Fluorescent Tracing Sensor
Product Features
-
*Modbus 485 and 4-20mA simultaneous output, directly connect to computers and PLC systems
-
*Measurement range (0~200PPB)
-
*Utilizes advanced 90-degree scattering light method
-
*IP68 waterproof standard
-
*Wide voltage power supply (7~30V)
-
*Low drift, compact size, fast response speed
-
*Easy installation, simple, direct readings and settings via computer and mobile phone, calibration
-
*Stable performance, long service life
Technical Parameters
-
Measurement Principle: Uses ultraviolet excitation of fluorescent agents in the reagent to measure its fluorescence signal value
-
Measurement Range: 0～200ppb, customizable
-
Response Time: 2s
-
Resolution: 0.1ppb
-
Accuracy: ±1%F.S
-
Calibration: Two-point calibration, supports one-click calibration
-
Operating Temperature: 0～60℃
-
Operating Pressure: <0.8MPa
-
Installation: ZG3/4″ thread, or sealed with a compression ring
-
Power Consumption: <0.2W
-
Protection Level: IP68
-
Power Supply: 7~30VDC, other voltages can be customized
