As we all know, embedded devices generally have limited storage media and tight resources, which is why a command system for embedded devices called BusyBox has emerged. The characteristic of BusyBox is its powerful functionality while occupying a small storage capacity. Today, I will introduce how to download and compile BusyBox for your embedded device.

Introduction to BusyBox

BusyBox is an open-source, lightweight Unix toolbox that integrates streamlined versions of many standard Unix tools. This tool is designed to run in resource-constrained environments, such as embedded systems or boot disks. BusyBox consolidates multiple standard Unix utilities into a single executable file, including file operations, process management, network configuration, text processing, and more.

Introduction to BusyBox: A Lightweight Command System for Embedded Devices The main features of BusyBox include:

Small Size: Its goal is to keep functionality as compact as possible, saving system resources and allowing the system to run more efficiently.
Multi-functional: Integrates over 300 common commands, such as file operations, text processing, system management, network tools, etc., covering most common system management functions.
Configurable: You can choose which features to include based on your needs and remove unnecessary parts, thus meeting the requirements of different systems.
Portable: It can run on different POSIX systems, whether Linux, BSD, or Solaris, without issues.
Open Source: It is an open-source project released under the GPL license, allowing everyone to use and modify it freely.

BusyBox is widely used in embedded Linux systems. It helps build a compact and efficient root filesystem, significantly reducing disk and memory usage. It is also commonly used as a startup script or initialization script tool to configure the system and start services.

Principle of BusyBox

BusyBox utilizes the parameters passed to the main function by the shell. At startup, the shell passes the user-input command and its parameters to the main function. For example, when you enter ls -l /home/user in the command line, the shell parses this command line into an array of parameters and passes it to BusyBox’s main function. This array contains the command name (ls), options (-l), and file path (/home/user), etc.

BusyBox checks argv[0] (the first parameter passed to the main function) to determine which command the user requested. The command name entered by the user (e.g., ls, cp, mv, etc.) is stored in argv[0]. Then, BusyBox uses its internal command mapping mechanism to find and call the corresponding function for that command.

For example, when argv[0] is ls, the main function will look up the implementation function corresponding to the command name ls, which might be ls_main(), and pass the remaining parameters (like -l and the path) to that function. Thus, the ls command will execute its file listing operation.

When executing each specific command, the command’s parameters are further parsed. For example, in the implementation of the ls command, there will be a piece of code to parse options like -l. This is usually done by processing the subsequent parameters in the argv array. The argc parameter indicates the total number of parameters, and argv is an array containing the command name and options. Therefore, the code for the ls command will iterate through the argv array to parse all options and file paths.

After the command execution is complete, the command handling function returns an integer value based on the operation result. Typically, if the command executes successfully, the return value is 0, otherwise it is a non-zero value. This return value is passed back to the main function and then returned by BusyBox to the shell to indicate the execution status of the command.

In this way, BusyBox implements the functionality of supporting multiple Unix tool commands within a single executable file. Each command is handled by an independent function and executes specific operations based on parameters. Through this method, BusyBox provides a compact yet efficient multi-command support while maintaining a small executable file size.

Downloading and Compiling BusyBox

The steps to compile BusyBox from source are not complicated. Let me guide you through the process step by step.

1. Prepare the Environment

Before starting, ensure that you have installed some necessary tools on your system:

GCC Compiler: Used for compiling source code.
Make Tool: Used for automating the build process.
Other Necessary Tools: Such as binutils, gzip, tar, etc.

You can install the necessary packages using the following command (for Ubuntu):

sudo apt-get update
sudo apt-get install build-essential gcc make binutils libncurses5-dev

2. Download BusyBox Source Code

Visit the BusyBox official website or download the latest source code directly using the following command:

wget https://busybox.net/downloads/busybox-1.0.tar.bz2

Extract the source package:

tar -xjf busybox-1.0.tar.bz2
cd busybox-1.0

3. Configure BusyBox

Now that we are in the source directory, we need to configure it to select the features and components we want to compile.

Using Default Configuration:

make defconfig

This command will generate a default configuration file suitable for most users.

Custom Configuration: If you want to manually select the commands and options to compile, you can run:

make menuconfig

This command will start a configuration interface based on ncurses, where you can select the required features, commands, libraries, etc., or enable or disable certain options. In this configuration interface, you can use the up and down arrow keys to select menu items, press Enter to confirm your selection, and press the Esc key to exit the configuration.

4. Compile BusyBox

After configuration is complete, you can start compiling BusyBox. Run the following command:

make

Executing this command will start the compilation of BusyBox, which may take a few minutes depending on your computer’s performance.

By following these steps, you have successfully compiled BusyBox from source. You can configure and customize BusyBox according to your needs, selecting the required commands and features. BusyBox provides a compact yet feature-rich toolkit, especially suitable for embedded systems or environments that require extreme minimization.

Installing BusyBox on Development Board

As previously discussed, if you want to compile BusyBox on your computer and use the compiled files on an embedded device, you will need cross-compilation tools. We have already covered the introduction to cross-compilation tools, so I will not elaborate further here.

Use the following command to install the compiled results to the specified storage directory:

make install CONFIG_PREFIX=/home/JsmesBin/linux/nfs/rootfs

After compilation, all tools and files of BusyBox will be installed in the rootfs directory, which contains the bin, sbin, and usr directories, as well as the linuxrc file. The Linux kernel’s init process will eventually look for the user-space init program, and once found, it will run this user-space init program, thus switching to user mode. If BusyBox is set with init=/linuxrc, then linuxrc can serve as the user-space init program.

After BusyBox is compiled, the root filesystem is still not usable; it requires some additional files. You need to add library files to rootfs/lib: since the above BusyBox uses dynamically linked libraries, you also need to add dynamic libraries to the root filesystem.

First, create a folder named lib in rootfs. The library files are obtained from the cross-compiler, which I have stored in the /usr/local/arm/ directory. Enter the libc/lib directory of the cross-compiler, where there are many .so and .a files, which are the library files. Copy all .so and .a files from this directory to the rootfs/lib directory.

At this point, all library files for the root filesystem have been added, and you can proceed to create the image and filesystem as usual to include BusyBox in your image. Of course, you can also use the NFS mounting method to test the created root filesystem rootfs.
