The industrial automation control system is the core of modern manufacturing, and almost all production lines, equipment, and processes rely on it. A good automation control system must not only be stable and reliable but also flexible and scalable to meet the dual demands of production efficiency and quality. Today, we will discuss how to design a complete industrial automation control system using Siemens PLC (S7-1200). From hardware selection to program design and debugging optimization, we will guide you step by step through the core technologies and implementation points.

1. Objective: Design a Complete Automation Control System

Core Technical Points

1. Hardware Selection and System Architecture Design: Choose the appropriate PLC model, I/O modules, sensors, and actuators based on project requirements.
2. Control Logic Design: Implement basic control functions such as sequential control, logical judgment, and analog processing using ladder diagram programming.
3. Communication and Data Management: Use protocols like PROFINET and MODBUS for data exchange between devices and integration with SCADA systems.
4. Debugging and Optimization: Optimize program stability and response speed through simulation and on-site debugging.

2. Hardware Composition and System Architecture

2.1 Hardware Composition of a Typical Industrial Control System

1. PLC Main Unit (e.g., S7-1200 CPU 1214C): The core of the control system, used for processing logical control and data calculations.
2. I/O Modules:

• Digital Input (DI): Receives switch signals from switches, buttons, or sensors.
• Digital Output (DO): Controls relays, solenoid valves, or alarms.
• Analog Input (AI): Collects continuous signals such as temperature, pressure, and flow.
• Analog Output (AO): Controls devices like inverters and servo drives.

Sensors and Actuators: Such as photoelectric sensors, temperature sensors, stepper motors, heaters, etc.

Communication Modules: Used for communication with other devices or host computers (e.g., CP modules).

HMI (Human-Machine Interface): Allows operators to view status, input parameters, and manually control devices.

Power Supply Module: Provides 24V DC power for PLC, I/O modules, and sensors.

2.2 System Architecture Design

A typical industrial automation system architecture is as follows:

Sensors (temperature, pressure, limit switches) → PLC I/O Modules → Actuators (motors, valves, alarms)
HMI (PROFINET interface connected to PLC) → Operator interaction interface
Host Computer (SCADA system) → PLC (via Ethernet or MODBUS communication)

Notes:

• Module Expansion: Choose an appropriate number of I/O modules based on system scale to ensure future expandability.
• Communication Network: Prefer standard industrial protocols (e.g., PROFINET) to ensure communication reliability.
• Power Supply Stability: Equip PLC and sensors with separate UPS power supplies to prevent data loss due to power outages.

3. PLC Program Design

Next, we will implement a simple automation control logic using ladder diagram (LAD).

3.1 Function 1: Sequential Control Logic

Scenario: A conveyor belt system with the following functions:

1. Start/Stop Control: Press the start button to run the conveyor belt; press the stop button to stop it.
2. Material Detection: The photoelectric sensor detects material and triggers an alarm sound while counting.

Ladder Diagram Program:

| I0.0 (Start Button) | ----[ Normally Open Contact ]----( )---- Q0.0 (Conveyor Motor Start)
| I0.1 (Stop Button) | ----[ Normally Closed Contact ]----|

| I1.0 (Photoelectric Sensor) | ----[ Normally Open Contact ]----( )---- Q0.1 (Alarm)
                                          ----[ Counter Function Block ]----> Count (Count Value)

Notes:

• Interlock Logic: The logic for the start and stop buttons needs to be interlocked to avoid equipment damage due to misoperation.
• Debounce Processing: Implement debounce processing for button and sensor input signals to avoid false triggering due to mechanical vibrations.

3.2 Function 2: Temperature Control Logic

Scenario: A heating system that needs to maintain the temperature within a set range (e.g., 50°C to 70°C).

Ladder Diagram Program:

| Current_Temperature < Min_Temperature (Lower Limit) | ----[ Comparison Function Block ]----( )---- Q0.2 (Heater Start)
| Current_Temperature > Max_Temperature (Upper Limit) | ----[ Comparison Function Block ]----( )---- Q0.2 (Heater Stop)

Notes:

• Hysteresis Control: Add a hysteresis value of 1-2°C to avoid frequent starting and stopping of the heater.
• Safety Protection: Set a temperature upper limit (e.g., 80°C) to trigger an alarm and stop the heater if exceeded.

3.3 Function 3: Data Logging and Communication

Scenario: Real-time transmission of the conveyor belt’s running time and material count to the host computer.

Data Logging Logic:

1. Create a data block (DB) to store running time and count value:

• <span>Run_Time</span> (Running Time)
• <span>Material_Count</span> (Material Count Value)

Periodically update running time:

| Timer (Triggered Every Second) | ----[ Function Block ]----> Run_Time (Running Time Accumulation)

Communication Logic:

1. Configure the PLC’s Ethernet communication module and set the MODBUS TCP protocol.
2. Map the <span>Run_Time</span> and <span>Material_Count</span> variables to MODBUS register addresses.
3. The host computer reads this data via the MODBUS protocol.

4. Practical Application Case

Case: Automatic Control of Food Processing Production Line

Requirements: A food processing plant needs to achieve the following functions:

1. Automatically control the conveyor belt, coordinating with robotic arms to sort materials.
2. Monitor temperature and humidity during production and adjust equipment operating status based on parameters.
3. Real-time upload of production data to the SCADA system for management review.

Solution:

• Use Siemens S7-1200 PLC to control the conveyor belt and robotic arm actions.
• Collect environmental data using temperature and humidity sensors, controlling heaters and fans with the PLC.
• Configure the Ethernet communication module to upload production data to the SCADA system.

Transformation Effects:

• Production efficiency increased by 30%, and defect rate decreased by 20%.
• Data visualization made management more transparent, reducing debugging time by 50%.

5. Common Problems and Solutions

Problem 1: Unstable Button or Sensor Signals

• Cause: Input signals have not undergone debounce processing.
• Solution: Add a Delay Function Block (TON) in the program to filter short-duration jitter signals.

Problem 2: Communication Data Loss or Delay

• Cause: Incorrect network configuration or device communication timeout.
• Solution: Check if the communication parameters of the PLC and host computer match, and optimize the network layout.

Problem 3: Frequent Starting of the Heater

• Cause: Control logic does not include hysteresis values.
• Solution: Set a hysteresis range between upper and lower limits in the program to avoid frequent starts and stops.

6. Precautions

1. Reasonable Module Selection: Choose I/O modules for the PLC based on actual needs to avoid resource waste or insufficient functionality.
2. Clear Program Structure: Divide different functions into independent program blocks or function blocks for easier debugging and maintenance.
3. Standardized Communication Protocols: Prefer industrial standard protocols like PROFINET or MODBUS to ensure compatibility and expandability.
4. Prioritize Safety Protection: Implement emergency stop, over-limit alarms, and other safety functions in the program to prevent equipment damage or personnel injury.

7. Practical Recommendations

1. Start with Small Systems: First implement control of a single device, then gradually expand to multi-device and multi-function collaborative work.
2. Utilize Simulation Tools: Use PLCSIM to simulate the actual operating environment and identify logical issues in the program in advance.
3. Optimize Program Performance: Regularly analyze program runtime and optimize resource-intensive function blocks.
4. Document Debugging Experience: Record problems encountered and solutions during project implementation to build your own experience database.

Through this article, you will not only master the design concepts of industrial automation control systems but also apply this knowledge to practical projects, gradually enhancing your engineering practice skills!
