FreeRTOS defines its own set of data types primarily to ensure portability across different processor architectures and compilers.

These data types are defined in the <span>portmacro.h</span> file, and the specific implementation will be adjusted according to different compilers and processors.

Basic Data Types

FreeRTOS defines the following basic data types:

Special Data Types

Example of Data Type Definitions

In the FreeRTOS source code, these types are typically defined as follows:

#define portCHAR        char
#define portFLOAT       float
#define portDOUBLE      double
#define portLONG        long
#define portSHORT       short
#define portSTACK_TYPE  uint32_t
#define portBASE_TYPE   long

typedef portSTACK_TYPE StackType_t;
typedef long BaseType_t;
typedef unsigned long UBaseType_t;

Coding Style

FreeRTOS has a very consistent coding style that runs throughout the project, making the code easy to read and maintain.

Naming Conventions

FreeRTOS adopts a strict naming convention:

1. Variable Naming:

   Example:

   BaseType_t xResult;
   char cByte;
   uint8_t ucCount;
   void *pvBuffer;


• <span>x</span>: Non-standard types (e.g., <span>BaseType_t</span>, <span>TickType_t</span>, etc.)
• <span>c</span>: Character type
• <span>s</span>: String
• <span>uc</span>: Unsigned character
• <span>p</span>: Pointer
• <span>pc</span>: Pointer to character
• <span>ul</span>: Unsigned long
• <span>v</span>: void

• Variable names use lowercase letters
• Multiple words are separated by underscores
• The prefix indicates the variable type or purpose:

void vTaskDelete(TaskHandle_t xTask);
BaseType_t xQueueSend(QueueHandle_t xQueue, const void *pvItemToQueue, TickType_t xTicksToWait);
void *pvPortMalloc(size_t xSize);

• <span>v</span>: void return type
• <span>x</span>: returns BaseType_t
• <span>pv</span>: returns void pointer

• <span>vTask</span>: Task related
• <span>xQueue</span>: Queue related
• <span>vSemaphore</span>: Semaphore related
• <span>pvPortMalloc</span>: Memory management related

• Use prefixes to indicate the module to which the function belongs:
• The prefix is followed by the action and object, using camel case naming
• The return type is also reflected in the naming:

#define configUSE_PREEMPTION        1
#define pdTRUE                     (1)
#define errQUEUE_FULL              (0)

• <span>config</span>: Macros in the configuration file
• <span>pd</span> (port dependent): Macros related to portability
• <span>err</span>: Error codes

• All uppercase
• Words are separated by underscores
• The prefix indicates the module to which it belongs:

Coding Style

1. Indentation and Braces:

   Example:

   if( xCondition == pdTRUE )
   {
       /* Indent 4 spaces */
       vFunction();
   }


• Use 4 spaces for indentation
• The opening brace is on the same line as the statement
• The closing brace is on a new line, aligned with the starting statement

/*
 * Create a new task and add it to the ready task list.
 *
 * @param pxTaskCode Task function pointer
 * @param pcName Descriptive name of the task
 * @param usStackDepth Task stack size (in words)
 * @param pvParameters Parameters passed to the task
 * @param uxPriority Task priority
 * @param pxCreatedTask Used to return the task handle
 * @return Returns pdPASS on success, error code on failure
 */
BaseType_t xTaskCreate( TaskFunction_t pxTaskCode,
                        const char * const pcName,
                        const uint16_t usStackDepth,
                        void * const pvParameters,
                        UBaseType_t uxPriority,
                        TaskHandle_t * const pxCreatedTask );

• Use standard C comments (/* */)
• Important parts use multi-line comments
• Function header comments describe functionality, parameters, and return values

xQueue = xQueueCreate(
            uxQueueLength,
            uxItemSize
        );

• If function parameters are too long, they are displayed on separate lines, each parameter on its own line
• Spaces around operators
• Spaces after commas

Specific Coding Habits

1. Return Value Check:

   Example:

   if( xQueueSend( xQueue, &xData, xTicksToWait ) != pdPASS )
   {
       /* Error handling */
   }


• FreeRTOS functions typically return <span>pdPASS</span> or <span>pdFAIL</span>
• Error codes are typically defined as macros

taskENTER_CRITICAL();
{
    /* Critical section code */
}
taskEXIT_CRITICAL();

• Use macros to enter and exit critical sections
• Keep critical sections as short as possible

configASSERT( xQueue != NULL );

• Use the <span>configASSERT()</span> macro for runtime checks
• Enabled during development, can be disabled in production

Example Code Analysis

Below is a typical FreeRTOS task creation code that demonstrates data types and coding style:

/* Task function prototype */
void vTaskFunction( void *pvParameters );

/* Task handle */
TaskHandle_t xHandle = NULL;

/* Create task */
BaseType_t xReturned = xTaskCreate(
    vTaskFunction,       /* Task function pointer */
    "Demo Task",         /* Task name */
    configMINIMAL_STACK_SIZE, /* Stack size */
    NULL,                /* Parameters passed to the task */
    tskIDLE_PRIORITY + 1, /* Task priority */
    &xHandle             /* Return task handle */
);

/* Check if task was created successfully */
if( xReturned == pdPASS )
{
    /* Task created successfully */
    vTaskStartScheduler(); /* Start scheduler */
}
else
{
    /* Handle error */
    for( ;; );
}

/* Task implementation */
void vTaskFunction( void *pvParameters )
{
    TickType_t xLastWakeTime;
    const TickType_t xFrequency = pdMS_TO_TICKS( 1000 ); /* 1 second period */

    /* Initialize variable */
    xLastWakeTime = xTaskGetTickCount();

    for( ;; )
    {
        /* Task functionality code */

        /* Delay until next period */
        vTaskDelayUntil( &xLastWakeTime, xFrequency );
    }
}

Porting Related Data Types

When porting FreeRTOS to different platforms, special attention should be paid to the following data types and macro definitions:

1. Defined in portmacro.h:

• Processor-specific data types
• Macros for entering/exiting critical sections
• Macros related to task switching
• Definitions related to system ticks

• Stack initialization
• Starting the first task
• System tick timer configuration
• Context switching

Conclusion

The design of FreeRTOS’s data types and coding style has the following characteristics:

1. Portability: Ensures compatibility across different platforms through custom data types
2. Consistency: Strict naming rules and coding style make the code easy to read and maintain
3. Clarity: Naming prefixes clearly express the type and purpose of variables and functions
4. Efficiency: Choosing the most suitable base data types for the target processor to improve efficiency

Understanding and following FreeRTOS’s data types and coding style is crucial for developing high-quality FreeRTOS applications, especially when porting to different platforms or collaborating with teams.

This consistent style also makes the FreeRTOS source code itself an excellent example for learning embedded real-time system programming.
