unset1. Macro Expansion Rulesunsetunset

In the C language preprocessor, if a macro parameter itself is a macro, the timing of its expansion follows certain rules. Specifically, the timing of the macro parameter’s expansion depends on its position and usage in the macro definition. Here are the detailed rules and explanations:

Timing of Macro Parameter Expansion

When a macro is called, the preprocessor processes the macro parameters according to the following steps:

Parameter Replacement

• During the macro call, the preprocessor replaces the macro parameters with actual arguments.
• If the macro parameter itself is a macro, the preprocessor first expands this macro parameter before performing the replacement.

Macro Expansion in Replacement List

• In the replacement list, the preprocessor processes each symbol one by one. If the symbol is a macro, the preprocessor further expands this macro.
• However, if the symbol is a macro parameter and this macro parameter is used as a parameter for the <span>#</span> or <span>##</span> operators in the replacement list, this macro parameter will not be expanded.

Specific Rules

• Parameter Expansion Takes Precedence Over Replacement List Expansion: Macro parameters are expanded before being replaced in the replacement list.
• Macro Expansion in Replacement List: Symbols in the replacement list (including expanded parameters) will be further expanded unless they are used as parameters for the <span>#</span> or <span>##</span> operators.

Examples

Example 1: Parameter Expansion Takes Precedence

Assume we have the following macro definition:

#define A 123
#define PRINT(x) printf("%d\n", x)

Calling the macro:

PRINT(A);

Expansion process:

1. Parameter Replacement:<span>A</span> is a macro, the preprocessor first expands <span>A</span>, resulting in <span>123</span>.

2. Replacement List Expansion: Replace <span>123</span> in the <span>PRINT</span> replacement list, resulting in:

   printf("%d\n", 123);


Final output:

123

Example 2: Parameter Not Expanded (<span>#</span> Operator)

Assume we have the following macro definition:

#define A 123
#define STRINGIFY(x) #x

Calling the macro:

printf("%s\n", STRINGIFY(A));

Expansion process:

1. Parameter Replacement:<span>A</span> is a macro, but since <span>STRINGIFY</span> uses the <span>#</span> operator in its replacement list, <span>A</span> will not be expanded.

2. Replacement List Expansion: Replace <span>A</span> in the <span>STRINGIFY</span> replacement list, resulting in:

   printf("%s\n", "A");


Final output:

A

Example 3: Parameter Not Expanded (<span>##</span> Operator)

Assume we have the following macro definition:

#define A 123
#define CONCAT(x, y) x##y

Calling the macro:

CONCAT(A, B);

Expansion process:

1. Parameter Replacement:<span>A</span> is a macro, but since <span>CONCAT</span> uses the <span>##</span> operator in its replacement list, <span>A</span> will not be expanded.

2. Replacement List Expansion: Replace <span>A</span> and <span>B</span> in the <span>CONCAT</span> replacement list, resulting in:

   AB


Final result:<span>AB</span> is a symbol, not <span>123B</span>.

4. Rules

• Parameter Expansion Takes Precedence: Macro parameters are expanded before being replaced in the replacement list.
• Macro Expansion in Replacement List: Symbols in the replacement list will be further expanded unless they are used as parameters for the <span>#</span> or <span>##</span> operators.
• Special Cases: If a macro parameter is used as a parameter for the <span>#</span> or <span>##</span> operators in the replacement list, this macro parameter will not be expanded.

unsetunset2. Handling Non-Expanded Macro Parametersunsetunset

#define STRINGIFY(x)    STRINGIFY_HELPER(x)
#define STRINGIFY_HELPER(x)     #x

#define STRINGCAT(x, y)  STRINGCAT_HELPER(x, y)
#define STRINGCAT_HELPER(x, y)  x##y

These rules ensure that the macro expansion process is predictable while also providing a flexible way to control macro behavior.

This code defines two macros <span>STRINGIFY</span> and <span>STRINGIFY_HELPER</span>, as well as <span>STRINGCAT</span> and <span>STRINGCAT_HELPER</span>. The reason for needing two macros to achieve functionality instead of using a single macro directly is due to the working mechanism of the C preprocessor.

Explanation of Reasons

1. Preprocessor Expansion Rules In the C preprocessor, macro parameters are not immediately replaced with actual values during the first expansion; they retain their original form. Only through indirect expansion (i.e., via another macro call) can the actual values of the parameters be correctly resolved.

2. Specific Scenario Analysis

• For <span>STRINGIFY(x)</span>, if defined directly as <span>#x</span>, it cannot correctly handle macros with parameters or complex expressions. By using <span>STRINGIFY_HELPER(x)</span> for indirect calls, it ensures that parameters are correctly expanded before being stringified.
• Similarly, for <span>STRINGCAT(x, y)</span>, if defined directly as <span>x##y</span>, it cannot correctly concatenate macros with parameters or complex expressions. By using <span>STRINGCAT_HELPER(x, y)</span> for indirect calls, it ensures that parameters are correctly expanded before concatenation.

#define FOO 123
#define STRINGIFY(x)    #x
#define STRINGCAT(x, y) x##y

const char* str = STRINGIFY(FOO); // Result is "FOO" instead of "123"
int value = STRINGCAT(FOO, 456);  // Result is FOO456 instead of 123456

#define STRINGIFY(x)    STRINGIFY_HELPER(x)
#define STRINGIFY_HELPER(x)     #x
#define STRINGCAT(x, y)  STRINGCAT_HELPER(x, y)
#define STRINGCAT_HELPER(x, y)  x##y

const char* str = STRINGIFY(FOO); // Result is "123"
int value = STRINGCAT(FOO, 456);  // Result is 123456

Through indirect macro calls, parameters are correctly expanded, achieving the expected functionality.

unsetunsetConclusionunsetunset

The reason for defining two macros is to utilize the two-step expansion mechanism of the C preprocessor, ensuring that macro parameters can be correctly resolved and processed. If only one macro were used, it would not be able to correctly handle complex macro parameters or expressions.
