Tight Coupled Memory on Microchip Cortex®-M7 MCU
This document describes how to configure and use the tight coupled memory (TCM) features in PIC32C and SAM MCUs using the MPLAB® XC32 compiler and MPLAB Harmony v3 software development framework within the MPLAB X IDE.
TCM offers numerous advantages for application developers, providing performance equivalent to when the code is located in cache.
Below are some suggestions for optimizing TCM usage in applications:
-
The application stack can be located in DTCM
-
The application heap can be located in DTCM
-
Critical variables can be located in DTCM
-
Frequently updated variables can be located in DTCM
-
Critical functions/programs can be located in ITCM
-
A copy of the interrupt vector table can be located in ITCM
-
Interrupt service routines can be located in ITCM
Main Content
-
Overview of Microchip Cortex-M7 based MCUs
-
Overview of Cache Memory and TCM
-
Tight Coupled Memory
-
Configuration
-
Impact of Software on TCM
-
Programming Sequence for TCM Configuration
-
Hardware and Software Requirements
-
Compiling and Programming the Application
-
Observing Output on MPLAB Data Visualizer
