FreeRTOS Development: Message Buffer – An Advanced Choice for Task Communication

1. Basic Concepts

In FreeRTOS, the “message buffer” refers to <span>Message Buffer</span>, which is a communication mechanism provided by FreeRTOS for transmitting variable-length data (byte streams) between tasks or between interrupts and tasks. It is part of FreeRTOS and was officially introduced in version <span>v10.0.0</span>.

Simply put, a message buffer (Message Buffer) is equivalent to a <span>buffer for variable-length message communication</span>. Compared to queues, message buffers are more suitable for sending byte streams or variable-length data rather than fixed-size data items.

Main Features

Feature	Description
Supports variable-length messages	Each message can be of different lengths
Unidirectional communication	Typically used for one sender and one receiver
Does not support multi-task reception	Multiple tasks receiving from the message buffer is unsafe
Supports sending from ISR	Messages can be sent in interrupts (using special APIs)
Underlying structure is a circular buffer	Efficient and low-overhead implementation

Message Buffer vs Queue

Feature	Queue	Message Buffer
Data Type	Fixed size	Variable size
Multi-task Access	Both sending and receiving can be done by multiple tasks	Generally used for one-to-one
Real-time Performance	Supported	Better real-time performance supported
Interrupt Support	Supported	More flexible support
Complexity of Use	Simple	Somewhat complex (due to variable length)

2. Working Principle

Core Idea

Circular Buffer + Variable Length Header

The essence of the message buffer is a circular buffer (ring buffer), which stores data in the following format:

| Message Header (2 bytes) | Message Content (n bytes) | Message Header (2 bytes) | Message Content (m bytes) | ...

✳️ Each message has a header (2 bytes) that indicates the length of the message body

• Thus, the receiving end knows how many bytes to read from the buffer.

Buffer Structure

typedef struct StreamBufferDef_t
{
    volatile size_t xTail;                       ///<  Read pointer (next byte index to read)
    volatile size_t xHead;                       ///<  Write pointer (next byte index to write)
    size_t xLength;                              ///<  Total length of the buffer (in bytes)
    size_t xTriggerLevelBytes;                   ///<  Trigger level (only for task blocking wake-up) If a task is waiting for data to be received, it will only be woken up when xTriggerLevelBytes bytes are readable.
    volatile TaskHandle_t xTaskWaitingToReceive; ///<  Current blocking task handle waiting to receive (if any)
    volatile TaskHandle_t xTaskWaitingToSend;    ///<  Current blocking task handle waiting to send (if any)
    uint8_t * pucBuffer;                         ///<  Pointer to the actual memory space of the circular buffer (i.e., where the data is located)
    uint8_t ucFlags;                             ///<  Control flags to identify whether the current buffer is a Stream Buffer or Message Buffer, and possibly other options.

    #if ( configUSE_TRACE_FACILITY == 1 )
        UBaseType_t uxStreamBufferNumber;        ///<  Debugging/tracing number (optional), used for tools like Tracealyzer.
    #endif

    #if ( configUSE_SB_COMPLETED_CALLBACK == 1 )
        // Can be used for event-driven programming (no polling or blocking)
        StreamBufferCallbackFunction_t pxSendCompletedCallback;    ///<  Optional callback function: for notification mechanism when sending is complete
        StreamBufferCallbackFunction_t pxReceiveCompletedCallback; ///<  Optional callback function: for notification mechanism when receiving is complete
    #endif
    UBaseType_t uxNotificationIndex;                               ///<  Used in conjunction with task notification mechanism (xTaskNotify()), supports FreeRTOS's Task Notification interface
} StreamBuffer_t;

Stream Buffer vs Message Buffer

Feature	Stream Buffer	Message Buffer
Data Structure	<span>StreamBuffer_t</span>	Also <span>StreamBuffer_t</span>
Data Type	Byte stream (no message boundaries)	Messages with boundaries (length of each message is indicated by the first 2 bytes)
Applicable Scenarios	Continuous data streams such as audio/video/serial	Log messages, command packets, variable-length protocols, etc.
Reading Method on Reception	Specify read length	Automatically read the entire complete message based on the message header

3. Interface Definitions

<1>. Create Message Buffer

MessageBufferHandle_t xMessageBufferCreate( size_t xBufferSizeBytes );

