject;
import org.eclipse.paho.client.mqttv3.IMqttDeliveryToken;
import org.eclipse.paho.client.mqttv3.MqttCallback;
import org.eclipse.paho.client.mqttv3.MqttClient;
import org.eclipse.paho.client.mqttv3.MqttMessage;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;

@Component
public class PushCallback implements MqttCallback {
    private static final Logger logger = LoggerFactory.getLogger(MqttPushClient.class);

    @Autowired
    private MqttConfig mqttConfig;

    private static MqttClient client;

    private static String _topic;
    private static String _qos;
    private static String _msg;

    @Override
    public void connectionLost(Throwable throwable) {
        // Reconnect after connection loss
        logger.info("Connection lost, can reconnect");
        if (client == null || !client.isConnected()) {
            mqttConfig.getMqttPushClient();
        }
    }

    @Override
    public void messageArrived(String topic, MqttMessage mqttMessage) throws Exception {
        // Messages received after subscribing will execute here
        logger.info("Received message topic : " + topic);
        logger.info("Received message Qos : " + mqttMessage.getQos());
        logger.info("Received message content : " + new String(mqttMessage.getPayload()));

        _topic = topic;
        _qos = mqttMessage.getQos() + "";
        _msg = new String(mqttMessage.getPayload());
    }

    @Override
    public void deliveryComplete(IMqttDeliveryToken iMqttDeliveryToken) {
        logger.info("deliveryComplete---------" + iMqttDeliveryToken.isComplete());
    }

    // Other controllers will call this method to get received hardware data
    public String receive() {
        JSONObject jsonObject = new JSONObject();
        jsonObject.put("topic", _topic);
        jsonObject.put("qos", _qos);
        jsonObject.put("msg", _msg);
        return jsonObject.toString();
    }

}

Note: The areas marked in red in the project can be resolved by pressing Alt+Enter to import dependencies.

6. Run the RuoYi project, the backend can receive data sent by MQTTX.

Integrating MQTT in RuoYi Frontend and Backend SeparationIntegrating MQTT in RuoYi Frontend and Backend Separation