<2>. Send Message

size_t xMessageBufferSend( MessageBufferHandle_t xMessageBuffer,
                           const void * pvTxData,
                           size_t xDataLengthBytes,
                           TickType_t xTicksToWait );

<3>. Receive Message

size_t xMessageBufferReceive( MessageBufferHandle_t xMessageBuffer,
                              void * pvRxData,
                              size_t xBufferLengthBytes,
                              TickType_t xTicksToWait );

<4>. Send from ISR

size_t xMessageBufferSendFromISR( MessageBufferHandle_t xMessageBuffer,
                                  const void * pvTxData,
                                  size_t xDataLengthBytes,
                                  BaseType_t *pxHigherPriorityTaskWoken );

4. Application Examples

Application Example

There are two tasks:

• SenderTask: Periodically sends variable-length messages (strings)
• ReceiverTask: Receives messages and prints content

Communication is implemented using <span>xMessageBufferSend()</span> and <span>xMessageBufferReceive()</span>.

Example Code

#include "FreeRTOS.h"
#include "task.h"
#include "message_buffer.h"
#include <stdio.h>
#include <string.h>

/* Define message buffer size (in bytes) */
#define MESSAGE_BUFFER_SIZE    100

/* Task stack size and priority */
#define TASK_STACK_SIZE        128
#define TASK_PRIORITY          2

/* Declare message buffer handle */
MessageBufferHandle_t xMessageBuffer;

/* Sender Task */
void SenderTask(void *pvParameters)
{
    const char *pcMessageArray[] = {
        "Hello",
        "FreeRTOS",
        "Message Buffer Example",
        "End"
    };

    for (int i = 0; i < sizeof(pcMessageArray) / sizeof(pcMessageArray[0]); i++)
    {
        const char *msg = pcMessageArray[i];
        size_t msgLen = strlen(msg) + 1; // Including '\0'

        /* Send message */
        size_t bytesSent = xMessageBufferSend(xMessageBuffer,
                                              (void *)msg,
                                              msgLen,
                                              pdMS_TO_TICKS(1000));  // Wait up to 1 second

        if (bytesSent != msgLen)
        {
            printf("Failed to send message: %s\n", msg);
        }
        else
        {
            printf("Sent message: %s\n", msg);
        }

        vTaskDelay(pdMS_TO_TICKS(1000));  // Delay 1 second
    }

    vTaskDelete(NULL);
}

/* Receiver Task */
void ReceiverTask(void *pvParameters)
{
    char recvBuffer[50];

    while (1)
    {
        /* Try to receive message */
        size_t bytesReceived = xMessageBufferReceive(xMessageBuffer,
                                                     recvBuffer,
                                                     sizeof(recvBuffer),
                                                     portMAX_DELAY); // Wait indefinitely

        if (bytesReceived > 0)
        {
            printf("Received message: %s\n", recvBuffer);
        }
    }
}

int main(void)
{
    /* Create message buffer */
    xMessageBuffer = xMessageBufferCreate(MESSAGE_BUFFER_SIZE);

    if (xMessageBuffer == NULL)
    {
        printf("Failed to create message buffer!\n");
        while (1);
    }

    /* Create sender and receiver tasks */
    xTaskCreate(SenderTask, "Sender", TASK_STACK_SIZE, NULL, TASK_PRIORITY, NULL);
    xTaskCreate(ReceiverTask, "Receiver", TASK_STACK_SIZE, NULL, TASK_PRIORITY, NULL);

    /* Start scheduler */
    vTaskStartScheduler();

    /* If scheduler fails to start, it will not execute here */
    for (;;);
}

Code Explanation

• <span>xMessageBufferCreate()</span>: Creates a message buffer of size 100 bytes.
• <span>xMessageBufferSend()</span>: Sends string messages.
• <span>xMessageBufferReceive()</span>: Receives a complete message (including variable-length content).
• Using <span>portMAX_DELAY</span> allows the receiving task to block until a message is available to read.

Application Scenarios

• A task receives data from a serial port and sends it to another task for processing.
• An interrupt service routine from a sensor packages data and sends it to a task.
• Used for asynchronous transmission of logs, debugging information, etc.

Application Notes

• Sending and receiving tasks cannot access concurrently (unless using mutex or ISR-safe interfaces)
• Generally, <span>Message Buffer / Stream Buffer</span> is only used for one-to-one communication
• If truly needing many-to-one, consider adding synchronization mechanisms or using queues.
